- Page 1 User Manual BG-UHD-DA1X16 HDMI V2.0 1x16 Splitter with Downscaling and AOC Supported All Rights Reserved...
-
Page 2: Table Of Contents
HDMI V2.0 1x16 Splitter with Downscaling and AOC Supported Table of Contents 1. Product Introduction ....................1 1.1 Features ......................1 1.2 Package List ....................... 1 2. Specification ........................ 2 3. Panel Description ......................4 3.1 Front Panel ......................4 3.2 Rear Panel ...................... -
Page 3: Product Introduction
HDMI V2.0 1x16 Splitter with Downscaling and AOC Supported 1. Product Introduction Thank you for choosing our HDMI V2.0 1x16 Splitter, which can distribute one HDMI input to sixteen HDMI outputs. The splitter supports 4K signals up to 4K@60Hz 4:4:4, HDR 10, Dolby Vision and features advanced EDID management option using 4-pin DIP switch on the front panel of the unit. -
Page 4: Specification
HDMI V2.0 1x16 Splitter with Downscaling and AOC Supported 2. Specification Video Input (1) HDMI Input Connector (1) Type-A female HDMI Input Video Resolution Up to 4K@60Hz 4:4:4 8bit, HDR10, Dolby Vision Output (16) HDMI Output Connector (16) Type-A female HDMI Output Video Up to 4K@60Hz 4:4:4 8bit, HDR10, Dolby Vision, supports 4K to 1080p Resolution... - Page 5 HDMI V2.0 1x16 Splitter with Downscaling and AOC Supported Video Resolution Down-scaling: The splitter supports video resolution downscaling, the 4K input can be automatically degraded to 1080p output for compatibility with 1080p display, shown in the below chart. Input Output Color Resolution Refresh...
-
Page 6: Panel Description
HDMI V2.0 1x16 Splitter with Downscaling and AOC Supported 3. Panel Description 3.1 Front Panel INPUT 1 2 3 4 EDID ① POWER SWITCH: Power on/off the splitter. ② POWER LED: Illuminates red when the device is powered on. ③ INPUT LED: Illuminates green when there is HDMI input. ④... -
Page 7: System Connection
HDMI V2.0 1x16 Splitter with Downscaling and AOC Supported 4. System Connection The following diagram illustrates the typical input and output connection of the splitter: HDMI: Audio: RS232: OUTPUTS RS232 AUDIO OUT DC 24V INPUT 1080p Blue-Ray Amplifier Central Control System 4K TV 1080p TV 1080p... -
Page 8: Dip Switch Operation
HDMI V2.0 1x16 Splitter with Downscaling and AOC Supported 5. DIP Switch Operation The 4-pin DIP switch on the front panel of the unit is used for EDID management and HDCP management. It represents “0” when in the lower (OFF) position, and it represents “1”... -
Page 9: Rs232 Control
HDMI V2.0 1x16 Splitter with Downscaling and AOC Supported 6. RS232 Control Connect the RS232 port to control device (e.g. PC) with RS232 cable. The splitter can be controlled by sending RS232 commands. RS232 Commands The command lists are used to control the splitter. The RS232 control software (e.g. docklight) needs to be installed on the control PC to send RS232 commands. -
Page 10: Setting Commands
HDMI V2.0 1x16 Splitter with Downscaling and AOC Supported 6.2 Setting Commands Command Example and Command Description Feedback <User edid ready,Please send edid data in 10s. Upload user-defined EDID. The EDID >SetUpdateEdid <SetUpdateEdid_True/False DIP switch must be set as “1111”. <Time out to send edid Set the EDID to [Param]. -
Page 11: Firmware Upgrade
HDMI V2.0 1x16 Splitter with Downscaling and AOC Supported [Param]=1~16.Output port. [Param] <VideoOutput 1 True Enable/disable 4K to 1080p down- >SetAutoDownScaler EN scaling function. >SetAutoDownScaler [Param]= EN, Dis [Param] <AutoDownScaler True Dis - Disable En - Enable Get the on-off status of down-scaling >GetAutoDownScaler <AutoDownScaler True function. -
Page 12: Warranty
HDMI V2.0 1x16 Splitter with Downscaling and AOC Supported 8. Warranty BZBGEAR wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*! Taking advantage of this program is simple, just follow the steps below: 1.
