1×4 HDBaseT Splitter
VER 1.0
Thank you for purchasing this product
For optimum performance and safety, please read these instructions
carefully before connecting, operating or adjusting this product. Please
keep this manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be
damaged by electrical spikes, surges, electric shock, lighting strikes, etc.
Use of surge protection systems is highly recommended in order to
protect and extend the life of your equipment.
Table of Contents
1. Introduction
2
Advertisement
Related Manuals for BZB Gear BZ-UHD-1x4HDBT
Summary of Contents for BZB Gear BZ-UHD-1x4HDBT
- Page 1 1×4 HDBaseT Splitter VER 1.0 Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc.
-
Page 2: Table Of Contents
2. Features 2 3. Package Contents 4. Specifications 5. Operation Controls and Functions 4 5.1 Transmitter Pa 4 5.2 Receiver Panel 6 6. HDBT Receiver 9 7. Web GUI User Guide 10 8. Application Example 16 1. Introduction The 1x4 HDBaseT splitter is an advanced signal distribution amplifier that can distribute one HDMI signal to four HDBaseT outputs each up to 230ft/70m through a single Cat6/6a cable. -
Page 3: Package Contents
3. Package Contents ① 1x 1×4 HDBaseT Splitter ② 4x HDBaseT Receivers ③ 4x Wideband IR Blaster cables ④ 4x Wideband IR Receiver cables ⑤ 1x 24V/2.7A Locking Power Adapter ⑥ 5x Phoenix connectors (5 pins male) ⑦ 4x Phoenix connectors (3 pins male) ⑧... -
Page 4: Operation Controls And Functions
5x IR OUTPUT [Phoenix jack] 4x HDBaseT Out [RJ45] 1x LAN [RJ45, Control] Input ports: 1×HDBaseT In [RJ45] IR In [3.5mm Stereo × Mini-jack] Output ports: 1×HDMI Type A Receiver [19-pin female] IR Out [3.5mm Stereo × Mini-jack] RS-232 [Phoenix ×... - Page 5 light. When the Power LED power supply is normal, the indicator LED is on HDMI IN LED: When the HDMI IN port has signal input, the indicator LED is HDMI LED HDMI OUT LED: When the HDMI OUT port has an active display be connected, the indicator LED is on...
-
Page 6: Receiver Panel
LED is on Select default EDID EDID button or copy HDBaseT OUT 1 EDID Press the button to open the power of the unit or set it as a standby mode. POWER button (Attention: The unit is power on status when it is powered on firstly.) 5.2 Receiver Panel... - Page 7 Connect 24V/2.7A adaptor to AC wall DC 24V outlet for power supply Connects to an active Ethernet link by an RJ-45 cable RS-232: Phoenix jack connects control equipment to transmit command from transmitter RS-232 to every MASTER receiver RS-232 port or transmit command from every receiver...
- Page 8 equipment to transmit signal from every receiver IR IN port RS-232: Phoenix jack connects control equipment to transmit command between Transmitter and Receiver. RS-232/IR (Attention: Transmitter RS-232 port and receiver RS-232 port is one-to-one transmission IR IN: Phoenix jack connects control equipment to transmission IR signal between...
-
Page 9: Hdbt Receiver
POC (Power over Cable) Application Example ※ Description 2 Bidirectional Infrared control Application Example ※ Description 3 Bidirectional RS232 control Application Example 6. HDBT Receiver Number Name Function description This LED illuminates when the POWER device is connected with power supply Plug the 24V DC power supply into the unit.(If the device connect to the... - Page 10 This slot is where HDMI OUT you connect the HDTV or monitor with HDMI cable Channel 1 IR Receiver. Connect IR IN with Wideband IR Channel 2 IR Transmitter. IR OUT Connect with Wideband IR Tx Connect to a PC or control system with RS-232 phoenix jack for...
-
Page 11: Web Gui User Guide
7. Web GUI User Guide The Splitter can be controlled via Web GUI through LAN port. You must know current Splitter IP address. The static IP address is 192.168.1.100. You can connect PC Web GUI through dynamic IP adress. In this unit, you can get the IP address via PC Controller. - Page 12 The “Yes” has connected display device and “No” represent not connection. ⑤ Reboot button: Click this button will reboot device. Factory Output button: Click this button will set to factory reset. EDID page ① Set EDID mode to input source, then click the “Set” button. ②...
-
Page 13: Application Example
We believe everyone deserves to see, hear, and feel the advancements made in today’s AV world without having to break the bank. BZB Gear is the solution for small to medium-sized applications requiring the latest professional products in AV. - Page 14 BZB Gear wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*! Taking advantage of this program is simple, just follow the steps below: 1.
