INTRODUCTION

SYSTEM COMPONENTS
THE LINK UP GATEWAY CONCEPT
The Link Up Pyrometer gateway (hereinafter "Device" or
"Link Up") provide an easy method to provide the exhaust
temperature to NMEA 2000.
Easily installed, the LinkUp gateway replaces the original
wiring, delivering power to both the LinkUp device and
sensor from the NMEA 2000 backbone while still being
compliant with the NMEA 2000 certification
requirements.
The data are then available for being displayed on any
OceanLink, AcquaLink, or more in general on any glass
cockpit NMEA 2000 display device.
1x Link Up gateway

B 000423
1x Pyrometer sensor

N 03-320-264
Configuring LinkUp gateways is simple using a mobile
device and the companion LinkUp Configurator App for
Android or iOS.
Each device has a built-in passive NFC antenna, so the
parameters of the sensor are wirelessly configured to type,
instance and warning threshold on the mobile device
which is then "tapped" against the LinkUp device for
instant data download.
INTRODUCTION
1x 6m extension cable
B000632
1x Safety Instructions
B000100
