- Page 1 Product Parts Information Second Generation Liftchain Industrial Air Hoist Models LC2A015S and LC2A030D (Dwg. MHP2659) Save These Instructions Form MHD56297 Edition 1 October 2004 71441307 © 2004 Ingersoll-Rand Company...
-
Page 2: Table Of Contents
Maintenance Information Manual Form MHD56279. Manuals can be downloaded from www.airwinch.com The use of other than genuine Ingersoll-Rand parts may result in a hazard, decreased performance and increased maintenance and may void all warranties. The original language of this manual is English. -
Page 3: Parts Ordering Information
Return Goods Policy replace those that have been subjected to wear. Ingersoll-Rand will not accept any returned goods for warranty or service unless The use of other than genuine Ingersoll-Rand replacement parts may result in prior arrangements have been made and written authorization has been provided decreased hoist performance, and may, at the company’s option, to invalidate the... -
Page 4: Powerhead And Brake Assembly Drawing
POWERHEAD AND BRAKE ASSEMBLY DRAWING 1.5 and 3 ton Hoist Capacities (Dwg. MHP2650) Form MHD56297 Edition 1... -
Page 5: Powerhead And Brake Assembly Parts List
POWERHEAD AND BRAKE ASSEMBLY PARTS LIST Item Description Total Part Item Description Total Part of Part Number of Part Number Plug 65110441 Washer 45001106 Retainer Ring 47703080 Hoist Body 96443069 Exhaust Washer 96443190 Oil Seal 58019830 Capscrew 41332506 Bearing 50050002 Reduction Gear End Cover 96443008 Bearing... -
Page 6: Motor Without Emergency Stop Assembly Drawing And Parts List
MOTOR WITHOUT EMERGENCY STOP ASSEMBLY DRAWING AND PARTS LIST (Dwg. MHP2652) Item Description Total Part Item Description Total Part of Part Number of Part Number Capscrew 41201604 Drive Gear ** 76441256 Ball 69401625 Exhaust Washer 96441145 ‘O’ Ring 58209229 46001116 Brake Reaction Plate 96441015 Motor Cover... -
Page 7: Emergency Stop Pendant Adapter Assembly Drawing And Parts List
EMERGENCY STOP PENDANT ADAPTER ASSEMBLY DRAWING AND PARTS LIST (Dwg. MHP2654) Item Description Total Part Item Description Total Part of Part Number of Part Number Ball 69401625 Washer 45701004 Capscrew 41301106 Diaphragm 96441097 ‘O’ Ring 58237429 ‘O’ Ring 58222329 Gasket 96441188 Plunger 96360017... -
Page 8: Remote Two Lever Pendant Assembly Drawing
REMOTE TWO LEVER PENDANT ASSEMBLY DRAWING (Dwg. MHP2666) Form MHD56297 Edition 1... -
Page 9: Remote Two Lever Pendant Assembly Parts List
REMOTE TWO LEVER PENDANT ASSEMBLY PARTS LIST Item Description Total Part Item Description Total Part of Parts Number of Parts Number Pendant Assembly PHS2E Hose ** As req’d 50923 Exhaust Washer 67600303 Fitting, Adapter 51029 Spring 69128541 Fitting, Nipple 68237528 Ball 69401625 Capscrew... -
Page 10: Remote Emergency Stop Pendant Assembly Drawings
REMOTE EMERGENCY STOP TWO LEVER PENDANT ASSEMBLY DRAWING (Dwg. MHP2655) Form MHD56297 Edition 1... -
Page 11: Remote Emergency Stop Pendant Parts List
REMOTE EMERGENCY STOP TWO LEVER PENDANT ASSEMBLY PARTS LIST Item Description Total Part Item Description Total Part of Parts Number of Parts Number Pendant Assembly PHS2E-U Label Kit *** 95790111 Exhaust Washer 67600303 Hose ** As req’d 50923 Spring 69128541 Fitting, Adapter 51029 Ball... -
Page 12: Top Hook Assembly Drawing And Parts List
TOP HOOK ASSEMBLY DRAWING AND PARTS LIST (Dwg. MHP2656) Part Item Description Total Number of Part 1.5 ton 3 ton Top Hook Assembly 76443124 76443125 Capscrew 41201604 Washer 45001106 Hook 94248356 94248357 Hook Latch Kit 94240364 94240365 Hook Support 96443034 96443035 96443244 96443245... -
Page 13: Bottom Block Hook Assembly Drawing And Parts List
BOTTOM BLOCK HOOK ASSEMBLY DRAWING AND PARTS LIST (Dwg. MHP2657) Single Fall Hoist Part Number Item Description Total of Part 1.5 ton Standard Option ‘R’ Hook 94248358 94240294 Hook Latch Kit 94240364 Limit Stop Washer 96443150 Retainer Wire 96090148 Ring 96090025 96090146 Half Hook Block... -
Page 14: Hoist Chain Container Assembly Drawing And Parts List
HOIST CHAIN CONTAINER ASSEMBLY DRAWING AND PARTS LIST (Dwg. MHP2658) Item Description Total Part Item Description Total Part of Part Number of Part Number Chain Container Assembly 76443147 Frame 94240139 Washer 45001106 Plate (Bottom) 94240161 75583M Chain Container 94240317 51720M8 Washer 45301010 Capscrew... - Page 15 ROPE CONTROL ASSEMBLY DRAWING AND PARTS LIST (Dwg. MHP2662) Item Description Total Part Item Description Total Part of Part Number of Part Number Rope Control Assembly * Screw 42008307 Spring 69128541 43707611 Ball 69401625 Adjustment Screw 96443177 ‘O’ Ring 58209229 Capscrew 41321506 51720M8...
- Page 16 ROPE CONTROL WITH EMERGENCY STOP ASSEMBLY DRAWING AND PARTS LIST (Dwg. MHP2663) Item Description Total Part Item Description Total Part of Part Number of Part Number Rope Control Assembly * 76443179 Bushing 59008826 Washer 45001106 Retainer 47837241 Spring 69128541 Gear 96441088 Ball 69401625...
- Page 17 SERVICE NOTES Form MHD56297 Edition 1...
- Page 18 SERVICE NOTES Form MHD56297 Edition 1...
-
Page 19: Warranty
WARRANTY Ingersoll-Rand Company (I-R) warrants to the original user its Hoists and Winches I-R makes no other warranty, and all implied warranties including any warranty (Products) to be free of defects in material and workmanship for a period of one year of merchantability or fitness for a particular purpose are limited to the duration from the date of purchase. - Page 20 www.airwinch.com...
