peerless-AV DS-S560-1X3 Manual

Hide thumbs Also See for DS-S560-1X3:

Advertisement

Quick Links

DS-S560-1X3
46" - 60"
375 lb
MAX
(117 - 152 cm)
(170 kg)
ENG
1
2015-07-01
#:009-9120-6
(2020-01-13)

Advertisement

loading
Need help?

Need help?

Do you have a question about the DS-S560-1X3 and is the answer not in the manual?

Questions and answers

Summary of Contents for peerless-AV DS-S560-1X3

  • Page 1 DS-S560-1X3 46" - 60" 375 lb (117 - 152 cm) (170 kg) 2015-07-01 #:009-9120-6 (2020-01-13)
  • Page 2 WARNING ENG - This product is designed to be installed on solid concrete. Hardware is included for solid concrete installation. Before installing make sure the supporting surface will support the combined load of the equipment and hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail.
  • Page 3 This page intentionally left blank. 2015-07-01 #:009-9120-6 (2020-01-13)
  • Page 4 Parts (Before beginning, make sure you have all parts shown below). Parts List Description Part # pedestal 147-T1426 cover 145-T1809 vertical support bracket 145-T1806 column 146-T1131 extension 145-T1778 left adaptor bracket 146-1609 right adaptor bracket 146-1608 cross support 146-T1904 computer cover 145-T1930 computer shelf 145-T1931...
  • Page 5 H ( 3 ) I ( 1 ) J ( 1 ) K ( 2 ) computer cover cross support computer shelf extension adaptor L ( 4 ) M ( 4 ) N ( 56 ) O ( 24 ) P ( 8 ) Q ( 8 ) cord...
  • Page 6 X (4) Do not fully tighten hardware N (4) R (2) 2015-07-01 #:009-9120-6 (2020-01-13)
  • Page 7 TIGHTEN CONNECTING HARDWARE 2015-07-01 #:009-9120-6 (2020-01-13)
  • Page 8 N (6) 1/8" 1/8" (3mm) (3mm) O (4) C (6) TIGHTEN CONNECTING HARDWARE 2015-07-01 #:009-9120-6 (2020-01-13)
  • Page 9: Top View

    P (4) L (2) M (2) TIGHTEN CONNECTING HARDWARE TOP VIEW 2015-07-01 #:009-9120-6 (2020-01-13)
  • Page 10 WARNING ENG - When installing Peerless mounts on a concrete floor, the floor must be at least 8" thick with a minimum compressive strength of 2000 psi. Never attach concrete expansion anchors to concrete covered with plaster, drywall, or other finishing material. 2015-07-01 #:009-9120-6 (2020-01-13)
  • Page 11 Drill mounting holes into supporting surface (3" (76mm) minimum depth required). Align base. Mark mounting holes. 3/8" (10mm) 3" 3/8" (76mm) (10mm) 25.50" (648mm) 3/8" (10mm) Align base. Install using concrete anchors provided. ENG Maximum 35 ft • lb (47 N.M.). Y (8) 25.50"...
  • Page 12 TIGHTEN CONNECTING HARDWARE H (3) Tighten. Cross supports must center on vertical leg supports. 2015-07-01 #:009-9120-6 (2020-01-13)
  • Page 13 Center adaptor brackets vertically on back of screen. 2015-07-01 #:009-9120-6 (2020-01-13)
  • Page 14 10-1 "LOCKED" POSITION Must hang displays on bottom row first; Secure pin in "locked" position. 10-2 OPTIONAL: Insert M5 x 10mm type-F socket pin screws (Q) to lock latches. "LOCKED" POSITION 2015-07-01 #:009-9120-6 (2020-01-13)
  • Page 15: Rotate Right

    Display adjustment TILT FORWARD SIDE SIDE SIDE TILT BACKWARD TILT RIGHT TILT LEFT SIDE DOWN ROTATE LEFT ROTATE RIGHT 2015-07-01 #:009-9120-6 (2020-01-13)
  • Page 16 This page intentionally left blank. 2015-07-01 #:009-9120-6 (2020-01-13)
  • Page 17 12-1 2015-07-01 #:009-9120-6 (2020-01-13)
  • Page 18 12-2 1/8" (3mm) Q (2) 12-3 TIGHTEN CONNECTING HARDWARE 2015-07-01 #:009-9120-6 (2020-01-13)
  • Page 19 Route cables through cord brackets. 2015-07-01 #:009-9120-6 (2020-01-13)
  • Page 20: Limited Five-Year Warranty

    (from date of the original installation of the product). At its option, Peerless-AV will repair or replace, or refund the purchase price of, any product which fails to conform with this warranty.
