- Page 1 User Manual BG-UHD-DA1x24 HDMI V2.0 1x24 Splitter with Downscaling and AOC Supported All Rights Reserved...
-
Page 2: Table Of Contents
Table of Contents 1. Product Introduction ....................1 1.1 Features ......................1 1.2 Package List ....................... 1 2. Specification ........................ 2 3. Panel Description ......................4 3.1 Front Panel ......................4 3.2 Rear Panel ......................4 4. System Connection ..................... 5 5. -
Page 3: Product Introduction
1. Product Introduction Thank you for your purchase of the BG-UHD-DA1X24. The 1x24 splitter can distribute one HDMI input to twenty-four HDMI outputs. The distribution amp supports HDMI V2.0, 4K signals up to 4K@60Hz 4:4:4, HDR 10, Dolby Vision and features advanced EDID management option using 4-pin DIP switch on the front panel of the unit. -
Page 4: Specification
2. Specification Video Input (1) HDMI Input Connector (1) Type-A female HDMI Input Video Resolution Up to 4K@60Hz 4:4:4 8bit, HDR10, Dolby Vision Output (24) HDMI Output Connector (24) Type-A female HDMI Output Video Up to 4K@60Hz 4:4:4 8bit, HDR10, Dolby Vision, supports 4K to 1080p Resolution down-scaling. - Page 5 Video Resolution Down-scaling: The splitter supports video resolution downscaling, the 4K input can be automatically degraded to 1080p output for compatibility with 1080p display, shown in the below chart. Input Output Color Resolution Refresh Downscale 1080p Specs Space 3840x2160 60Hz 4:4:4 Support 1080p@60Hz 4:4:4...
-
Page 6: Panel Description
3. Panel Description 3.1 Front Panel INPUT 1 2 3 4 EDID ① POWER SWITCH: Power on/off the splitter. ② POWER LED: Illuminates red when the device is powered on. ③ INPUT LED: Illuminates green when there is HDMI input. ④... -
Page 7: System Connection
4. System Connection The following diagram illustrates the typical input and output connection of the splitter: HDMI: Audio: RS232: OUTPUTS RS232 AUDIO OUT DC 24V INPUT 1080p Blue-Ray Amplifier Central Control System 4K TV 4K TV 1080p TV 1080p 4K TV 4K TV 1080p TV... -
Page 8: Dip Switch Operation
5. DIP Switch Operation The 4-pin DIP switch on the front panel of the unit is used for EDID management and HDCP management. It represents “0” when in the lower (OFF) position, and it represents “1” while putting the switch in the upper (ON) position. Switch 1~3 are used for EDID setting. -
Page 9: Rs232 Control
6. RS232 Control Connect the RS232 port to control device (e.g. PC) with RS232 cable. The splitter can be controlled by sending RS232 commands. RS232 Commands The command lists are used to control the splitter. The RS232 control software (e.g. docklight) needs to be installed on the control PC to send RS232 commands. -
Page 10: Setting Commands
6.2 Setting Commands Command Example and Command Description Feedback <User edid ready,Please send edid data in 10s. Upload user-defined EDID. The EDID >SetUpdateEdid <SetUpdateEdid_True/False DIP switch must be set as “1111”. <Time out to send edid Set the EDID to [Param]. Param]=0~7. -
Page 11: Firmware Upgrade
[Param]=1~24.Output port. [Param] <VideoOutput 1 True Enable/disable 4K to 1080p down- >SetAutoDownScaler EN scaling function. >SetAutoDownScaler [Param]= EN, Dis [Param] <AutoDownScaler True Dis - Disable En - Enable Get the on-off status of down-scaling >GetAutoDownScaler <AutoDownScaler True function. Set the baud rate to [Param]. >SetRS232Baudrate 1 [Param]=1~7 1 - 115200... -
Page 12: Warranty
8. Warranty BZBGEAR wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*! Taking advantage of this program is simple, just follow the steps below: 1.
