- Page 1 LINK UP GATEWAY PYROMETER INSTRUCTIONS MANUAL rev. AA B000942...
-
Page 2: Table Of Contents
CONTENT CONTENT Introduction Safety Information System installation Configuration Technical data... -
Page 3: Introduction
THE LINK UP GATEWAY CONCEPT The Link Up Pyrometer gateway (hereinafter “Device” or Configuring LinkUp gateways is simple using a mobile “Link Up”) provide an easy method to provide the exhaust device and the companion LinkUp Configurator App for temperature to NMEA 2000. - Page 4 INTRODUCTION DESIGN AND FUNCTION The Link Up gateway has a simple but yet effective design. The pyrometer sensor serves to monitor accurately the temperature in the elbow flange of the exhaust pipe and The housing filled with bi-component resin allows the unit indicates eventual thermal overload of the engine.
-
Page 5: Safety Information
SAFETY INFORMATION SAFETY INFORMATION WARNING • No smoking! No open fire or heat sources! • • The product was developed, manufactured and To prevent personal injury, property damage or inspected according to the basic safety requirements environmental damage, basic knowledge of motor of EC Guidelines and state-of-the-art technology. - Page 6 SAFETY INFORMATION • • When working underneath the vehicle, secure it Use only the multimeter or diode test lamps provided, according to the specifications from the vehicle to measure voltages and currents in the manufacturer. vehicle/machine or boat. Use of conventional test •...
-
Page 7: System Installation
SYSTEM INSTALLATION SYSTEM INSTALLATION WARNING Before beginning, disconnect the negative terminal on the battery, otherwise you risk a short circuit. If the vehicle is supplied by auxiliary batteries, you must also disconnect the negative terminals on these batteries! Short circuits can cause fires, battery explosions and damages to other electronic systems. Please note that when you disconnect the battery, all volatile electronic memories lose their input values and must be reprogrammed. - Page 8 SYSTEM INSTALLATION PYROMETER SENSOR INSTALLATION Connect the Pyrometer sensor to the extension cable as indicated in the picture making sure to follow the connections table below. WARNING • Do not shorten measuring leads. Coil if necessary. Sensor Cable A (red) ...
- Page 9 SYSTEM INSTALLATION Mount the bushing centrically and weld on. WARNING • The weld must form a tight seal. • Always follow the safety instructions and advice of the welding equipment manufacturer. Slide the heat-shrinkable sleeve over the cable connections and then heat with a hot-air fan over the entire length until it shrinks.
- Page 10 SYSTEM INSTALLATION LINK UP CONNECTION Connect the Link Up sensor-side plug to the 6 m extension The 6 m extension cable B000632 is designed with the cable B000632 to interface the pyrometer sensor. mating AMP SuperSeal connector for a plug-and-play installation.
- Page 11 Please ensure to tighten the M12 connector by screwing it onto its counterpart, so to preserve the water tightness. A drop cable is not needed unless the total length of the Link Up device is not enough to reach the NMEA 2000® backbone. In this case it is possible to extend the total length by using one of the accessory drop cables.
-
Page 12: Configuration
LINK UP CONFIGURATOR APP To properly configure the system, some parameters must A simple and detailed explanation of the configuration be calibrated through the Link Up gateway, like sensor process is also available as in-app instructions. instance and warning threshold. - Page 13 To modify the configuration, press the “Change Configuration” button. 3. Choose the instance (e.g. Engine 2) so that the Link Up gateway will correctly transmit the exhaust temperature value over NMEA 2000®. Once the settings are completed, press the “Write Configuration”...
- Page 14 CONFIGURATION SUPPORTED LINK UP CONFIGURATIONS* Sensor Type Calibration Alarm available NMEA 2000® PGN Veratron pyrometer sensor Exhaust Temperature 130316 characteristic (fixed) (above) * the supported configurations may be updated at any time. Please make sure to always use the latest App version.
-
Page 15: Technical Data
TECHNICAL DATA TECHNICAL DATA DATASHEET Operating voltage 6 – 16.5 V Nominal voltage 12 V (from NMEA 2000® network) Power consumption ≤ 100 mA NMEA 2000® LEN IP X7 according to IEC60529 (when Protection class connected) Operating temperature -30°C to 80°C Flammability UL94-HB 100 –... - Page 16 TECHNICAL DATA LINK UP GATEWAY PYROMETER SENSOR Thermoelement: NiCr-Ni DIN 43710 Rubber grommet (with casing insulation) V-ring bolting Compensating wire: NiCr-Ni, 2x 0.5 mm Sleeve with sheathing, brazed Cable lug (2x): DIN 46237-3.5 Break protection spring Screw (2x): M3 x 6...
- Page 17 TECHNICAL DATA THREADED BUSHING (STEEL) EXTENSION CABLE...
- Page 18 NMEA 2000® drop cable 2 m A2C9624380001 NMEA 2000® drop cable 6 m A2C9624400001 NMEA 2000® T-splitter A2C3931270002 NMEA 2000® Power Cable A2C3931290001 NMEA 2000® Terminator Female A2C3931060001 NMEA 2000® Terminator Male A2C3931100001 Visit http://www.veratron.com for the complete list of accessories.
- Page 19 AG, except for the following actions: • Printing the document in its original format, totally or partially. • Copying contents without any modifications and stating Veratron AG as copyright owner. Veratron AG reserves the right to make modifications or improvements to the relative documentation without notice.
