Instruction Manual
Rain Gauge Station
model 01608 / 06042M
Rain Gauge Installation .........10
Placement Guidelines ............ 11
Programmable Rain Alarm.....12
Rainfall Tracking ...................12
Troubleshooting ....................14
Care & Maintenance.............15
Calibration ...........................15
Specifications........................18
FCC Information ...................18
Customer Support .................19
Warranty..............................19
Battery ..17
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ACU-RITE 01608
Summary of Contents for ACU-RITE 01608
-
Page 1: Table Of Contents
Instruction Manual Rain Gauge Station model 01608 / 06042M outdoor TODAYALL-TIME heat index point today’s rainfall inches all time records last year this year this week yesterday indoor TODAYALL-TIME pressure STORM! CONTENTS Unpacking Instructions ... 2 Rain Gauge Installation ..10 Package Contents .... -
Page 2: Unpacking Instructions
Congratulations on your new AcuRite product. To ensure the best possible product performance, please read this manual in its entirety and retain it for future reference. Unpacking Instructions Remove the protective film that is applied to the LCD screen prior to using this product. -
Page 3: Features & Benefits: Display
Features & Benefits outdoor TODAYALL-TIME heat index point today’s rainfall inches all time records last year this year this week yesterday indoor TODAYALL-TIME pressure STORM! DISPLAY FRONT Current Outdoor Temperature 11. Intelli-Time Clock ® Arrow icon indicates the direction Automatically updates itself for Daylight temperature is trending. - Page 4 Features & Benefits DISPLAY BACK 1. Integrated Hang Hole 5. Battery Compartment Cover For easy wall mounting. 6. A-B-C Switch Button ID code that must match the wire- For setup preferences and less sensor and rain gauge’s A-B-C viewing today’s HIGH temperature switches to ensure units synchronize.
-
Page 5: Features & Benefits: Rain Gauge
Features & Benefits SQUEEZE A B C RAIN GAUGE 3. Battery Compartment & 1. Rain Gauge Cover Electronics Box 2. Rain Gauge Tipping Cups 4. Rain Gauge Base Collects and empties rain for continuous rain measurement. 5. A-B-C Switch ID code that must match display’s A-B-C switch to ensure units synchronize. -
Page 6: Setup
SETUP Sensor Setup Set the A-B-C Switch conditions. Cold temperatures can cause alkaline batteries The A-B-C switch is located inside to function improperly. Use the battery compartment. It can lithium batteries in the sensor for be set to A, B or C. However, temperatures below -4ºF / -20ºC. -
Page 7: Rain Gauge Setup
Rain Gauge Setup Install or Replace Batteries AcuRite recommends high quality alkaline batteries for the best product performance. Heavy duty or rechargeable batteries are not recommended. SQUEEZE SQUEEZE LARGE LARGE SQUEEZE SQUEEZE TABS TO OPEN 1. Separate rain gauge cover from the base by gently squeezing tabs and pulling the cover upwards. -
Page 8: Display Setup
Display Setup Set the A-B-C Switch Install or Replace Batteries Locate the A-B-C switch inside 1. Remove the battery the battery compartment. Set compartment cover. the A-B-C switch to A, B or C. 2. Insert 3 x AAA alkaline You must select the same letter batteries into the battery choices for the display, wireless compartment, as shown. -
Page 9: Intelli-Time ® Clock
Intelli-Time Clock ® Intelli-Time products are pre-programmed with the correct time and date. Intelli-Time technology instructs the time and date to set themselves. All you need to do is select your Time Zone and Daylight Saving Time preferences. The clock will then automatically set itself and change for Daylight Saving Time. Set the Time, Date &... -
Page 10: Rain Gauge Installation
Rain Gauge Installation • To ensure accurate rain measurement, the rain gauge MUST be placed on a flat, level surface. • Ensure the rain gauge is not placed in a low spot that could become flooded or in an area where there are obstructions above it. 1. -
Page 12: Programmable Rain Alarm
OPERATION Programmable Rain Alarm Set a Daily Rain Alarm: When the rain alarm sounds, the display emits an audible alert and flashes the rainfall total. The alarm can be customized to notify you when your programmed value is reached. The alarm automatically resets at 12:00am midnight every day. 1) Press and release the ”SET”... - Page 13 Rainfall History today’s rainfall today’s rainfall today’s rainfall inches inches inches all time records all time records all time records last year this year this week yesterday last year this year this week yesterday last year this year this week yesterday indoor PREVIOUS DAY...
-
Page 14: Troubleshooting
Troubleshooting Problem Possible Solution If the wireless signal indicator shows no bars: • Relocate the display and/or the wireless sensor. The units must be within 330 ft (100 m) of each other. • Relocate the display and/or the rain gauge. The units must be within 100 ft (30 m) of each other. -
Page 15: Care & Maintenance
Care & Maintenance Display Care Clean with a soft, damp cloth. Do not use caustic cleaners or abrasives. Keep away from dust, dirt and moisture. Clean ventilation ports regularly with a gentle puff of air. Wireless Sensor Care Clean with a soft damp cloth. Do not use caustic cleaners or abrasives. Rain Gauge Care Clean with a soft damp cloth. - Page 16 After 20 seconds of inactivity, the display will save the adjustments and exit calibration mode. Calibrations will be erased if the display is reset or if the batteries are NOTE: removed. Calibrate the Rain Gauge The rain gauge can be calibrated to improve accuracy. Items Needed: rain gauge, display, plastic cup, pin, screw driver 1.
-
Page 17: Replace Intelli-Time ® Battery
Replace Intelli-Time Clock Battery Intelli-Time technology is powered by a pre-installed coin-cell battery that stores the time and date settings. The battery has a shelf life of several years. Time and date will need to be entered after replacing Intelli-Time battery. To replace the Intelli-Time battery: 1. -
Page 18: Specifications
Specifications Outdoor: -40ºF to 158ºF; -40ºC to 70ºC TEMPERATURE RANGE Indoor: -4ºF to 122ºF; -20ºC to 50ºC 1% to 99% RH HUMIDITY RANGE 0.01 inches (0.25 mm) and up RAINFALL MEASUREMENT Wireless Sensor: 330 ft/100 m depending on home WIRELESS RANGE construction materials Rain Gauge: 100 ft/30 m depending on home construction materials... - Page 20 ©Chaney Instrument Co. All rights reserved. AcuRite is a registered trademark of the Chaney Instrument Co., Lake Geneva, WI 53147. All other trademarks and copy- rights are the property of their respective owners. AcuRite uses patented technology. Printed in China 01608/06042M INST 031516 Visit www.AcuRite.com/patents for details.
