ACU-RITE 01607BPDI Instruction Manual

Weather center
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CONTENTS
Unpacking Instructions................2
Package Contents.......................2
Product Registration....................2
Setup ........................................6
3-in-1 Sensor Setup....................6
Display Unit Setup......................7
Clock ......................8
®
Set Time, Date & Units ................8
Backlight Settings .......................8
Questions?
(877) 221-1252 or visit www.AcuRite.com.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Placement Guidelines .................9
Troubleshooting........................13
Care & Maintenance ................15
Calibration ..............................15
FCC Information.......................17
Customer Support ....................18
Warranty.................................18
Contact Customer Support at
Instruction Manual
Weather Center
model 01607BPDI
Battery......16
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 01607BPDI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ACU-RITE 01607BPDI

Summary of Contents for ACU-RITE 01607BPDI

  • Page 1: Table Of Contents

    Instruction Manual Weather Center model 01607BPDI CONTENTS Placement Guidelines ....9 Unpacking Instructions....2 3-in-1 Sensor Installation ..10 Package Contents.......2 Using the Weather Center ..11 Product Registration....2 Troubleshooting......13 Features & Benefits: 3-in-1 ..3 Care & Maintenance ....15 Features & Benefits: Display ..4 Calibration ......15...

  • Page 2: Unpacking Instructions

    Congratulations on your new AcuRite product. To ensure the best possible product performance, please read this manual in its entirety and retain it for future reference. Unpacking Instructions Remove the protective film that is applied to the LCD screen prior to using this product.

  • Page 3: Features & Benefits: 3-In-1

    Features & Benefits 3-in-1 SENSOR 5. Mounting Hardware Includes anchors and screws. 1. Temperature & Humidity Sensors Diameter Length (internal) 1” 2. Release Lever for Battery Access #6 or #8 1/4” or 3/8” 3. Mounting Point 6. Mounting Bracket 4. Wind Speed Anemometer 7.

  • Page 4: Features & Benefits: Display

    Features & Benefits 13 12...
  • Page 5 DISPLAY UNIT FRONT 17. 12 to 24 Hour Weather Forecast 1. Average Wind Speed Self-Calibrating Forecasting pulls data Based on all wind speed readings from your sensor to generate your from the past 2 minutes. personal forecast. 2. Current Wind Speed 18.

  • Page 6: Setup

    SETUP 3-IN-1 Sensor Setup 1. Press the release lever and pull Set the A-B-C Switch off the lower housing of the The A-B-C switch is located inside sensor. the battery compartment. It can be 2. Remove the battery compartment set to A, B or C. However, you must cover.

  • Page 7: Display Unit Setup

    Display Unit Setup Set the A-B-C Switch 2. Insert 3 x AA alkaline batteries into the battery compartment, Locate the A-B-C switch inside as shown. Follow the polarity the battery compartment. Set (+/–) diagram in the battery the A-B-C switch to A, B or C. compartment.

  • Page 8: Intelli-Time ® Clock

    Intelli-Time Clock ® Intelli-Time products are pre-programmed with the correct time and date. Intelli- Time technology instructs the time and date to set themselves. All you need to do is select your Time Zone and Daylight Saving Time preferences. The clock will then automatically set itself and change for Daylight Saving Time.

  • Page 9: Placement Guidelines

    AUTO DIM MODE: Automatically adjusts display brightness based on time of day & year. MARCH 11- NOVEMBER 4 6:00 a.m. - 9:00 p.m. = 100% brightness 9:01 p.m. - 5:59 a.m.= 30% brightness NOVEMBER 5 - MARCH 10 7:30 a.m. - 7:00 p.m.= 100% brightness 7:01 p.m.

  • Page 10: 3-In-1 Sensor Installation

    LOCATE AWAY FROM WIND OBSTRUCTIONS DO NOT mount the sensor with obstructions around it. Consider a location that is a wide open area, with few structures around to ensure accurate wind speed measurement. Visit us online to view installation photos and video, or learn more about AcuRite technology: View Video www.AcuRite.com/3in1...

  • Page 11: Using The Weather Center

    OPERATION Using The Weather Center Learning Mode Self-Calibrating Forecasting use a unique algorithm to analyze changes in pressure over a time period (called Learning Mode) to determine your altitude. After 14 days, the Learning Mode icon disappears from the display screen. At this point, the self-calibrated pressure is tuned in to your location and the unit is ready for superior weather prediction.
  • Page 12 Moon Phase Track the phases of the moon, conveyed through simple lunar phase icons: WAXING FULL WANING CRESCENT QUARTER QUARTER CRESCENT Wind Speed The Wind Speed area of the display features the CURRENT speed, as well as the AVERAGE and PEAK wind speeds. AVERAGE wind speeds are based on all wind speed readings from the last 2 minutes.

  • Page 13: Troubleshooting

    Troubleshooting Problem Possible Solution • Relocate the display unit and/or the 3-in-1 sensor. The units must be within 330 ft (100 m) of each other. • Make sure both units are placed at least 3 feet (.9 m) away from electronics that may interfere with the wireless communication (such as TVs, microwaves, computers, etc).
  • Page 14 Troubleshooting Problem Possible Solution • Make sure both the display unit and 3-in-1 sensor are placed away from any heat sources or vents (see page 9). • Make sure both units are positioned away from moisture Inaccurate sources (see page 9). temperature or •...

  • Page 15: Care & Maintenance

    Care & Maintenance Display Unit Care Clean with a soft, damp cloth. Do not use caustic cleaners or abrasives. Keep away from dust, dirt and moisture. Clean ventilation ports regularly with a gentle puff of air. 3-in-1 Sensor Care Clean the Sensor Clean with a soft, damp cloth.

  • Page 16: Replace Intelli-Time ® Battery

    *To change from AUTO to MANUAL pressure mode and vice versa, press AND HOLD the “ ” button for at least 10 seconds. The display indicates the current pressure mode selected,“AUTO” or “MANUAL”. After 20 seconds of inactivity, the display will save the adjustments and exit calibration mode.

  • Page 17: Specifications

    Specifications Outdoor: -40ºF to 158ºF; -40ºC to 70ºC TEMPERATURE RANGE Indoor: 32ºF to 122ºF; 0ºC to 50ºC Outdoor: 1% to 99% HUMIDITY RANGE Indoor: 1% to 99% 0 to 99 mph; 0 to 159 kph WIND SPEED 330 ft / 100 m depending on home construction materials WIRELESS RANGE 433 mhz OPERATING FREQUENCY...

  • Page 18: Customer Support

    Customer Support AcuRite customer support is committed to providing you with best-in-class service. For assistance, please have the model number of this product available and contact us in any of the following ways: (877) 221-1252 info@chaney-inst.com AcuRite 24/7 support at www. .com Installation Videos Register your Product...
  • Page 20 Weather Temperature Weather Kitchen Clocks Stations & Humidity Alert Radio Thermometers & Timers It’s more than accurate, it’s AcuRite offers an extensive assortment of precision instruments, designed to provide you with information you can depend on to Plan your day with confidence ™...
