INSTALLATION AND OPERATION INSTRUCTIONS FOR ZERO CLEARANCE
AND INSERT UNITS
ZC-FM-37
ZC-FM-45
INS-FM-26
INS-FM-30
INS-FM-34
SAFETY INFORMATION
WARNING
If the information in these instructions are
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Amantii ZC-FM-37
Summary of Contents for Amantii ZC-FM-37
- Page 1 INSTALLATION AND OPERATION INSTRUCTIONS FOR ZERO CLEARANCE AND INSERT UNITS ZC-FM-37 ZC-FM-45 INS-FM-26 INS-FM-30 INS-FM-34 SAFETY INFORMATION WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
Please read and carefully follow all of the instruction found in this manual. Please pay special attention to the safety instructions provided in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii product. IMPORTANT INSTRUCTIONS ........................... -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS Please read the following instructions carefully before using the appliance. Caution - Fire, electric shock, physical injury and material damage hazards: To use the appliance, always follow the instructions for assembly, use and maintenance as well as usage cautions: 1. - Page 4 the room on their own, unless constant supervision is provided. 22. If the glass is damaged, do not use the heater in order to avoid a hazard. 23. Children of less than 3 years should be kept away from unless continuously supervised. 24.
- Page 5 Cautions ·Always install the heater in accordance with this guide. If in doubt obtain expert advice. ·Always make sure the electrical socket is accessible and located adjacent to, but not above the heater. ·Always disconnect the heater from the electrical supply before Do’s moving it, or carrying out cleaning, maintenance.
-
Page 6: Plug Installation Instructions
PLUG INSTALLATION Your power cord will come separate from the unit, please locate it when unpacking your fireplace. The plug contained inside the box is predetermined at the factory and according to orders placed by authorized dealers. Available are UK, European & Swiss plugs. Should you require any of these options please contact your dealer for purchase. -
Page 7: Unpacking And Testing Appliance
UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Remove the packing screws from both sides of the fireplace. Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a conveniently located 240 Volt grounded outlet. Test all aspects of its operation (manual switches, remote and heater) to make sure all components operate correctly. -
Page 8: Clearances When Built-In
A 15 ampere, 240 Volt, 50 Hz branch circuit with proper ground must be available at the location. Preferably a dedicated branch circuit should be provided to avoid circuit breakers to trip of fuses to blow. CLEARANCES WHEN BUILT-IN The fireplace may be placed within a framed enclosure that is level, dry and capable of supporting the weight of the appliance and front glass. -
Page 9: Zc-Fm-37
ZC-FM-37 Description Built-in Appliance Voltage 240V AC 50Hz Watts 1900W Max NO HEATER 20.7W MOTOR HEATER Appliance Width 29 3/8” or 74.6 cm Appliance Height 24 3/4” or 63.2 cm Appliance Depth 10 1/4” or 26.1 cm Gross Weight 63.8 lbs or 29kg... -
Page 10: Zc-Fm-45
ZC-FM-45 Description Built-in Appliance Voltage 240V AC 50Hz Watts 1900W Max NO HEATER 27.8W MOTOR HEATER Appliance Width 37 1/2” or 95.5 cm Appliance Height 31 3/4” or 80.5 cm Appliance Depth 10 1/4” or 26.1 cm Gross Weight 92.4lbs or 42kg Plug Location Left side Cord Length... -
Page 11: Ins-Fm-26
INS-FM-26 Description Built-in Appliance Voltage 240V AC 50Hz Watts 1900W Max NO HEATER MOTOR HEATER Appliance Width 25 1/4” or 64.2 cm Appliance Height 16 7/8” or 42.8 cm Appliance Depth 8 3/4” or 22.2 cm Gross Weight 61.6lbs or 28kg Plug Location Left side Cord Length... -
Page 12: Ins-Fm-30
INS-FM-30 Description Built-in Appliance Voltage 240V AC 50Hz Watts 1900W Max NO HEATER 16.2W MOTOR HEATER Appliance Width 29 1/2” or 74.6 cm Appliance Height 19 ” or 48.2 cm Appliance Depth 10” or 25.7 cm Gross Weight 63.8lbs or 29kg Plug Location Left side Cord Length... -
Page 13: Ins-Fm-34
INS-FM-34 Description Built-in Appliance Voltage 240V AC 50Hz Watts 1900W Max NO HEATER 20.5W MOTOR HEATER Appliance Width 33” or 84 cm Appliance Height 23” or 58.7 cm Appliance Depth 10” or 25.7 cm Gross Weight 77lbs or 33kg Plug Location Left side Cord Length 72.6”... -
Page 14: Installation Overview - Masonry Fireplaces
INSTALLATION OVERVIEW – MASONRY FIREPLACES Cover plate is required if chimney does not have suitable rain cap. 2” (50mm) Minimum HINT: Close and seal the damper to prevent air infiltration. Attach the "This fireplace has been altered..." plate to the fireplace (use two screws or other suitable method). -
Page 15: Installation Overview -Zero-Clearance (Metal) Fireplaces
INSTALLATION OVERVIEW –ZERO-CLEARANCE (METAL) FIREPLACES Cover plate is required if chimney does not have suitable rain cap. The log shelf, screen, and doors (if present) must be removed. 2” (50mm) Minimum HINT: Close and seal the damper to prevent air infiltration. HINT: Attach the "This fireplace has been Paint the interior of the... -
Page 16: Media Options
MEDIA OPTIONS The fireplace shipped with an ember log set that set. is pre-installed. Consumers have their choice of decorative media should they wish to install it. (INS-FM-30 and INS-FM-34 can not do the decorative media install) Log set Installing the decorative media HZ-12-EMBER Pour the decorative media into the tray. -
Page 17: Operation
OPERATION The fireplace can be operated either by the switches located on the left bottom of the fireplace unit or by supplied remote control. Plug the fireplace into a 15 Amp wall socket. MANUAL OPERATION 1、 Press key . Press for the first time，heater work at 1900W, indicator lights red. -
Page 18: Remote Control Operation-Standard Flame
REMOTE CONTROL OPERATION-STANDARD FLAME 、 Press the remote control’s key“ ”, its screen turns on, the flame ignites and the flame icon appears on the LCD screen of the remote control. Week, time (24h system), and temperature setting are displayed normally. - Page 19 7、 Press the heating key“ .” Press for the first time ,the heating elements work at 1900W, the LCD screen displays , the indicator on the machine lights red. Press a second time , the heating elements work at 950W, the LCD screen displays , the indicator on the machine lights blue.
- Page 20 for Tuesday. Press for the 7th time and it displays . Press for the 8th time and it exits and recovers to the current week day; 11、Press“ .” Press for the first time and the timing function turns on, the LCD screen displays the machine’s indicator lights green.
-
Page 21: Care And Maintenance
CARE AND MAINTENANCE 1. Switch off and unplug from the power supply before cleaning. 2. Using a soft, moist cloth, with or without a mild soap solution, carefully clean the exterior surface of the products. CAUTION: Allow the product to completely cool before handling or cleaning it. 3. -
Page 22: Replacement Parts
REPLACEMENT PARTS PART NUMBER QTY. INS-FM-26 ZC-FM-37 INS-FM-30 ZC-FM-45 INS-FM-34 DESCRIPTION TOP PANEL 602032B 602032B 602032B 602032B 602032B BLOWER AND HEATER ASSEMBLY 601094F 601094F 601094F 601094F 601094F CIRCUIT BOARD FIREPLACE BOX 10104010 10104010 10104010 10104010 10104010 SWITCH 601035 601035 601035... -
Page 23: Exploded View
EXPLODED VIEW... -
Page 24: Trouble Shooting
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary Back black cloth is falling off Change a new flicker and back and roll the flicker black cloth Ember Ember LED’s are burnt out Inspect the ember bed LED’s and... -
Page 25: Service History
SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service Technician Service Performed Special Concerns Name Name NOTES:...
