Stirling Black Edition PA33W Instruction Manual

Stirling Black Edition PA33W Instruction Manual

Wi-fi portable air conditioner (3.3kw cooling)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Wi-Fi Portable Air Conditioner
(3.3kW Cooling)
Model Number PA33W
INSTRUCTION MANUAL
AFTER SALES SUPPORT
info@tempo.org
AUS
1300 886 649
MODEL: PA33W PRODUCT CODE: 703225 10/2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Black Edition PA33W and is the answer not in the manual?

Questions and answers

Related Manuals for Stirling Black Edition PA33W

Summary of Contents for Stirling Black Edition PA33W

  • Page 1 Wi-Fi Portable Air Conditioner (3.3kW Cooling) Model Number PA33W INSTRUCTION MANUAL AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: PA33W PRODUCT CODE: 703225 10/2020...
  • Page 2 Welcome Congratulations on choosing to buy a STIRLING product. ® All products brought to you by STIRLING are manufactured to the highest ® standards of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 3 Year Warranty.

  • Page 3: Table Of Contents

    Contents 02 Welcome 04 Warranty Details 05 General Safety Instructions 09 R290-Specific Safety Advice 11 Getting Started 12 Product Overview 16 Installation 18 Instructions 21 Wi-Fi Control 28 FAQs & Troubleshooting Guide 29 Other Useful Information 35 Repair and Refurbished Goods or Parts Notice AFTER SALES SUPPORT info@tempo.org 1300 886 649...

  • Page 4: Warranty Details

    Wi-Fi Portable Air Conditioner (3.3kW Cooling) Warranty Details REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION The product is guaranteed to be free from defects in workmanship and parts for a period of 36 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion.

  • Page 5: General Safety Instructions

    General Safety Instructions READ CAREFULLY AND KEEP FOR FUTURE REFERENCE Read this manual thoroughly before first use, even if you are familiar with this type of product. The safety precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly adhered to. Make sure you understand all instructions and warnings.
  • Page 6 General Safety Instructions (Cont.) • RCD: The installation of a residual current device (safety switch) is recommended to provide additional safety protection when using electrical appliances. It is advisable that a safety switch with a rated residual operating current not exceeding 30mA be installed in the electrical circuit supplying the appliance.
  • Page 7 General Safety Instructions (Cont.) • Airflow: Do not direct the airflow onto plants or animals, as long and direct exposure to cold air from the air conditioner could adversely affect them. • Cold air exposure: Never remain directly exposed to the flow of cold air for a long time, as direct and prolonged exposure to cold air from the air conditioner could be dangerous for your health.
  • Page 8 General Safety Instructions (Cont.) • Do NOT install/use the appliance in the following areas: – outdoors or where water is likely to splash – near a bath, shower, laundry basin or swimming pool – in an area where oil is likely to splash –...

  • Page 9: R290-Specific Safety Advice

    R290-Specific Safety Advice WARNING: Combustible & Dangerous This symbol alerts you to take care as the appliance contains a flammable refrigerant: R290 (propane). Take extra care when installing the unit and when carrying out maintenance. R290 is a colourless and odourless hydrocarbon gas. It is an efficient refrigerant with a low Global Warming Potential (GWP) and no potential for ozone depletion.
  • Page 10 R290-Specific Safety Advice (Cont.) • After servicing the appliance, the service technician must: – check that air cannot enter the refrigerant system – check for refrigerant leaks when moving the air conditioner – carry out a test cycle under controlled conditions after installing the unit and record the operating data.

  • Page 11: Getting Started

    Getting Started Before you start • Unpacking: This product has been packaged to protect it against transportation damage. Unpack the appliance and keep the original packaging materials in a safe place. It will help prevent any damage if the product needs to be transported in the future, and you can use it to store the appliance when it is not in use.

  • Page 12: Product Overview

    Product Overview Scope of delivery Portable air conditioner Louvre Control panel (see page 14 for details) Front panel Castor wheels Air inlet Drainage outlet Air outlet Power cord and plug Drainage outlet Front view (Fig. 3) Rear view (Fig. 4) AFTER SALES SUPPORT info@tempo.org 1300 886 649...
  • Page 13 Product Overview (Cont.) Accessory parts (Fig. 5) Flexible air exhaust hose Exhaust hose connector (window end) Exhaust hose connector (hous- ing adaptor) (air conditioner end) Remote control Adjustable window slider (for 67.5cm – 123cm windows) 2 Dowels 2 AAA-size batteries (packaged separately) NOTE: Due to continued product improvement, images and illustrations in this...
  • Page 14 Product Overview (Cont.) Control panel (Fig. 6) Temperature/ Timer display High fan speed Low fan speed AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: PA33W PRODUCT CODE: 703225 10/2020...
  • Page 15 Product Overview (Cont.) Remote control (Fig. 7) NOTE: Do not drop the remote control. Do not place the remote control in a location exposed to direct sunlight. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: PA33W PRODUCT CODE: 703225 10/2020...

  • Page 16: Installation

    Installation Installing the air exhaust hose • Fit the exhaust hose and Fig. 8 housing connectors to the ends of the flexible air exhaust hose, twisting them into place (Fig. 8). • Insert the fixing clip of the Fig. 9 housing connector into the openings at the back of the air conditioner (Fig.
  • Page 17 Installation (Cont.) Installing the window kit Your window kit has been designed to fit most standard ‘horizontal’ and ‘vertical’ window applications, but for certain types of windows it may be necessary for you to improvise/modify some aspects of the installation procedure.

  • Page 18: Instructions

    Instructions Using the portable air conditioner • Before switching the unit on for the first time, make sure you have properly installed the exhaust hose and window kit (see pages 7–10 and 16–17) and inserted two AAA size batteries into the remote control (see page 31). •...
  • Page 19 Instructions (Cont.) Cooling mode • Press the MODE button until the cooling mode indicator illuminates. • Press the DOWN (-) or UP (+) button repeatedly to set the desired room temperature between 16°C and 31°C. • Press the SPEED button to select the fan speed: high, medium or low. NOTE: For best cooling efficiency, make sure that: * Curtains/blinds are closed if your room is directly exposed to the sun.
  • Page 20 Instructions (Cont.) Timer operation The air conditioner has a 24 hour timer, which you can set to start the unit at a later time, or to switch off the unit automatically. On-Timer setting • With the unit switched off (but power supplied), press the TIMER button and then use the UP and DOWN buttons to select the number of hours after which you want the unit to turn on.

  • Page 21: Wi-Fi Control

    Wi-Fi network. • On your mobile device, tap on the [ STIRLING ] app (Fig. WF1). It will open and take you to the Login Page (Fig. WF2). Fig. WF1 Fig.
  • Page 22 Wi-Fi Control (Cont.) Before you log in, please tap [ Register ] and register your account using • your email account (Fig. WF3, WF4). • Once you enter your email address, tap [ Get Verification Code ] and an email will be sent directly to the email account that you entered when registering.
  • Page 23 Wi-Fi Control (Cont.) • On the air conditioner’s remote control (or control panel), press and hold the SPEED button for 5 seconds to reset the Wi-Fi module. • When the Wi-Fi indicator on the control panel is blinking rapidly (WF8), the Wi-Fi module is ready for configuration with your mobile phone.
  • Page 24 Wi-Fi Control (Cont.) • On completion (Fig. WF12), you can name your device. • Tap [ Done ] and you will return to the Device list page and your device will be shown. • Click on the device name and it will take you to the device’s main control page (Fig.
  • Page 25 Adding the STIRLING app to your Google Home app * • Open your Google Home app. (Before you can link your STIRLING App to your Google Home app you will have to have a Google Home account set up.) •...
  • Page 26 Wi-Fi Control (Cont.) Wi-Fi troubleshooting Problem Possible cause and solution Check and ensure you have internet reception and your mobile phone and the air conditioner are connected to the same Wi-Fi network. Check and ensure your Wi-Fi password is correct. During the set-up, the portable air Check and ensure that no firewalls or other...
  • Page 27 Wi-Fi Control (Cont.) Smartphone and Wi-Fi specification requirements Minimum smartphone specifications Android 5.0 version or later IOS 9.0 version or later Wireless network requirements of the Wi-Fi module Frequency band 2.412 GHz to 2.484 GHz Wi-Fi standard IEEE 802.11 b/g/n (channels 1 to 14) Data transmission rate 802.11b: 1, 2, 5.5 or 11 (Mbits/s) 802.11g: 6, 9, 12, 18, 24, 36, 48 or 54 (Mbits/s)

  • Page 28: Faqs & Troubleshooting Guide

    FAQs & Troubleshooting Guide If you experience problems with your portable air conditioner, or it appears not to be operating correctly, check the information below for solutions to common problems. If none of the solutions offered help you solve your problem, please contact our after sales support centre for advice.

  • Page 29: Other Useful Information

    Other Useful Information Care and cleaning Electric shock hazard! Before cleaning and servicing, ensure the unit is switched off and disconnected from the power outlet to prevent possible injury. Cleaning the air conditioner Wipe the housing with a damp cloth, moistened with water and a little mild detergent.
  • Page 30 Other Useful Information (Cont.) Before storage At the end of the summer season, follow the simple steps below before disconnecting and storing the appliance. • Place a pan under a water drainage outlet and remove the rubber stopper (Fig. 17). •...
  • Page 31 Other Useful Information (Cont.) Battery replacement The remote control is powered by 2x AAA size batteries, packaged separately. To install them, or to replace them when required, proceed as follows: • Open the cover to the battery compartment at the back of the remote control and insert 2 AAA batteries, making sure to match the polarity markings (+/-) on the batteries with those inside the compartment.
  • Page 32 Other Useful Information (Cont.) Technical specifications Model PA33W Cooling capacity 3.3kW Refrigerant, quantity R290, 226g Discharge 2.6MPa Permissible excessive operating pressure Suction 1.0MPa Discharge 3.2MPa Max. allowable pressure Suction 1.2MPa Weight 30kg Rated voltage 220-240V~ Rated frequency 50Hz Rated current 5.9A Rated input 1320W...
  • Page 33 This page has been left blank intentionally. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: PA33W PRODUCT CODE: 703225 10/2020...
  • Page 34 This page has been left blank intentionally. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: PA33W PRODUCT CODE: 703225 10/2020...

  • Page 35: Repair And Refurbished Goods Or Parts Notice

    Wi-Fi Portable Air Conditioner (3.3kW Cooling) Repair and Refurbished Goods or Parts Notice Unfortunately, from time to time, faulty products are manufactured which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of...
  • Page 36 Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product. Product does not work? If you encounter problems with this product, or if it fails to perform to your expectations, make sure to contact our After Sales Support Centre on 1300 886 649.
