ACU-RITE 01525 Instruction Manual

ACU-RITE 01525 Instruction Manual

Professional weather center
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CONTENTS
Package Contents .................. 2
Product Registration ............... 2
Features: Display ................... 4
Back of Display...................... 6
Setup .................................... 7
5-in-1 Sensor Setup ................ 7
Display Setup ........................ 8
Set the Time & Date ............... 9
Measurement Units ...............10
Set Language .......................10
Placement Guidelines ............ 11
Questions?
(844) 228-5465 or visit www.AcuRite.com.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Professional Weather Center
AcuRite Connect ...................13
Weather Underground ..........13
Weather Ticker .....................16
Programmable Alarms...........18
Troubleshooting ................... 20
Care & Maintenance............ 23
Calibration .......................... 23
Specifications....................... 25
FCC Information .................. 25
Customer Support ................ 26
Warranty............................. 26
Contact Customer Support at
Instruction Manual
model 01525

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 01525 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ACU-RITE 01525

Summary of Contents for ACU-RITE 01525

  • Page 1: Table Of Contents

    Instruction Manual Professional Weather Center model 01525 CONTENTS Unpacking Instructions ... 2 5-in-1 Sensor Installation..12 Package Contents ....2 AcuRite Connect ....13 Product Registration ....2 Weather Underground ..13 Features & Benefits: 5-in-1..3 Using the Weather Center ..15 Features: Display ....4 Weather Ticker .....16...

  • Page 2: Unpacking Instructions

    Congratulations on your new AcuRite product. To ensure the best possible product performance, please read this manual in its entirety and retain it for future reference. Unpacking Instructions Remove the protective film that is applied to the LCD screen prior to using this product.

  • Page 3: Features & Benefits: 5-In-1

    Features & Benefits 5-IN-1 SENSOR 1. Rainfall Collector Funnel 5. Temperature & Humidity Sensors (internal) 2. Solar Cell Panel Converts sunlight into power to run 6. Mounting Point internal aspirating fan. 7. Wind Speed Anemometer Internal Aspirating Fan (not shown) 8.

  • Page 4: Features: Display

    Features & Benefits Display 3738 39 40...
  • Page 5 1. Peak Wind Speed 19. All-Time Records Button Press for all-time low and date Highest speed from past 60 minutes. recorded for current category 2. Average Wind Speed selected on display (#33). Press Of all speeds from past 2 minutes. twice for all-time high and date 3.

  • Page 6: Back Of Display

    Back of Display BACK OF DISPLAY 6. Clear All Clears all recorded data without 1. Integrated Hang Hole having to reset time and date for easy wall mounting Reset 2. Plug-in for USB Cable Full reset to factory defaults 3. Plug-in for Power Adapter 8.

  • Page 7: Setup

    SETUP 5-in-1 Sensor Setup Set the A-B-C Switch cause alkaline batteries to function improperly. Use lithium batteries in Locate the A-B-C switch inside the the 5-in-1 sensor for temperatures battery compartment. Set the A-B-C below -4ºF / -20ºC. switch to A, B or C. You must select 1.

  • Page 8: Display Setup

    Display Setup The display operates with batteries and/or power adapter. Regardless of the power source, it is recommended that batteries always be installed to ensure continuous operation (and retain records) in case of a power outage. Set the A-B-C Switch Insert 6 x AA alkaline batteries into the battery compartment, The A-B-C switch is located inside...

  • Page 9: Set The Time & Date

    Set the Time & Date The clock and calendar are utilized to time stamp history records and other data, so it is important to set the time and date soon after you power on the display. Set the Time 1. Press the "▲” or “▼” buttons until “SET CLOCK?”...

  • Page 10: Measurement Units

    Select Measurement Units To select between standard units (mph, ºF, etc.) or metric units (kph, ºC, etc.): 1. Press the “▲” or “▼” buttons until “SET UNITS?” is displayed on the Selectable Category part of the display. 2. Press the “ ”...

  • Page 11: Placement Guidelines

    Placement for Maximum Accuracy AcuRite sensors are sensitive to surrounding environmental conditions. Proper placement of both the display and the sensor are critical to the accuracy and performance of this product. Display Placement Place the display in a dry area free of dirt and dust. To ensure accurate temperature measurement, place out of direct sunlight and away from heat sources or vents.

  • Page 12: 5-In-1 Sensor Installation

    5-in-1 Sensor Installation Guidelines INSTALLATION HEIGHT Mount the sensor at least 5 feet (1.5 meters) off the ground in an open area. Higher is better for wind measurement- the National Weather Service recommends 33 feet (10 meters) high! MOUNTING OPTIONS The included mounting bracket is designed to screw directly onto wooden posts or surfaces that are 2”x 4”...

  • Page 13: Acurite Connect

    AcuRite Connect AcuRite Connect works with Windows PC’s to provide access to your Weather Center data in the following ways:  Data File: Display logs (or stores) data so that you can download it to a PC in a data file (CSV, or comma-separated values file).  Web Browser or Smartphone: Monitor sensor data remotely using AcuRite’s free AcuRite online software, or from a mobile device using the free AcuRite app, available from the iOS App Store or Google Play Store.
  • Page 14 After AcuRite Connect is installed on the computer, the initial configuration will begin automatically. When selecting where to save weather data downloaded from the display, a folder named “AcuRite Weather Station” will be created on the computer. (PC) When prompted by the software to plug in the display, connect the USB (larger end of the cable) into a USB port on the computer.

  • Page 15: Using The Weather Center

    OPERATION Using the Professional Weather Center Learning Mode Self-Calibrating Forecasting use a unique algorithm to analyze changes in pressure over a time period (called Learning Mode) to determine your altitude. After 14 days, the Learning Mode icon disappears from the display screen. At this point, the self-calibrated pressure is tuned in to your location and the unit is ready for superior weather prediction.

  • Page 16: Weather Ticker

    Weather Ticker ™ The Weather Ticker automatically streams your real-time weather information and alerts as scrolling text in the lower part of the display screen. You can manually cycle through all the available messages by pressing “ ”. Default WEATHER TICKER messages are pre-loaded as follows: 12 to 24 hour future weather forecast FORECAST Current moon phase...
  • Page 17 Customize Weather Ticker Messages Customize which messages you want to scroll across the WEATHER TICKER: 1. Press the “ ” button to manually cycle through each message available. 2. During the MANUAL REVIEW: PRESS the “ ” button to activate the current scrolling message.

  • Page 18: Programmable Alarms

    Programmable Weather Alarms Each Selectable Weather Category features an alarm option. When an alarm sounds, the display emits audible beeping and flashes the affected category, its alarm settings, and any other relevant data. Some alarms can be customized to alert you when your programmed value is reached.
  • Page 19 ICON DEFINITIONS = Alarm On = Alarm Off = Adjust Mode = Low Value = High Value BUTTON FUNCTIONS Silence a Sounding Alarm Press to activate or The alarm sounds initially for a few minutes, deactivate an alarm. then silences itself. The alarm then sounds every Press and hold to set few minutes afterwards until one of the or adjust an alarm...

  • Page 20: Troubleshooting

    Troubleshooting Problem Possible Solution • Relocate the display and/or the 5-in-1 sensor. The units must be within 330 ft (100 m) of each other. • Make sure both units are placed at least 3 feet (.9 m) away from electronics that may interfere with the wireless communication (such as TVs, microwaves, computers, etc).
  • Page 21 Troubleshooting Problem Possible Solution • Make sure both the display and 5-in-1 sensor are placed away from any heat sources or vents (see page 11). Inaccurate • Make sure both units are positioned away from moisture sources (see page 11). temperature or humidity •...
  • Page 22 Troubleshooting Problem Possible Solution • Verify that the status in the AcuRite Connect software on your PC indicates that the data was received from the display. • Verify that you created an account or logged into an existing account at www.acu-link.com or in the AcuRite app, and that you input the display’s MAC ADDRESS as a part of the account setup.

  • Page 23: Care & Maintenance

    Care & Maintenance Display Care Clean with a soft, damp cloth. Do not use caustic cleaners or abrasives. Keep away from dust, dirt and moisture. Clean ventilation ports regularly with a gentle puff of air. 5-in-1 Sensor Care Clean the Sensor Clean with a soft damp cloth.
  • Page 24 “▲” or “▼” 3. Press the buttons to calibrate the data value higher or lower from the actual reading. 4. Press the “ ” button to confirm the calibration adjustment. Note: The “ ” icon remains illuminated next to calibrated values.

  • Page 25: Specifications

    Specifications TEMPERATURE RANGE Outdoor: -40ºF to 158ºF; -40ºC to 70ºC Indoor: 32ºF to 122ºF; 0ºC to 50ºC HUMIDITY RANGE Outdoor: 1% to 99% Indoor: 16% to 98% WIND SPEED 0 to 99 mph; 0 to 159 kph WIND DIRECTION 16 points INDICATORS RAINFALL 0 to 99.99 in;...

  • Page 26: Customer Support

    Customer Support AcuRite customer support is committed to providing you with best-in- class service. For assistance, please have the model number of this product available and contact us in any of the following ways: (844) 228-5465 info@chaney-inst.com AcuRite 24/7 support at www. .com Installation Videos Register your Product...
  • Page 28 ©Chaney Instrument Co. All rights reserved. AcuRite is a registered trademark of the Chaney Instrument Co., Lake Geneva, WI 53147. All other trademarks and copy- rights are the property of their respective owners. AcuRite uses patented technology. Printed in China 01525 INST 082615 Visit www.AcuRite.com/patents for details.
