Spacetronik SPE-O112BB Installation Manual

Model: SPE-O112BB
Accessory List
Attention: The drawings below are only for reference which might be slightly different from the actual object, please in kind prevail. Any tools missing
or installation problems, please contact the customer service firstly.
B C
A
X3
x8
x4
ST4.2 M6
M6
Part List
Qty Qty
No. Part No. Part No.
1 2 1 3
1
Tabletop Lifting column
4 2 5 1 6
Feet Power plug
4
7
Cable
mounts
Installation guide
Technical Data
Column Number
50KG
Maximum Load
25mm/s
Max Speed
100-240V
Input Voltage
730mm
Lowest Position
1230mm
Highest Position
1200mm(length)
Desktop Size
600mm(width)
Continuous operation for 2 mins at most after
Duty Cyde
pause for 18 mins
0~4 0°C
Applicable Temperature
D
x1
4x4 5x5
(With cross)
Installation Instruction
1
Qty
Part
1
Right Column
1
2
Adaptor
4
STEP1
B
x4
D
4x4
Long side of
the column
2
Short side of
the desktop
STEP2
C
x8
D
4x4
STEP3
A
x2
D
5x5
3
5
6
7
Install the lifting column
3
Rotate the column after
inserting it to the bottom
to avoid height difference
2
1
Install the lifting column (2)(3) to the tabletop(1),
then tighten the screws (B) with allen key (D)
Install the feet
4
2
Connect liting columns(2)(3) to the feet, tighten
screw(C) with allen key(D)
Install the hand switch
D
Hand switch
A
Fix the hand switch with the screw (A)and tighten it with 5*5 wrench (D)
1 2
Insert
Insert the hexagon of the column
Rotate the column after inserting
head along the guide groove it, making the screws on the
supporting beam into the column slot
3 4
D
B
Screws
Tighten the screws (B) with 4*4 allen key
D
C
3
