Fluidics; Electronics And Computer - SYSMEX CyFlow Space Operating Manual

Optical Coupling
Excitation Optics
NOTICE
Information on the optical configuration of a specific instrument is
displayed in the optical layout scheme of an instrument which can be
found in the individual instruments documentation.

12.3 Fluidics

Flow Cuvette
Sample Delivery
Sampling Volume
Flow Rates
Fluidics Volume
Biosafety System

12.4 Electronics and Computer

Electronics
™
CyFlow Space | Operating Manual | March 2021
Standard objective
numerical aperture
Elliptical 15 µm x 60 µm at 488 nm
Synthetic quartz flow cuvette (350x 200
µm) for laminar sample transport with
sheath fluid for fluorescence, forward and
side scatter light detection
Computer controlled precision syringe
pump for contamination-free
transport.
Built-in air pressure for sheath fluid. Sheath
fluid pressure is adjustable from 0-300
mbar (Computer
setting: 200 mBar.
Continuous up to 1000 µl
200 µl for precision absolute counting
Free sampling volume
counting method
1) Sample volume
continuously between 0 and 20 µl/s
2) Sheath fluid pressure continuously
adjustable
2 x 2-litre reservoirs for sheath fluid and
waste
Avoids sample droplets and sample cross
contamination
Parallel real-time signal processing for
each of the optical channels with selectable
linear, 3- or 4-decade
amplification (6-decade log amplifiers),
pulse height, area and width analysis for
doublet discrimination, 16 bit analogue-to-
digital converters, trigger on any parameter
or all parameters
mount with high
sample
controlled). Default
with syringe
speed adjustable
logarithmic
