Jeep 2008 Liberty Owner's Manual
Hide thumbs
Also See for 2008 Liberty:
- Installation instructions manual (6 pages) ,
- Owner's manual (487 pages)
Table of Contents
Advertisement
Quick Links
SECTION
1
INTRODUCTION
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE
4
INSTRUMENT PANEL AND CONTROLS
5
STARTING AND OPERATING
6
WHAT TO DO IN EMERGENCIES
7
MAINTAINING YOUR VEHICLE
8
MAINTENANCE SCHEDULES
9
IF YOU NEED CONSUMER ASSISTANCE
10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 469
INDEX
TABLE OF CONTENTS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .383
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 395
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 451
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .459
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
PAGE
1
2
3
4
5
6
7
8
9
10
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Jeep 2008 Liberty
Summary of Contents for Jeep 2008 Liberty
-
Page 1: Introduction
TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE... -
Page 3: Table Of Contents
CONTENTS Introduction ......4 Rollover Warning ......4 How To Use This Manual . -
Page 4: Introduction
4 INTRODUCTION INTRODUCTION This manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your new vehicle. It is supplemented by a Warranty Information Booklet and various customer oriented documents. You are urged to read these publications carefully. -
Page 5: How To Use This Manual
Rollover Warning Label Failure to use driver and passenger seat belts provided is a major cause of severe or fatal injury. In fact, the U.S. government notes that the universal use of existing seat belts could cut the highway death toll by 10,000 or more each year, and could reduce disabling injuries by 2 million annually. - Page 6 6 INTRODUCTION...
-
Page 7: Warnings And Cautions
INTRODUCTION 7 WARNINGS AND CAUTIONS This manual contains WARNINGS against operating procedures, which could result in an accident or bodily injury. It also contains CAUTIONS against procedures, which could result in damage to your vehicle. If you do not read this entire manual, you may miss important information. -
Page 8: Vehicle Modifications / Alterations
8 INTRODUCTION VEHICLE MODIFICATIONS / ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death. -
Page 9: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Ignition Key Removal ....12 Key-In-Ignition Reminder . - Page 10 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Unlatch The Liftgate Flip-Up Window ..24 Using The Panic Alarm ....24 Programming Additional Transmitters .
- Page 11 Driver And Front Passenger Supplemental Restraint System (SRS) - Airbag ... .52 Child Restraint ......69 Engine Break-In Recommendations .
-
Page 12: Things To Know Before Starting Your Vehicle
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS You can insert the double-sided keys into the locks with either side up. Vehicle Key The dealer that sold you your new vehicle has the key code numbers for your vehicle locks. These numbers can be used to order duplicate keys from your dealer. - Page 13 Ignition Key Positions Manual Transmission — If Equipped Turn the key to the ACC position and then push the key and cylinder inward slightly and rotate the key to the LOCK position. Then remove the key. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 NOTE: •...
-
Page 14: Key-In-Ignition Reminder
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Never leave children alone in a vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons. A child or others could be seri- ously or fatally injured. Don’t leave the key in the ignition. - Page 15 the vehicle. The system will shut the engine off in two (2) seconds if someone uses an invalid key to start the engine. NOTE: A key, which has not been programmed, is also considered an invalid key even if it is cut to fit the ignition switch lock cylinder for that vehicle.
-
Page 16: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Replacement Keys NOTE: Only keys that are programmed to the vehicle electronics can be used to start and operate the vehicle. Once a Sentry Key is programmed to a vehicle, it cannot be programmed to any other vehicle. -
Page 17: General Information
addition, the Vehicle Security Alarm Indicator Light will begin to flash. Turn the ignition switch to the “LOCK” position and remove the second key. 4. Insert a blank Sentry Key into the ignition switch. Turn the ignition switch to the “ON” position within 60 seconds. -
Page 18: Steering Wheel Lock - If Equipped
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE STEERING WHEEL LOCK — IF EQUIPPED Your vehicle may be equipped with a passive steering wheel lock (manual transmission only). This lock pre- vents steering the vehicle without the ignition key. If the steering wheel is moved a half turn in either direction and the key is not in the ignition, the steering wheel will lock. -
Page 19: Rearming Of The System
Rearming of the System: If something triggers the alarm, and no action is taken to disarm it, the system will turn off the horn after 3 minutes, turn off all of the visual signals after 15 minutes, and then the system will rearm itself. To Arm the System: 1. -
Page 20: Tamper Alert
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Security Alarm System is designed to protect your vehicle; however, you can create conditions where the system will give you a false alarm. If the previously described arming sequence has occurred, the system will arm regardless of whether you are inside or outside the vehicle. -
Page 21: To Unlock The Doors And Liftgate
NOTE: Inserting the key into the ignition switch dis- ables all buttons on the transmitter. Vehicle Key To Unlock the Doors and Liftgate: Press and release the Unlock button on the transmitter once to unlock the driver’s door, or twice to unlock all doors and the liftgate. -
Page 22: Illuminated Approach - If Equipped
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Test the feature from outside the vehicle by pressing the Lock and Unlock buttons on the transmitter. 4. Repeat these steps if you want to return this feature to its previous setting. NOTE: Pressing the Lock button on the transmitter while you are inside the vehicle will activate the Security Alarm. - Page 23 • For vehicles not equipped with the EVIC, perform the following steps: 1. Press the Lock button on a programmed (i.e. func- tional) transmitter for at least 4 seconds, but no longer than 10 seconds. Then, press the Panic button while still holding the Lock button.
-
Page 24: To Unlatch The Liftgate Flip-Up Window
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Release both buttons at the same time. 3. Test the feature from outside the vehicle by pressing the Lock and Unlock buttons on the transmitter. 4. Repeat these steps if you want to return this feature to its previous setting. -
Page 25: Programming Additional Transmitters
headlights and turn signal lights will flash, the horn will pulse on and off, and the illuminated entry system will turn on. The panic alarm will stay on for 3 minutes unless you turn it off by pressing the Panic button a second time or if the vehicle speed is 5 mph (8 km/h) or greater. -
Page 26: General Information
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. With the transmitter buttons facing down, use a flat blade tool to pry the two halves of the transmitter case apart. Make sure not to damage the seal during removal. Separating Case Halves 3. -
Page 27: Remote Starting System - If Equipped
NOTE: Changes or modifications not expressly ap- proved by the party responsible for compliance could void the user’s authority to operate the equipment. If your Keyless Entry Transmitter fails to operate from a normal distance, check for these two conditions. 1. -
Page 28: How To Use Remote Start
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How To Use Remote Start All of the following conditions must be met before the engine will remote start: • Gear selector lever in “P” (Park). • Doors closed. • Hood closed. •... -
Page 29: Door Locks
To Exit Remote Start Mode & Drive the Vehicle Before the end of the 15-minute cycle, press and release the Unlock button on the RKE transmitter to unlock the doors and disarm the Vehicle Security Alarm (if equipped). Then, insert the key into the ignition switch and turn the switch to the ON position. - Page 30 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If the door lock plunger is down when you shut the door, the door will lock. Therefore, make sure the keys are not inside the vehicle before closing the door. NOTE: The manual door locks will not lock or unlock the liftgate.
-
Page 31: Power Door Locks
Power Door Locks A power door lock switch is on each front door trim panel. Use this switch to lock or unlock the doors and liftgate. Power Door Lock Switch If you press the power door lock switch while the key is in the ignition, and any front door is open, the power THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 locks will not operate. -
Page 32: Automatic Unlock Doors On Exit
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Door Locks Programming The Automatic Door Locks feature can be enabled or disabled as follows: • For vehicles equipped with the Electronic Vehicle Information Center (EVIC), refer to “Personal Settings (Customer Programmable Features)” under “Elec- tronic Vehicle Information Center (EVIC)”... -
Page 33: Child-Protection Door Lock System (Rear Doors)
5. The doors were not previously unlocked. 6. The vehicle speed is 0 mph (0 km/h). Automatic Unlock Doors on Exit Programming The Automatic Unlock Doors On Exit feature can be enabled or disabled as follows: • For vehicles equipped with the Electronic Vehicle Information Center (EVIC), refer to “Personal Settings (Customer Programmable Features)”... - Page 34 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Insert the tip of the ignition key into the child lock control and rotate it to the lock position. Inserting Ignition Key 3. Repeat Steps 1 and 2 on the opposite rear door. NOTE: When the child lock system is engaged, the door can be opened only by using the outside door handle even though the inside door lock is in the unlocked...
- Page 35 • For emergency exit with the system engaged, move the lock plunger up (unlocked position), roll down the window, and open the door with the outside door handle. To Disengage the Child Protection Door Lock 1. Open the rear door. 2.
-
Page 36: Windows
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WINDOWS Power Windows The window controls on the driver’s door trim panel control all the door windows. Power Window Switches There are single window controls on each passenger door trim panel, which operate the passenger door windows. The window controls will operate when the ignition switch is in the ON or ACC position. - Page 37 To open the window part way, press the window switch to the first detent and release it when you want the window to stop. To stop the window from going all the way down during the auto-down operation, pull up on the switch briefly. For vehicles not equipped with the Electronic Vehicle Information Center (EVIC), the power window switches will remain active for 45 seconds after the ignition switch...
- Page 38 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE will remain active for 45 seconds after the ignition switch is turned to the LOCK position. Opening either front door will cancel this feature. For vehicles equipped with the EVIC, the power window switches will remain active for up to 10 minutes after the ignition switch is turned to the LOCK position.
-
Page 39: Wind Buffeting
Window Lockout Switch Reset It may be necessary at some point in time to reactivate the auto-up feature. To do so, perform the following procedure: 1. Pull the window switch up to close window com- pletely and continue to hold the switch up for an additional two seconds after the window is closed. -
Page 40: Liftgate
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LIFTGATE To open the liftgate, pull up (squeeze) on the handle and lift. Liftgate Release NOTE: Use the power door lock switch on either front door trim panel or the Remote Keyless Entry (RKE) transmitter to lock and unlock the liftgate. -
Page 41: Occupant Restraints
OCCUPANT RESTRAINTS Some of the most important safety features in your vehicle are the restraint systems. These include the front and rear seat belts for the driver and all passengers, front airbags for both the driver and front passenger, and side curtain airbags for the driver and passengers seated next to a window. -
Page 42: Lap/Shoulder Belts
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE inside of the vehicle. Everyone in a motor vehicle should be belted at all times to reduce or prevent injuries. Lap/Shoulder Belts All seating positions in your vehicle have combination lap/shoulder belts. The belt webbing retractor is de- signed to lock during very sudden stops or collisions. - Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the seat. 2. The seat belt latch plate is above the back of your seat. Grasp the latch plate and pull out the belt. Slide the latch plate up the webbing as far as necessary to make the belt go around your lap.
- Page 44 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Latch Plate To Buckle WARNING! • A belt that is buckled into the wrong buckle will not protect you properly.
- Page 45 4. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap belt portion, pull up a bit on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt. A snug belt reduces the risk of sliding under the belt in a collision.
- Page 46 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button on the buckle. The belt will automatically retract to its stowed position. If necessary, slide the latch plate down the webbing to allow the belt to retract fully. WARNING! A frayed or torn belt could rip apart in a collision and leave you with no protection.
-
Page 47: Lap/Shoulder Belt Untwisting Procedure
As a guide, if you are shorter than average, you will prefer a lower position, and if you are taller than average, you will prefer a higher position. When you release the anchorage, try to move it up and down to make sure that it is locked in position. -
Page 48: Enhanced Seat Belt Use Reminder System (Beltalert)
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Enhanced Seat Belt Use Reminder System (BeltAlert) If the driver’s or front passenger’s seat belt has not been buckled within 60 seconds of starting the vehicle, and if the vehicle speed is greater than 5 mph (8 km/h), the Enhanced Warning System (BeltAlert) will alert the driver or front passenger to buckle their seat belt. -
Page 49: Automatic Locking Mode - If Equipped
3. Within 60 seconds of turning the ignition switch to the ON position, unbuckle and then re-buckle the driver’s seat belt at least three times within 10 seconds, ending with the seat belt buckled. NOTE: Watch for the Seat Belt Reminder Light to turn on while unbuckling the seat belt and turn off while re-buckling the seat belt. -
Page 50: How To Disengage The Automatic Locking Mode
50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How to Disengage The Automatic Locking Mode Disconnect the combination lap/shoulder belt from the buckle and allow it to retract completely to disengage the automatic locking mode and activate the vehicle sensitive (emergency) locking mode. -
Page 51: Seat Belt Extender
Keep the belt low so that it does not come across the abdomen. That way the strong bones of the hips will take the force if there is a collision. Seat Belt Extender If a seat belt is too short, even when fully extended, and when the adjustable upper shoulder belt anchorage (if so equipped) is in its lowest position, your authorized dealer can provide you with a seat belt extender. -
Page 52: Driver And Front Passenger Supplemental
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Driver and Front Passenger Supplemental Restraint System (SRS) - Airbag This vehicle has airbags for both the driver and front passenger as a supplement to the seat belt restraint systems. The driver’s airbag is mounted in the steering wheel. - Page 53 The front airbags have a multistage inflator design. This may allow the airbag to have different rates of inflation that are based on collision severity and occupant size. The front passenger airbag is also certified to the Federal regulations that define Occupant Classification (refer to information on Occupant Classification System in this section).
- Page 54 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Do not put anything on or around the front and side curtain airbag covers or attempt to manually open them. You may damage the airbags and you could be injured because the airbags are no longer functional. These protective covers for the airbag cushions are designed to open only when the airbags are inflating.
- Page 55 classified in a category other than that of an adult (refer to information on Occupant Classification System in this section). This could be a child, teenager, or even a small size adult. Here are some simple steps you can take to minimize the risk of harm from a deploying airbag.
- Page 56 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Do not lean against the door or window, airbags will inflate forcefully into the space between you and the door. 5. If the airbag system in this vehicle needs to be modified to accommodate a disabled person, contact the Customer Center.
- Page 57 Airbag System Components The airbag system consists of the following: • Occupant Restraint Controller (ORC) • Airbag Warning Light • Driver Airbag • Front Passenger Airbag • Side Curtain Airbags above Side Windows • Side Remote Acceleration Sensors • Steering Wheel and Column •...
- Page 58 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The ORC also monitors the readiness of the electronic parts of the system whenever the ignition switch is in the START or ON position. These include all of the items listed above except the Passenger Airbag Disable (PAD) Indicator Light, the instrument panel, and the steering wheel and column.
- Page 59 NOTE: Children 12 years and under should always ride buckled up in a rear seat in an appropriate child restraint. • The Passenger Airbag Disable (PAD) Indicator Light (an amber light located in the center of the instrument panel) tells the driver and front passenger when the front passenger airbag is turned off.
- Page 60 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE is turned off and it will not inflate. If the “PAD Indicator Light” is not illuminated, DO NOT assume the airbag is turned off and move the child restraint to the rear seat. A deploying passenger airbag can cause death or serious injury to a child in a rear facing infant seat.
- Page 61 will cause the system to turn the airbag on. In this case, the OCS has classified the occupant of the seat as an adult. An adult occupant needs to sit in a normal position (with their feet on or near the floor) in order to be properly classified.
- Page 62 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE lodged under the seat and interferes with operation of the weight sensors, a fault will occur which turns on both the “PAD Indicator Light” and the “Airbag Warning Light.” Once the lodged object is removed, the fault will be automatically cleared after a short period of time.
- Page 63 • The Side Impact SRS Side Curtain Airbags are de- signed to activate only in certain side collisions and rollover events. When the ORC detects a collision requiring the side curtain airbag to inflate, it signals the inflators on the crash side of the vehicle or both sides of the vehicle for a rollover event.
-
Page 64: If A Deployment Occurs
64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Unapproved modifications or service procedures to the front passenger seat assembly or its related com- ponents may inadvertently change the airbag deploy- ment in case of a frontal crash. This could result in death or serious injury to the front seat passenger if the vehicle is involved in an accident. - Page 65 • As the airbags deflate, you may see some smoke-like particles. The particles are a normal by-product of the process that generates the nontoxic gas used for airbag inflation. These airborne particles may irritate the skin, eyes, nose, or throat. If you have skin or eye irritation, rinse the area with cool water.
-
Page 66: Maintaining Your Airbag System
66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Turns on the interior lights, which remain on as long as the battery has power or until the ignition key is removed. • Unlocks the doors automatically. NOTE: The interior lights can only be deactivated if the key is removed from the ignition switch or the vehicle is driven. - Page 67 NOTE: Perchlorate Material – special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate Airbag Warning Light You will want to have the airbag system ready to inflate for your protection in an impact. The airbag system is designed to be maintenance free. If any of the following occurs, have an authorized dealer service the system promptly: •...
- Page 68 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE In conjunction with other data gathered during a com- plete accident investigation, the electronic data may be used by DaimlerChrysler Corporation and others to learn more about the possible causes of crashes and associated injuries in order to assess and improve vehicle perfor- mance.
-
Page 69: Child Restraint
Data Parameters that May Be Recorded: • Diagnostic trouble code(s) and warning light status for electronically controlled safety systems, including the airbag system • Airbag disable light status (if equipped) • Time of airbag deployment (in terms of ignition cycles and vehicle mileage) •... - Page 70 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! In a collision, an unrestrained child, even a tiny baby, can become a missile inside the vehicle. The force required to hold even an infant on your lap can become so great that you could not hold the child, no matter how strong you are.
- Page 71 “LATCH — Child Seat Anchorage System (Lower Anchors and Tether for CHildren)” in this section. • Rearward-facing child seats must NEVER be used in the front seat of a vehicle with the front passenger airbag unless the airbag is turned off. An airbag deployment could cause severe injury or death to infants in this position.
- Page 72 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Check belt fit periodically. A child’s squirming or slouching can move the belt out of position. • If the shoulder belt contacts the face or neck, move the child closer to the center of the vehicle. Never allow a child to put the shoulder belt under an arm or behind their back.
- Page 73 Here are some tips on getting the most out of your child restraint: • Before buying any restraint system, make sure that it has a label certifying that it meets all applicable Safety Standards. The manufacturer also recommends that you try a child restraint in the vehicle seats where you will use it before you buy it.
- Page 74 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE connection to the top tether anchorages have been avail- able for some time. For some older child restraints, many child restraint manufacturers offer add-on tether strap kits or retrofit kits. You are urged to take advantage of all the available attachments provided with your child re- straint in any vehicle.
- Page 75 The rear seat lower anchorages are round bars, located at the rear of the seat cushion where it meets the seat back, and are just visible when you lean into the rear seat to install the child restraint. You will easily feel them if you run your finger along the intersection of the seatback and seat cushion surfaces.
-
Page 76: Installing Child Restraints Using The Vehicle Seat Belt
76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE means of adjusting the tension in the strap. Forward- facing toddler restraints and some rear-facing infant restraints will also be equipped with a tether strap, a hook for attachment to the tether strap anchorage and a means of adjusting the tension of the strap. - Page 77 belt. However, any seat belt system may loosen with time, so check the belt occasionally, and pull it tight if necessary. If the seat belt has an automatic locking retractor, pull the belt from the retractor until there is enough to allow you to pass through the child restraint and slide the latch plate into the buckle.
-
Page 78: Transporting Pets
78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To attach a child restraint tether strap: Route the tether strap over the seat back and attach the hook to the tether anchor located on the back of the seat. For the outboard seating positions, route the tether underneath the headrest and attach the hook to the tether anchor located on the back of the seat. -
Page 79: Engine Break-In Recommendations
ENGINE BREAK-IN RECOMMENDATIONS A long break-in period is not required for the engine in your new vehicle. Drive moderately during the first 300 miles (500 km). After the initial 60 miles (100 km), speeds up to 50 or 55 mph (80 or 90 km/h) are desirable. While cruising, brief full-throttle acceleration, within the limits of local traffic laws, contributes to a good break-in. -
Page 80: Lock Your Vehicle
80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and seat belts. -
Page 81: Safety Checks You Should Make Inside The
inspect the exhaust system each time the vehicle is raised for lubrication or oil change. Replace as required. WARNING! • Exhaust gases can injure or kill. They contain carbon monoxide (CO) which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. -
Page 82: Periodic Safety Checks You Should Make Outside The Vehicle
82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Defroster Check operation by selecting the defrost mode and place the blower control on high speed. You should be able to feel the air directed against the windshield. See your authorized dealer for service if your defroster is inoper- able. -
Page 83: Understanding The Features Of Your Vehicle
