PROGRAMMING

XII.

USING THE LED KEYPAD

I.A.
ACTION
1. Entering the Program Mode
Go To Program Code
Factory
2. Entering the Module Address:
(example only)
3. Programming a Location:
To Enter a Location:
[location] #
To Change Location Data:
[changed data]
NX-320E Power Supply
RESULT
Enters the Program Mode.
Stay, Chime, Exit, Bypass & Cancel LEDS will flash.
If the "Go To Program Code" is valid, the "Service" LED will flash and
the 5 function LEDs will illuminate steady. You are now in the
Default is
Program Mode and ready to select the module to program.
#
Refer to Table IX:1 on page 8 for the module address.
The Armed LED will illuminate while it is waiting for a programming
location to be entered.
If an attempt is made to program an invalid entry for a particular segment, the keypad
sounder will emit a triple error beep (beep, beep, beep), and remain in that segment
awaiting a valid entry.
The Armed LED will flash. If the location is valid, the "Armed" LED will
extinguish, the "Ready" LED will illuminate, and the zone LED's will
show the data for the first segment of this location.
The "Ready" LED will flash to indicate a data change in process and
will continue until the data is saved.
The new data is saved.
The keypad will advance to the next segment and display its data.
NOTE: These steps are repeated until the last segment is reached.
