- Page 1 BG-DA-1X4AS 1x4 HDMI 2.0 Splitter with Scaler/Audio Extract...
-
Page 2: Table Of Contents
Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. -
Page 3: Introduction
1. Introduction The 1x4 HDMI 2.0 Splitter simultaneously routes one HDMI source to four HDMI displays. It supports resolutions up to 4K2K@60Hz (4:4:4) and HDCP 2.2. This product supports audio extraction from the HDMI source to optical and analog outputs. It also features COPY and AUTO EDID settings. Output supports bypass and downscaler (4K->1080P) functions. -
Page 4: Specifications
4. Specifications Technical HDMI Compliance HDMI 2.0b HDCP Compliance HDCP 2.2 and HDCP 1.4 18Gbps Video Bandwidth 720P50/60Hz, 1080P50/60Hz, 4K2K24Hz, 4K2K30Hz, Video Resolution 4K2K@50/60Hz (4:4:4) Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2 Color Depth 4K60Hz 8-bit, 1080P 12-bit LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, HDMI Audio Formats DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD L/R Audio Formats... -
Page 5: Operation Controls And Functions
5. Operation Controls and Functions 5.1 Front Panel AUTO O F F CO PY 1 2 3 4 POWER OU T 1 OU T 2 OU T 3 OUT 4 SE RVIC E EDID 4K 1080P Number Name Function description This blue LED will illuminate when the unit is connected POWER LED to an active power supply. -
Page 6: Rear Panel
5.2 Rear Panel HDMI OU T 4 HDMI OUT 3 HDMI OUT 2 HDMI OUT 1 OPTICAL OUT L/R OUT HDMI IN DC 5V Number Name Function description HDMI OUTPUT Connect to HDMI display device. Optical audio output. OPTICAL OUT (This port outputs audio from HDMI IN port.) Analog audio output. -
Page 7: Application Example
6. Application Example HDMI OUT 2 HDMI OUT 1 OPTICAL OUT L/R OUT HDMI I N HDMI OUT 4 HDMI OUT 3 DC 5V Amplifier DVD or Blu-ray Player 2.0 Speakers UHDTV UHDTV... -
Page 8: Warranty
7. Warranty BZBGEAR wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*. Taking advantage of this program is simple, just follow the steps below: 1. -
Page 9: Mission Statement
8. Mission Statement BZBGEAR manifests from the competitive nature of the audiovisual industry to innovate while keeping the customer in mind. AV solutions can cost a pretty penny, and new technology only adds to it. We believe everyone deserves to see, hear, and feel the advancements made in today’s AV world without having to break the bank.
