Vive
Vive Wireless Hub
The Vive hub provides a connection point for Lutron
Vive devices such as PowPak wireless dimming and
switching modules, Pico remote controls, Radio
Powr Savr occupancy sensors, and daylight
sensors. For a complete list of compatible devices,
see the last page of this document.
For more information on the Vive hub, including
training materials, design information and software
updates, please visit www.lutron.com/vive
Features
• Can be easily programmed with any Wi-Fi enabled
device by using the free Lutron web-based software.
• Communicates with controls on a floor using Lutron
wireless Clear Connect technology.
• Distributed system architecture.
– Wireless sensors and controls must be located
within 9 m of the associated device.
• Supports timeclock events based on both sunrise
and sunset or fixed time-of-day.
• Timeclock events can control individual devices,
areas, or groups of areas.
• Uses Lutron RF signal strength measurements
to find devices nearby for quick association and
programming without having to climb ladders.
• Dashboard of current status for control and
monitoring of the system. Also shows current
energy usage.
• Integrated multi-color LED provides feedback on
what mode the hub is in.
• Connects directly to any smartphone, tablet or
computer using built in Wi-Fi. 2.4 GHz 802.11b / g
using WPA2 Security.
• Ethernet 10 / 100 Mbps connection for:
– Native BACnetR / IP (see Lutron P/N 369996 at
www.lutron.com for PIC Statement) integration
into Building Management Systems
(HMS-2-XX only). The Vive Hub has been
tested by BACnetR Testing Laboratories (BTL)
and is certified to comply with all necessary
interoperability requirements.
S P E C I F I C AT I O N S U B M I T TA L
®
Job Name:
Job Number:
HMS-0, HMS-1, HMS-2
Model Numbers:
Vive Hub
– Network multiple Vive hubs together as an
independent system or as part of an existing
building network.
– Native OpenADRR support, to manage Automatic
Demand Response / Load Shed events dictated
by a utility company.
– Each Vive hub hosts a unique virtual BACnet
network. As such, each Vive hub requires a
unique BACnet network number.
®
• Firmware upgradable for future features and
security patches.
• Password protected access.
• Supported on most devices that use an HTML5
compliant browser (iOS
Mac ).
®
• Required browsers are Google
• Supports HTTPS.
• Recommended configurations for smart devices:
Device
iPhone 6, iPhone 6 plus or newer
Supported on most Android
running Android 6.0 or later.
®
• Daylighting Setpoint Tweaking – If the lights are too
bright or too dim while using daylighting, adjust the
settings in real time from a smart device to alter
the setpoint for the light level that is maintained
between natural and electric light.
Wireless Hub
3691044-04g 1 03.23.21
Vive Hub Dashboard
, Android , Windows
®
® ®
Chrome and Safari
® ®
OS Version
iOS 11 or later
®
devices Android 6.0 or later
® ®
