Summary of Contents for Stirling Black Edition STR-18R32WIFI
- Page 1 Reverse Cycle Inverter Split System Air Conditioner with Wi-Fi Model Number STR-18R32WIFI INSTALLATION MANUAL AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-18R32WIFI PRODUCT CODE : 11894 10/2019...
-
Page 2: Welcome
Welcome Congratulations on choosing to buy a STIRLING product. ® All products brought to you by STIRLING are manufactured to the highest ® standards of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive warranty. -
Page 3: Table Of Contents
Contents Welcome Warranty Details Installation Safety Instructions Product Overview Selecting the Installation Place Installation Information for the Installer Other Useful Information Repair and Refurbished Goods or Parts Notice AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-18R32WIFI PRODUCT CODE : 11894 10/2019... -
Page 4: Warranty Details
Reverse Cycle Inverter Split System Air Conditioner with Wi-Fi Warranty Details REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION The product is guaranteed to be free from defects in workmanship and parts for a period of 60 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion. -
Page 5: Installation Safety Instructions
Installation Safety Instructions PROTECT YOUR WARRANTY Do not try to install the Air Conditioner on your own; doing so will expose you to danger and void the warranty. These instructions for installation of the Reverse Cycle Inverter Air Conditioner are for use by an appropriately qualified, licensed installer. The appliance must be installed in accordance with national wiring regulations. - Page 6 Installation Safety Instructions (Cont.) Important safety precautions concerning refrigerant R32 WARNING: Combustible & Dangerous This symbol alerts you to take care as the appliance contains a flammable refrigerant: R32 (difluoromethane). Take extra care when installing the unit and when carrying out maintenance. The refrigerant used in this air conditioner, R32, is an odourless hydrocarbon gas with a high level of environmental compatibility, with significantly lower...
- Page 7 Installation Safety Instructions (Cont.) Maximum charge and minimum floor area = (4m ) x LFL = (26m ) x LFL = (130m ) x LFL Where LFL is the lower flammable limit in kg/m , the LFL for R32 is 0.306 kg/m <...
- Page 8 Installation Safety Instructions (Cont.) Site and operation safety • No open flames: The sites for installing and maintaining an air conditioner using refrigerant R32 should be free from open fires or welding, smoking, drying ovens or any other heat source higher than 548°C, which easily produces open fire.
- Page 9 Installation Safety Instructions (Cont.) Special tools required Tool Requirements for use It should be an explosion-proof vacuum pump that Mini vacuum pump can ensure certain precision and its vacuum degree should be lower than 10Pa. It should be a special explosion-proof filling device, Filling device have certain precision and its filling deviation should be less than 5g.
-
Page 10: Product Overview
Product Overview • This Reverse Cycle Inverter Air Conditioner is made up of an indoor and outdoor unit (Fig. 1 & 2), which are connected through properly insulated copper pipes (not supplied) and an electrical connecting cable. • The indoor unit is installed on a wall of the room to be air conditioned (it must not be installed in a laundry or similar room with high humidity levels). - Page 11 Product Overview (Cont.) (B) Outdoor unit: parts No Part 12 Outdoor unit rating label 13 Terminal block cover 14 Air outlet grille 15 Gas valve 16 Liquid valve Fig. 2 NOTE: The diagrams throughout this manual are for illustrative purposes only and may vary slightly from the appearance of the unit purchased.
- Page 12 Product Overview (Cont.) Installation hardware Fig. 3 (for illustrative purposes only, not to scale) (C) Installation hardware (D) Other inclusions Part (not pictured) 17 Power cable Remote control holder (for wall-mounting) 18 Copper nuts (x4) AAA Batteries (x2) 19 Drainage pipe Instruction and installation 20 Sealing colloid manuals...
-
Page 13: Selecting The Installation Place
Selecting the Installation Place PROTECT YOUR WARRANTY These instructions for installation of the Reverse Cycle Inverter Air Conditioner are for use by an appropriately qualified, licensed installer. The appliance must be installed in accordance with national wiring regulations. Do not try to install the Air Conditioner on your own; doing so will expose you to danger and void the warranty. - Page 14 Selecting the Installation Place (Cont.) Outdoor unit Fig. 5 • Do not install the unit: • Near sources of heat, steam or flammable gas. • Where it is exposed to high winds or excessive dust. • Where people often pass. •...
-
Page 15: Installation
STR-18R32 Outdoor Unit Picture Installation Installation of the indoor unit • Before starting installation, decide on the position of the indoor and outdoor units, taking into account the minimum space required around the units. • Install the indoor unit in the room to be air conditioned, avoid installation in corridors or communal areas. - Page 16 Installation (Cont.) Electrical connections for the indoor unit • Lift the front panel. Fig. 9 • Take off the cover, as indicated (Fig. 9), by Front panel removing a screw or breaking the hooks. • For the electrical connections, see the circuit Wiring diagram diagram on the right part of the unit under the front panel.
- Page 17 Installation (Cont.) Connecting the pipes • Do not remove the cap from the pipe until connecting it, to avoid dampness or dirt from entering. • If the pipe is bent or pulled too often, Fig. 11 it will become stiff. Do not bend it more than three times at one point.
- Page 18 Installation (Cont.) After having connected the pipe according to the instructions, install the connection cables, then the drain pipe (Fig. 14). After connection, lag the pipe, cables and drain pipe with the insulating material. • Arrange the pipes, cables and drain hose well. •...
- Page 19 Installation (Cont.) Installation of the outdoor unit • The outdoor unit should be installed on a solid wall, or on the ground, and fastened securely. • Before connecting pipes and cables, decide on the best position on the wall, leaving enough space for easy maintenance. •...
- Page 20 Installation (Cont.) Connecting the pipes Screw the flare nuts to the outdoor unit coupling with the same tightening procedures described for the indoor unit. To avoid leakage, pay attention to the following points: • Tighten the flare nuts using two Fig.
- Page 21 Installation (Cont.) Refrigerant pressure inspection The low pressure range of refrigerant R32 is 0.8–1.2MPa and the high pressure range is 3.2–3.7MPa. This means that the refrigerating system or refrigerant of an air conditioner is abnormal if the low or high pressure ranges of the detected compressor exceed the normal ranges.
- Page 22 Installation (Cont.) Final stage ind insulating covering around • W the joints of the indoor unit and fix it with insulating tape Insulating (Fig. 21). • Fix the exceeding part of the Piping signal cable to the piping or to Insulating the outdoor unit.
-
Page 23: Information For The Installer
Information for the Installer Wiring diagrams Indoor wiring diagram Outdoor wiring diagram AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-18R32WIFI PRODUCT CODE : 11894 10/2019... - Page 24 Information for the Installer (Cont.) Cable wire specifications Model / Capacity 5.1kW 1.5mm (min.) AWG16 Power Supply 1.5mm Cable (min.) AWG16 Sectional Area 1.5mm (min.) AWG16 1.5mm (min.) 1.5mm Connection (min.) Supply Cable 1.5mm Sectional Area 1.5mm 1.5mm (min.) Pipe details Inverter Air Conditioner Capacity 5.1kW Liquid pipe diameter...
- Page 25 Information for the Installer (Cont.) Technical specifications STR-18R32WIFI Model Number Cooling 5100W Capacity Heating 5100W Cooling 5.3A Current Heating 5.2A Cooling 10.3A Rated Current (AS/NZS 60335) Heating 10.2A Cooling 1190W Power Input Heating 1180W Cooling 2300W Rated Power Input (AS/NZS 60335) Heating 2250W Room size suitability...
-
Page 26: Other Useful Information
Other Useful Information Other Useful Information Compliance This product has been fully tested and meets all requirements as set out by standards AS/NZS 60335.1 and AS/NZS 60335.2.40 and also AS/NZS 3823.1.1 and AS/NZS 3823.2. The RCM Mark (Regulatory Compliance Mark) indicates that the product complies with the relevant guidelines of the ACMA as well as corresponding government requirements for the safety of electrical devices. -
Page 27: Repair And Refurbished Goods Or Parts Notice
Reverse Cycle Inverter Split System Air Conditioner with Wi-Fi Repair and Refurbished Goods or Parts Notice Unfortunately, from time to time, faulty products are manufactured which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of... - Page 28 Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product. Product does not work? If you encounter problems with this product, or if it fails to perform to your expectations, make sure to contact our After Sales Support Centre on 1300 886 649.
