ACU-RITE 01033W Instruction Manual

Weather forecaster
Hide thumbs
Table of Contents

Advertisement

Quick Links

CONTENTS
Package Contents .................. 2
Product Registration ............... 2
Setup .................................... 5
Sensor Setup ......................... 5
Display Setup ........................ 6
Clock .................. 6
®
Questions?
(877) 221-1252 or visit www.AcuRite.com.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Weather Forecaster
Placement Guidelines ............. 7
Using the Forecaster............... 8
Troubleshooting ..................... 9
Care & Maintenance .............10
Specifications ........................ 11
FCC Information ................... 11
Customer Support .................12
Warranty..............................12
Contact Customer Support at
Instruction Manual
model 01033W
battery ..10
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 01033W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ACU-RITE 01033W

Summary of Contents for ACU-RITE 01033W

  • Page 1: Table Of Contents

    Instruction Manual Weather Forecaster model 01033W CONTENTS Unpacking Instructions ... 2 Placement Guidelines ..... 7 Package Contents ....2 Using the Forecaster....8 Product Registration ....2 Troubleshooting ..... 9 Features & Benefits: Sensor ..2 Care & Maintenance .....10 Features &...

  • Page 2: Unpacking Instructions

    Congratulations on your new AcuRite product. To ensure the best possible product performance, please read this manual in its entirety and retain it for future reference. Unpacking Instructions Remove the protective film that is applied to the LCD screen prior to using this product.

  • Page 3: Features & Benefits: Display

    Features & Benefits DISPLAY UNIT FRONT 8. Current Outdoor Humidity 1. Current Indoor Temperature 2. Low/High Temperature Records 9. Low/High Temperature Records Lowest and highest indoor Lowest and highest outdoor temperature recorded since temperature recorded since midnight. midnight. 10. Current Outdoor Temperature 3.
  • Page 4 DISPLAY UNIT BACK 6. Display Unit Stand 1. ”+” Button For setup preferences. 7. Battery Compartment 2. “SET” Button 8. RESET Button For setup preferences. Full reset to factory defaults. 3. ” ” Button 9. Intelli-Time Battery Compartment ® For setup preferences. 10.

  • Page 5: Setup

    SETUP Sensor Setup Set the A-B-C Switch conditions. Cold temperatures can cause alkaline batteries The A-B-C switch is located inside to function improperly. Use the battery compartment. It can lithium batteries in the sensor for be set to A, B or C. However, temperatures below -4ºF / -20ºC.

  • Page 6: Display Setup

    Install or Replace Batteries Display Unit 1. Slide off the battery compartment cover. 2. Insert 3 x AA alkaline batteries into the battery compartment, as shown. Follow the polarity (+/-) diagram in the battery compartment. 3. Replace the battery cover. Intelli-Time Clock ®...

  • Page 7: Placement Guidelines

    Placement for Maximum Accuracy AcuRite sensors are sensitive to surrounding environmental conditions. Proper placement of both the display unit and outdoor sensor are critical to the accuracy and performance of this product. Display Unit Placement Place the display unit in a dry area free of dirt and dust. Display unit stands upright for tabletop use or is wall-mountable.

  • Page 8: Using The Forecaster

    OPERATION Using the Weather Forecaster Learning Mode Self-Calibrating Forecasting uses a unique algorithm to analyze changes in pressure over a time period (called Learning Mode) to determine your altitude. After 14 days, the Learning Mode icon disappears from the display screen. At this point, the self-calibrated pressure is tuned in to your location and the unit is ready for superior weather prediction.

  • Page 9: Troubleshooting

    Troubleshooting If the wireless signal indicator shows no bars: • Relocate the display unit and/or the outdoor sensor. The units must be within 330 ft (100 m) of each other. • Make sure both units are placed at least 3 feet No outdoor sensor (.9 m) away from electronics that may interfere with the wireless communication (such as TVs, microwaves,...

  • Page 10: Care & Maintenance

    Care & Maintenance Display Unit Care Clean with a soft, damp cloth. Do not use caustic cleaners or abrasives. Keep away from dust, dirt and moisture. Clean ventilation ports regularly with a gentle puff of air. Outdoor Sensor Care Clean with a soft damp cloth. Do not use caustic cleaners or abrasives. Replace Intelli-Time Battery Intelli-Time technology CR2032...

  • Page 11: Specifications

    Specifications TEMPERATURE RANGE Outdoor: -40ºF to 158ºF; -40ºC to 70ºC Indoor: 32ºF to 122ºF; 0ºC to 50ºC WIRELESS RANGE 330 ft / 100 m depending on home construction materials OPERATING FREQUENCY 433 MHz POWER Display: 3 x AA alkaline batteries Sensor: 2 x AA alkaline or lithium batteries DATA REPORTING Outdoor Data: 16 second updates...

  • Page 12: Customer Support

    Customer Support AcuRite customer support is committed to providing you with best-in- class service. For assistance, please have the model number of this product available and contact us in any of the following ways: (877) 221-1252 info@chaney-inst.com AcuRite 24/7 support at www. .com Installation Videos Register your Product...
  • Page 16 Weather Temperature Weather Kitchen Clocks Stations & Humidity Alert Radio Thermometers & Timers It’s more than accurate, it’s AcuRite offers an extensive assortment of precision instruments, designed to provide you with information you can depend on to Plan your day with confidence ™...
