- Page 1 Reverse Cycle Inverter Split System Air Conditioner Model Number STR-23RSJAIF INSTRUCTION MANUAL AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014...
-
Page 2: Table Of Contents
Contents Warranty Details Welcome General Safety Instructions Product Overview Getting Started Features Instructions Troubleshooting Guide Other Useful Information Repair and Refurbished Goods or Parts Notice AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014... -
Page 3: Warranty Details
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. YEARS IN HOME WARRANTY AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014... -
Page 4: Welcome
Welcome Congratulations on choosing to buy a STIRLING ® product. All products brought to you by STIRLING ® are manufactured to the highest standards of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive warranty. -
Page 5: General Safety Instructions
Grip the plug when disconnecting, do not pull the cord. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014... - Page 6 • Do not insert objects: Never insert a stick or similar object into the appliance. It could cause injury. • Maximise efficiency: Do not leave windows or doors open for long when the air conditioner is operating. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014...
- Page 7 Prolonged use of the unit in such conditions could cause fire or electrocution. Please refer to the Installation Manual for safety instructions specific to the installation of the indoor and outdoor units. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014...
-
Page 8: Product Overview
9 Airflow direction flaps 10 Remote control Fig. 2 Outdoor Unit No Part 11 Air outlet grille 12 Outdoor unit rating label 13 Cover 14 Gas valve 15 Liquid valve AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014... - Page 9 (in °C or °F) Timer Timer mode Unit working NOTE: The shape and position of switches and indicators may vary slightly according to the model, but their function is the same. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014...
-
Page 10: Remote Control
SWING the deflectors. the correct reception of each action. Increase the temperature or time by 1 unit. Switch on/off the LED display (if 12 DISPLAY present). AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014... -
Page 11: Remote Control Display
Every time you press a button, the unit SLEEP indicator confirms with a beep SUPER/TURBO indicator the correct reception of each action. ECO indicator BATTERY indicator CLOCK indicator Airflow swing indicator AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014... -
Page 12: Getting Started
If the remote control is programmed for COOLING mode, you will not be able to activate the heating function. To do this you need to take out the batteries and repeat the programming procedure for HEATING mode. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014... -
Page 13: Using The Remote Control
See ‘Inserting batteries’, page 13 for detailed instructions. NOTE: Only remove the batteries from the remote control when the air conditioner is not in operation. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014... -
Page 14: Getting Started
• The shape and position of the emergency button may vary according to the model, but its function is the same. • The external static pressure of the heat pump is 0Pa for all models. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014... -
Page 15: Features
However, ceiling sweep fans will help move warm/cool air back down to floor level in rooms with very high ceilings. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014... -
Page 16: Instructions
• DANGER! Never insert your hand or objects in the unit’s air outlet. It contains a fan that turns at high speed. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014... -
Page 17: Heating Mode
• If the remote control is programmed for COOLING mode, you will not be able to activate the heating function. To do this you need to take out the batteries and repeat the programming procedure for HEATING mode (see page 12). AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014... - Page 18 (with the ON/OFF button). • In case of a power failure or other disconnections from the power supply, you will have to reset your timer settings. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014...
-
Page 19: Sleep Mode
• In HEATING mode the set temperature is gradually decreased by 2°C during the first 2 hours. Fig. 21 • After running in SLEEP mode for 10 hours, the air Indoor display conditioner automatically switches off. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014... - Page 20 Ambient temp. Operation mode Auto temp. < 20°C Heating 23°C 20°C ~ 26°C Drying 18°C >26°C Cooling 23°C AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014...
-
Page 21: Troubleshooting Guide
• The remote control batteries are flat — insert new ones. • There are obstacles between the remote control and the signal receiver on the indoor unit — move the obstacles, see page 14. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014... - Page 22 Fault of the indoor pipe temperature sensor — set the temperature manually and call for service. Flashes 6 times Malfunction of the indoor fan motor — call for service. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014...
-
Page 23: Other Useful Information
• Clean and replace the filters. • On a sunny day let the conditioner work in ventilation for some hours, so that the inside of the unit can dry completely. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014... - Page 24 Never use harsh solvents or detergents. • If the battery of the outdoor unit is clogged by dust, leaves or other environmental debris, remove it with an air jet or a bit of water. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014...
-
Page 25: Repair And Refurbished Goods Or Parts Notice
Telephone: 1300 886 649 (Aust) - Fax: (02) 9975 2688 Tempo Help Desk: 1300 886 649 (Aust) (Operating Hours: Mon-Fri 08:30am to 06:00pm EST) Email: info@tempo.org YEARS IN HOME AFTER SALES SUPPORT WARRANTY 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014... - Page 26 This page has been left blank intentionally. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014...
- Page 27 This page has been left blank intentionally. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014...
- Page 28 If you encounter problems with this product, or if it fails to perform to your expectations, make sure to contact our After Sales Support Centre on 1300 886 649 before returning it to the store for a refund. AFTER SALES SUPPORT 1300 886 649 info@tempo.org MODEL:STR-23RSJAIF PRODUCT CODE:43512 10/2014...
