- Page 1 Product Information Liftchain Mining Air Hoist Models LC2A015SM, LC2A030DM, LC2A040SM, LC2A060SM, LC2A080DM, and LC2A120DM (Dwg. MHP2684) Save These Instructions Form MHD56307 Edition 2 January 2011 71455802 2011 Ingersoll-Rand Company ©...
-
Page 2: Product Description
Only allow trained technicians to perform maintenance on this product. For additional information contact factory or nearest Ingersoll Rand Ingersoll Rand Distributor. For additional supporting documentation refer to Table 1 ‘Product Information Manuals’ on page 2. Manuals can be downloaded from www.ingersollrandproducts.com. The use of other than genuine Ingersoll Rand replacement parts may result in safety hazards, decreased performance and increased maintenance and will invalidate all warranties. -
Page 3: Specifications
SPECIFICATIONS Model Code Explanation Example: LC2A015SMP3C3M2T1-E LC2A015S Liftchain Air Hoist Capacity and Chain Falls = 1500 kg (3,300 lbs), single fall LC2A015S LC2A030D = 3000 kg (6,600 lbs), two fall LC2A040S = 4000 kg (8,800 lbs), single fall LC2A060S = 6000 kg (13,200 lbs), single fall LC2A080D = 8000 kg (17,600 lbs), two fall LC2A120D... -
Page 4: Capacity Information
Table 2: Specifications Sound Air Inlet Weight of Chain Unit Net Weight with Chain Size Pressure Minimum Headroom Size per meter of lift Standard 10 ft (3 m) Lift Level * Rated Capacity Load Hoist Model metric tons Chain Falls dB(A) LC2A015S 90.4... -
Page 5: Operation
Overload protection is adjusted at the factory to 120% of the safe working load (SWL). Air Line Filter It is also able to operate on both sides for mining versions with two bottom hooks. Refer to the “MAINTENANCE” section in Product Maintenance Information Manual for Place the strainer/filter as close as practical to the motor air inlet port, but upstream adjustment procedures. -
Page 6: Frequent Inspection
9. Hook Latch. Make sure hook latch is present and not damaged. Replace if n Frequent Inspection necessary. CAUTION On equipment in continuous service, a ‘Daily Inspection’ should be made by the operator at the beginning of each shift and a ‘Quarterly Inspection’ (90 days) should •... -
Page 7: Air Line Lubricator
1. Lubricate each link of load chain weekly, or more frequently, depending on n Hook Assemblies severity of service. 2. In corrosive environments, lubricate more frequently than normal. 3. Lubricate each link of the load chain and apply new lubricant over existing layer. Hoist top and bottom hooks are supported by thrust bearings. -
Page 8: Product Information Graphics
PRODUCT INFORMATION GRAPHICS Air Control Liftchain Pneumatic Valve Hoist Torque Limiter Liftchain Hoist P=5 to 7 bar (Up) (Down) P=5 to 7 bar (Down) (Up) PHS2E E-Stop PHS2E-RU Motor View Motor View A (UP) (UP) C (Air (Down) Supply) C (Air (Stop) (Down) (On) - Page 9 PRODUCT INFORMATION GRAPHICS CONTINUED (Dwg. MHP0111) (Dwg. MHP0102) (Dwg. MHP1299) (Dwg. MHP1300) Function Levers (Dwg. MHP1649) Throat Width (Dwg. MHP0040) Form MHD56307 Edition 2...
- Page 10 PRODUCT INFORMATION GRAPHICS CONTINUED Single Hook Lifting or Pulling Applications (3 ton shown) Double Hook Reversible Pulling Applications (3 ton shown (Dwg. MHP3066) Old Style 1.5 and 3 ton Note: For double fall/double hook units, pull only 50% of maximum hoist capacity with free end hook (Dwg.
