INSTALLATION AND OPERATION INSTRUCTIONS FOR
INS-FM-30 / INS-AMB-30
(INS-190030-01)
INS-FM-34 / INS-AMB-34
(INS-190030-01)
SAFETY INFORMATION
For your safety, always comply with all
warnings and safety instructions
contained in this manual to prevent
personal injury or property damage.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this appliance.
INSTALLER: LEAVE OWNER'S MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN OWNER'S MANUAL FOR FUTURE REFERENCE.
WARNING
Version:20211111
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Amantii INS-AMB-30
Summary of Contents for Amantii INS-AMB-30
- Page 1 INSTALLATION AND OPERATION INSTRUCTIONS FOR INS-FM-30 / INS-AMB-30 (INS-190030-01) INS-FM-34 / INS-AMB-34 (INS-190030-01) SAFETY INFORMATION WARNING For your safety, always comply with all warnings and safety instructions contained in this manual to prevent personal injury or property damage. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this appliance.
-
Page 2: Table Of Contents
Please read and carefully follow all of the instruction found in this manual. Please pay special attention to the safety instructions provided in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii product. IMPORTANT INSTRUCTIONS ............................ -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS PLEASE RETAIN THIS USER GUIDE FOR FUTURE REFERENCE When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1) Read all instructions before using this fireplace 2) The fireplace is hot when in use. -
Page 4: Fcc Cautions
FCC CAUTIONS This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 5: Unpacking And Testing The Appliance
UNPACKING AND TESTING APPLIANCE ND TESTING APPLIANCE Carefully remove the appliance from the box. Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging Prior to installing the appliance, test to make sure the appliance operates properly by plugging Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a 120 Volt grounded outlet. -
Page 6: Ins-Fm-30 / Ins-Amb-30 (Ins-190030-1)
INS-FM-30/INS-AMB-30(INS-190030-01) This appliance has been tested in Description Built-in Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated Watts 1500W Max electric room appliances in the United NO HEATER 16.2W States and Canada. If you need... -
Page 7: Ins-Fm-34 / Ins-Amb-34 (Ins-190034-1)
INS-FM-34/INS-AMB-34(INS-190034-01) This appliance has been tested in Description Built-in Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated Watts 1500W Max electric room appliances in the United NO HEATER 20.5W States and Canada. If you need MOTOR HEATER assistance during installation, please Appliance Width... -
Page 8: Installation Built-In
INSTALLATION BUILT-IN The fireplace may be placed within a framed enclosure that is level, dry and capable of supporting the weight of the appliance and front glass. It may be placed directly on wood or a non-combustible surface(not on linoleum or carpet). The side and back must maintain 1”(25.4mm) clearance to any material. -
Page 9: Mantel Clearance
MANTEL CLEARANCE The clearance to the mantel should be 2” minimum when a mantel is applied (Measurement is taken from the trim). Wall Mantel Fireplace Floor... -
Page 10: Hardwire Installation
HARDWIRE INSTALLATION Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance. If it is necessary to hard-wire this appliance, a qualified electrician must remove the cord connection, and wire the appliance directly to the house hold wiring. This appliance must be electrically connected and grounded in accordance with local codes, if hardwired. -
Page 11: Media Options
MEDIA OPTIONS Your fireplace shipped with the following media: sable glass and 6 piece log set. Customers can decorate their fireplace according to their wishes with supplied media. This fireplace includes the following decorative media: Sable Log set MEDIA INSTALLATION STEP 1: Unplug the unit and make sure Now you can start to decorate your fireplace control is switched off. -
Page 12: Operation
OPERATION The Fireplace operates by using either the touch panel located on the upper left hand corner or by remote control. Plug the fireplace into a 15 Amp wall socket. Plug the fireplace into a 15 Amp wall socket. MANUAL OPERATION Press to turn on and off the fireplace. -
Page 13: Remote Control Operation
REMOTE CONTROL OPERATION For remote to function make sure the fireplace is plugged in and the remote has batteries. Important: When operating the remote make sure you point the remote to the center of the fireplace. Each time you press the button, the buzzer inside the unit will beep once. It takes some time for the receiver to respond to the transmitter. - Page 14 AUTO means fireplace can automatically adjust to the temperature you set. When in AUTO, you can set the desired temperature with keys. You can switch temperature between Celsius and Fahrenheit with keys.When it is on Auto mode,fireplace operate at 1500W. Press this button to adjust the speed of the flame.
- Page 15 When the 7 day timer’s set, the icon will be displayed on the LCD screen of the remote control. Press again to cancel the 7 da y timer and the icon will disappears. NOTE: If the 7 day timing and the general timing are set at the same time, the system will respond to an earlier shutdown time.
-
Page 16: Wifi Operation
WIFI OPERATION INSTALL TuyaSmart life There are 2 ways to install TuyaSmart; 1. Search for “TuyaSmart life” in the APP store on your phone, download and install. 2. Scan the QR code below with your mobile phone. WIFI SETTING AND FIREPLACE OPERATION 1. - Page 17 FIG.4 3. Press (flame button) on the touch panel of the fireplace for more than 5 seconds when the fireplace in standby mode. There will be 2 beeps come out from the fireplace and the (flame button) will flash as well indicating that Wi-fi is in EZ mode. Then please confirm to go next.
- Page 18 6. Now you are in the interface like FIG.7. You can operate the fireplace via Wi-fi. FIG.7 NOTE: Turn off the flashing blue Wifi indicator light Touch the (power button) once, the blue light will stop flashing.
-
Page 19: Replacement Parts
REPLACEMENT PARTS Ref. Description Quantity INS-FM-30/INS-AMB-30 INS-FM-34/INS-AMB-34 (INS-190030-1) (INS-190034-1) Trim 3103502 3104502 Adjustable screws Not applicable Not applicable Front glass bracket Not applicable Not applicable Front glass 10701184 10701185 Back glass 107021031 107021041 10702132D 10702214 Tray glass Side glass Not applicable... -
Page 20: Exploded View
EXPLODED VIEW... -
Page 21: Wiring Diagram
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary. Back black cloth is falling off Change a new flicker and back and roll the flicker black cloth. Ember Ember LED’s are burnt out Inspect the ember bed LED’s and... -
Page 22: Service History
SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service technician Service Performed Special Concerns Name Name NOTES:... - Page 23 Products covered by this limited warranty have been tested and inspected prior to shipment and, subject to the provisions of this warranty, Amantii warrants such products to be free from defects in material and workmanship for a period of five (5) years from the date of the first purchase of such products.
-
Page 24: Warranty
The provisions of the United Nations Convention on Contracts for the Sale of Goods shall not apply to this limited warranty or the sale of products covered by this limited warranty. GENERAL Amantii reserves the right to make changes at any time without notice, in design, material, specifi cations, prices and the right to discontinue styles and products. GLASS...
