UM0993
User manual
How to upgrade the firmware of the STEVAL-MKI062V2
iNEMO™ inertial module V2 demonstration board
Introduction
This user manual describes the procedure required to upgrade the device firmware of the
STEVAL-MKI062V2 iNEMO™ inertial module V2 demonstration board based on MEMS and
the STM32.
September 2010
Doc ID 17902 Rev 1
1/11
www.st.com
www.BDTIC.com/ST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UM0993 and is the answer not in the manual?

Questions and answers

Related Manuals for ST UM0993

Summary of Contents for ST UM0993

  • Page 1 UM0993 User manual How to upgrade the firmware of the STEVAL-MKI062V2 iNEMO™ inertial module V2 demonstration board Introduction This user manual describes the procedure required to upgrade the device firmware of the STEVAL-MKI062V2 iNEMO™ inertial module V2 demonstration board based on MEMS and the STM32.
  • Page 2 Contents UM0993 Contents Using DFU with the STEVAL-MKI062V2 iNEMO V2 platform ..4 Revision history ......... . . 10...

  • Page 3: Table Of Contents

    UM0993 List of figures List of figures Figure 1. How to enter DFU mode through the iNEMO GUI ....... . 4 Figure 2.

  • Page 4: Figure 1. How To Enter Dfu Mode Through The Inemo Gui

    Using DFU with the STEVAL-MKI062V2 iNEMO V2 platform UM0993 Using DFU with the STEVAL-MKI062V2 iNEMO V2 platform Install the DfuSe.exe, which can be downloaded from: http://www.st.com/stonline/products/families/evaluation_boards/steval-mki062v2.htm Enter DFU mode. This can be done either through hardware or software. – Hardware: unplug the USB cable, press the SW2 button and, keeping the button pressed, connect the USB cable to the PC.

  • Page 5: Figure 2. Confirm Entry In Dfu Mode Through The Inemo Gui

    UM0993 Using DFU with the STEVAL-MKI062V2 iNEMO V2 platform Figure 2. Confirm entry in DFU mode through the iNEMO GUI Open DfuSe Demonstration from “Start -> Programs -> STMicroelectronics -> DfuSe -> DfuSe Demonstration”. If the device is in DFU mode, it appears in the box circled in red Figure Figure 3.

  • Page 6: Figure 4. How To Load The .Dfu File From The Dfuse Gui

    Using DFU with the STEVAL-MKI062V2 iNEMO V2 platform UM0993 Load the .dfu file (example: from the iNEMO V2 application installation folder, select \Firmware\DFU_Images\ iNEMOV2 Firmware_Package_V1.0.dfu), as shown in Figure Figure 4. How to load the .dfu file from the DfuSe GUI...

  • Page 7: Figure 5. Verify The Vendor Id And Product Id

    UM0993 Using DFU with the STEVAL-MKI062V2 iNEMO V2 platform Verify that the vendor ID and product ID are 0483 and 7007, respectively (see Figure Figure 5. Verify the vendor ID and product ID Check the “Verify after download” and “Optimize Upgrade duration (Remove some FFs)”...

  • Page 8: Figure 7. Verify The Upgrade

    Using DFU with the STEVAL-MKI062V2 iNEMO V2 platform UM0993 Check that the “Verify Successful!” message is displayed, as in Figure Figure 7. Verify the upgrade Press the “Leave DFU mode” button to exit DFU mode. You can also exit from DFU...

  • Page 9: Figure 9. Verify Dfu Mode Exit

    UM0993 Using DFU with the STEVAL-MKI062V2 iNEMO V2 platform Figure 9. Verify DFU mode exit Doc ID 17902 Rev 1 9/11 www.BDTIC.com/ST...
  • Page 10 Revision history UM0993 Revision history Table 1. Document revision history Date Revision Changes 10-Sep-2010 Initial release. 10/11 Doc ID 17902 Rev 1 www.BDTIC.com/ST...
  • Page 11 No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted under this document. If any part of this document refers to any third party products or services it shall not be deemed a license grant by ST for the use of such third party products or services, or any intellectual property contained therein or considered as a warranty covering the use in any manner whatsoever of such third party products or services or any intellectual property contained therein.
