- Page 1 BG-UDAIC-E18 1X8 4K60 UHD 18Gbps HDMI Splitter/Distribution Amplifier up to 230ft User Manual...
- Page 2 BZBGEAR BG-UDAIC-E18 PRODUCT MANUAL · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com...
-
Page 3: Table Of Contents
BZBGEAR BG-UDAIC-E18 PRODUCT MANUAL TABLE OF CONTENTS Statement Safety Precaution Introduction Features Packing List Specifications Panel Description Installation Procedures Control Settings Tech Support Warranty Mission Statement Copyright · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906... -
Page 4: Statement
BZBGEAR BG-UDAIC-E18 PRODUCT MANUAL Statement Please read these instructions carefully before connecting, operating, or configuring this product. Please save this manual for future reference. Safety Precaution ● To prevent damaging this product, avoid heavy pressure, strong vibration, or immersion during transportation, storage, and installation. -
Page 5: Introduction
PRODUCT MANUAL Introduction The BG-UDAIC-E18 is an extender splitter kit that distributes 1 HDMI input to 8 HDMI outputs and extends these signals up to 230 feet (70m). The kit supports resolutions up to 4K@60Hz and the transmitter is also equipped with an HDMI loop out to view the content near the source. -
Page 6: Specifications
BZBGEAR BG-UDAIC-E18 PRODUCT MANUAL Specifications Item Specification Transport protocol ipcolor Split mode 1 IN 8 OUT Transmission Distance CAT 6/6A/7<70m HDMI signal HDMI 2.0, HDCP 2.2 Resolution 480i@60Hz,480p@60Hz,576i@50Hz,576p@50Hz, 720p@50/60Hz,1080i@50/60Hz,1080p@50/60Hz, 1280x960,1280x800,1280x768,1680x1050, 1360x768,1366x768,1600x900,1024x768, 800x600, 3840x2160@24/25/30/50/60Hz,4096x2160@24/25Hz Audio formats LPCM/DTS-HD/DTS-Audio/Dolby Digital 5.1 Bi-directional IR passback (20-60khz) -
Page 7: Panel Description
BZBGEAR BG-UDAIC-E18 PRODUCT MANUAL Panel Description Transmitter (TX) Name Function Description Power Indicator The indicator will turn blue when the power is turned on EDID DIP switch Set the output resolution through the EDID DIP switch IR in Connect to the IR receiver extension cable... - Page 8 BZBGEAR BG-UDAIC-E18 PRODUCT MANUAL Receiver (RX) No. Name Function Description Reset button Restarts the device Choose the audio source output from the S/PDIF port Audio switch S/PDIF: From the source device ARC: From the TV (receiver end) RJ45 signal input...
-
Page 9: Installation Procedures
BZBGEAR BG-UDAIC-E18 PRODUCT MANUAL Installation Procedures Connection Diagram Connection Instructions 1. Connect the source device to the transmitter's HDMI IN port using an HDMI cable. 2. Connect the transmitter's CAT6 OUT port to the receiver's CAT6 IN port using network cables. -
Page 10: Control Settings
BZBGEAR BG-UDAIC-E18 PRODUCT MANUAL Control Settings RS232 Settings The default configuration is as follows: Baud rate: 9600 / Data bits: 8 / Stop bits: 1 / Parity: 0 Control Commands Function Descriptions ES XX Onf【Enter】 Turn on the network signal output port(s), choose from “01” to “08” (the network ports from right to left are: 01, 02, 03, 04, 05, 06, 07, 08.);... - Page 11 BZBGEAR BG-UDAIC-E18 PRODUCT MANUAL EDID Settings: The transmitter has 16 built-in EDID settings that can be configured using the DIP switch panel. Flipping the DIP switch upward indicates a “1” and flipping them down indicates “0.” Switch up for "1"...
-
Page 12: Faq
BZBGEAR BG-UDAIC-E18 PRODUCT MANUAL Q: Why does my display device not have an image? 1. Check the power supply and all cables to ensure they are properly connected. 2. Check if the HDMI signal input is detected. 3. Check the corresponding network output and ensure it has not been turned off by the RS-232 command. -
Page 13: Tech Support
BZBGEAR BG-UDAIC-E18 PRODUCT MANUAL Tech Support Have technical questions? We may have answered them already! Please visit BZBGEAR’s support page (bzbgear.com/support) for helpful information and tips regarding our products. Here you will find our Knowledge Base (bzbgear.com/knowledge-base) with detailed tutorials, quick start guides, and step-by-step troubleshooting instructions. -
Page 14: Warranty
BZBGEAR BG-UDAIC-E18 PRODUCT MANUAL Warranty BZBGEAR Pro AV products and cameras come with a three-year warranty. An extended two-year warranty is available for our cameras upon registration for a total of five years. For complete warranty information, please visit bzbgear.com/warranty. -
Page 15: Mission Statement
BZBGEAR BG-UDAIC-E18 PRODUCT MANUAL Mission Statement BZBGEAR is a breakthrough manufacturer of high-quality, innovative audiovisual equipment ranging from AVoIP, professional broadcasting, conferencing, home theater, to live streaming solutions. We pride ourselves on unparalleled customer support and services. Our team offers system design consultation, and highly reviewed technical support for all the products in our catalog. -
Page 16: Copyright
BZBGEAR BG-UDAIC-E18 PRODUCT MANUAL Copyright All the contents in this manual and its copyright are owned by BZBGEAR. No one is allowed to imitate, copy, or translate this manual without BZBGEAR’s permission. This manual contains no guarantee, standpoint expression or other implies in any form. Product specification and information in this manual is for reference only and subject to change...
