INSTALLATION AND OPERATION INSTRUCTIONS FOR ZERO
CLEARANCE AND INSERT UNITS
ZECL-31-3228-STL
SAFETY INFORMATION
WARNING
If the information in these
instructions are not followed exactly,
a fire or explosion may result causing
property damage, personal injury or
loss of life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
Advertisement
Table of Contents
Related Manuals for Amantii ZECL-31-3228-STL
Summary of Contents for Amantii ZECL-31-3228-STL
- Page 1 INSTALLATION AND OPERATION INSTRUCTIONS FOR ZERO CLEARANCE AND INSERT UNITS ZECL-31-3228-STL SAFETY INFORMATION WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
-
Page 2: Table Of Contents
Please read and carefully follow all of the instruction found in this manual. Please pay special attention to the safety instructions provided in this manual. The instructions included here will as sure that you have many years of dependable and enjoyable service from your Amantii product. -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS Read all instructions before installing or using this heater. 2. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet from the front of the heater; keep them away from sides and rear as well. -
Page 4: Unpacking And Testing Appliance
UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a conveniently located 120 Volt grounded outlet. Test all aspects of its operation (manual switches, remote and heater) to make sure all components operate correctly. -
Page 5: Clearances When Built-In
CLEARANCES WHEN BUILT-IN The fireplace may be placed within a framed enclosure that is level, dry and capable of supporting the weight of the appliance and front glass. It may be placed directly on wood or a non-combustible surface(not on linoleum or carpet). The minimum clearance from the top of the appliance to a mantel (combustible or non-combustible) is 2”... -
Page 6: Zecl-31-3228-Stl
ZECL-31-3228-STL This appliance has been tested in Description Built-in Appliance accordance with the UL Standard Voltage 120V AC 60Hz 2021 fixed location Watts 1500W Max dedicated electric room appliances NO HEATER in the United States and Canada. If MOTOR HEATER... - Page 7 Square Surround ZECL-31-3228-STL-SQR Arch Surround ZECL-31-3228-STL-ARCH...
- Page 8 INSTALLATION OVERVIEW – MASONRY FIREPLACES Cover plate is required if chimney does not have suitable rain cap. 2” (50mm) Minimum HINT: Close and seal the damper to prevent air infiltration. Attach the "This fireplace has been altered..." plate to the fireplace (use two screws or other suitable method).
-
Page 9: Installation Overview -Zero-Clearance (Metal) Fireplaces
INSTALLATION OVERVIEW –ZERO-CLEARANCE (METAL) FIREPLACES Cover plate is required if chimney does not have suitable rain cap. The log shelf, screen, and doors (if present) must be removed. 2” (50mm) Minimum HINT: Close and seal the damper to prevent air infiltration. HINT: Attach the "This fireplace has been Paint the interior of the... -
Page 10: Hard- Wire Installation
HARD- WIRE INSTALLATION Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance. If it is necessary to hard wire this appliance, a qualified electrician must remove the cord connection, and wire the appliance directly to the house hold wiring. -
Page 11: Media Options
MEDIA OPTIONS The fireplace shipped with an ember log set that is pre-installed. Consumers have their choice of decorative media should they wish to install it. Log set Log set Installing the decorative media HZ-12-EMBER Pour the decorative media into the tray. Feel free to use any combination of fire glass media that you find most appealing. -
Page 12: Operation
OPERATION The fireplace can be operated either by the switches located on the left front of the fireplace unit or by supplied remote control. MANUAL OPERATION 1. The main power ON/OFF switch in position O, the fireplace is OFF. 2. When main power ON/OFF switch is at position I, the fireplace is ready to use. 3. -
Page 13: Remote Control Operation
REMOTE CONTROL OPERATION For remote to function make sure the heater is plugged in and mains power switch located on the bottom left hand side is at position I. When operating the remote make sure you point the remote to the centre of the fireplace and make sure each time you press the button. -
Page 14: Installing Wall Thermostat
INSTALLING WALL THERMOSTAT WALL THERMOSTAT WIRING DIAGRAMS NOTE: THE WALL THERMOSTAT WILL WOKING WHEN THE HEATER ON TEMP. SETTING.PLEASE REEFER TO THE MANUAL CONTROL AND THE REMOTE CONTROL. Wire the wall thermostat prior to installing the fireplace. WALL THERMOSTAT WIRING(24 VAC) Install Wall Thermostat per instructions provided with kit and per the following information: 1. -
Page 15: Replacement Parts
REPLACEMENT PARTS PART NUMBER DESCRIPTION QTY. TOP PANEL 602030C BLOWER AND HEATER ASSEMBLY 601097B CIRCUIT BOARD FIREPLACE BOX 10104010 SWITCH 601032B CONTROL PANEL 10104010 REMOTE RECEIVER 359006B BACK GLASS 601136B+601137B FLAME LED STRIP 10702138B BOTTOM GLASS 3059019 RIGHT BRACKET 10101225 FLICKER MOTOR 3059502 FLICKER ASSEMBLY... -
Page 16: Exploded View
EXPLODED VIEW... -
Page 17: Trouble Shooting
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary. Back black cloth is falling off Change a new flicker and back and roll the flicker black cloth. Ember Ember LED’s are burnt out Inspect the ember bed LED’s and... -
Page 18: Service History
SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service technician Service Performed Special Concerns Name Name NOTES:... -
Page 19: Warranty
Products covered by this limited warranty have been tested and inspected prior to shipment and, subject to the provisions of this warranty, Amantii warrants such products to be free from defects in material and workmanship for a period of one (1) year from the date of the first purchase of such products.
