INSTALLATION AND OPERATION INSTRUCTIONS FOR ZERO
CLEARANCE AND INSERT UNITS
INS-FM-30
INS-FM-34
SAFETY INFORMATION
WARNING
If the information in these
instructions are not followed exactly,
a fire or explosion may result causing
property damage, personal injury or
loss of life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Amantii INS-FM-30
Summary of Contents for Amantii INS-FM-30
- Page 1 INSTALLATION AND OPERATION INSTRUCTIONS FOR ZERO CLEARANCE AND INSERT UNITS INS-FM-30 INS-FM-34 SAFETY INFORMATION WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
Please read and carefully follow all of the instruction found in this manual. Please pay special attention to the safety instructions provided in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii product. IMPORTANT INSTRUCTIONS............................3 UNPACKING AND TESTING APPLIANCE .......................4... -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS PLEASE RETAIN THIS USER GUIDE FOR FUTURE REFERENCE When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1) Read all instructions before using this fireplace 2) The fireplace is hot when in use. -
Page 4: Unpacking And Testing Appliance
UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a 120 Volt grounded outlet. Test all aspects of its operation (manual switches, remote and heater) to make sure all components are operating correctly. -
Page 5: Ins-Fm-30
INS-FM-30 This appliance has been tested in Description Built-in Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated Watts 1500W Max electric room appliances in the United NO HEATER 16.2W States and Canada. If you need... -
Page 6: Ins-Fm-34
INS-FM-34 This appliance has been tested in Description Built-in Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated Watts 1500W Max electric room appliances in the United NO HEATER 20.5W States and Canada. If you need MOTOR HEATER assistance during installation, please Appliance Width... -
Page 7: Installation Built In
INSTALLATION BUILT-IN The fireplace may be placed within a framed enclosure that is level, dry and capable of supporting the weight of the appliance and front glass. It may be placed directly on wood or a non-combustible surface(not on linoleum or carpet). The side and back must maintain 1”(25.4mm) clearance to any material. -
Page 8: Hard- Wire Installation
HARD- WIRE INSTALLATION Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance. If it is necessary to hard- wire this appliance, a qualified electrician must remove the cord connection, and wire the appliance directly to the house hold wiring. -
Page 9: Media Options
MEDIA OPTIONS Your fireplace shipped with the following media: sable glass and 6 piece log set. Customers can decorate their fireplace according to their wishes with supplied media. This fireplace includes the following decorative media: Sable Log set MEDIA INSTALLATION STEP 1: Unplug the unit and make sure Now you can start to decorate your fireplace control is switched off. -
Page 10: Operation
OPERATION The fireplace can be operated either by the switches located on the left bottom of the fireplace unit or by supplied remote control. Plug the fireplace into a 15 Amp wall socket. MANUAL OPERATION 1. The main power ON/OFF switch in position O, the fireplace is OFF. 2. -
Page 11: Remote Control Operation
REMOTE CONTROL OPERATION For remote to function make sure the heater is plugged in and main power switch located on the bottom left hand side is at position I. When operating the remote make sure you point the remote to the centre of the fireplace and make sure each time you press the button the buzzer inside the unit will beep once. -
Page 12: Installing Wall Thermostat
INSTALLING WALL THERMOSTAT WALL THERMOSTAT WIRING DIAGRAMS NOTE: The wall thermostat will be functioning when the heater is on the TEMP. setting. Wire the wall thermostat prior to installing the fireplace. WALL THERMOSTAT WIRING(24 VAC) Install Wall Thermostat per instructions provided with kit and per the following information: 1. -
Page 13: Replacement Parts
REPLACEMENT PARTS PART NUMBER QTY. DESCRIPTION INS-FM-30 INS-FM-34 TRIM 3103502 3104502 FRONT PANEL 3103501 3104501 FRONT GLASS 10701184 10701185 EMBER BED GLASS 10702132D 10702133D 3103009B 3104012B PLASTIC BOARD FIRE BOX 301506 THERMOSTAT SWITCH 10104010 CIRCUIT BOARD 601097B BLOWER AND HEATER... -
Page 14: Exploded View
EXPLODED VIEW... -
Page 15: Truble Shooting
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary Back black cloth is falling off Change a new flicker and back and roll the flicker black cloth Ember Ember LED’s are burnt out Inspect the ember bed LED’s and... -
Page 16: Service History
SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service Technician Service Performed Special Concerns Name Name NOTES:...
