Summary of Contents for ST STM32Cube FP-SNS-MOTENVWB1
- Page 1 Quick Start Guide STM32Cube function pack for STM32WB with BLE connectivity and environmental and motion sensors (FP-SNS-MOTENVWB1) Version 1.1 (Nov, 2019)
- Page 2 Quick Start Guide Contents FP-SNS-MOTENVWB1: STM32Cube function pack for STM32WB with BLE connectivity and environmental and motion sensors Hardware and Software overview Setup & Demo Examples Documents & Related Resources STM32 Open Development Environment: Overview...
- Page 3 MEMS environmental sensor evaluation board system • It is compatible with the Arduino UNO R3 connector layout, and is designed around ST’s latest sensors. Key Products on board LSM6DSO MEMS 3D accelerometer (±2/±4/±8/±16 g) + 3D gyroscope (±125/±250/±500/±1000/±2000 dps) LIS2DW12 MEMS 3D accelerometer (±2/±4/±8/±16 g)
-
Page 4: Hardware Overview
Motion MEMS and environmental sensors expansion board Hardware Overview (2/3) Key features • The X-NUCLEO-IKS01A3 is a motion MEMS and environmental sensor evaluation board system. • All sensor sensors are connected on a single I²C • Sensor I²C address selection •... - Page 5 Board expansion connectors: – Arduino™ Uno V3 – ST morpho • Integrated PCB antenna or footprint for SMA connector • Flexible power-supply options: ST-LINK USB VBUS or external sources • On-board socket for CR2032 battery • On-board ST-LINK/V2-1 debugger/programmer with USB re- Latest info available at www.st.com...
-
Page 6: Software Overview
FP-SNS-MOTENVWB1 is an STM32Cube function pack, which lets you connect your IoT node to a smartphone via BLE and uses a suitable Android™ or iOS™ application, such as the ST Software overview BLE Sensor app, to view realtime motion and environmental (such as temperature, relative humidity) sensor data. - Page 7 Quick Start Guide Contents FP-SNS-MOTENVWB1: STM32Cube function pack for STM32WB with BLE connectivity and environmental and motion sensors Hardware and Software overview Setup & Demo Examples Documents & Related Resources STM32 Open Development Environment: Overview...
- Page 8 Setup & demo examples HW prerequisites • 1 x Motion MEMS and Environmental Sensor Expansion Board (X-NUCLEO-IKS01A3) • 1 x Bluetooth™ 5 and 802.15.4 Nucleo Pack including USB dongle and Nucleo-68 with STM32WB55 MCUs (P-NUCLEO-WB55) • 1x USB type A to Mini-B USB cable Micro USB P-NUCLEO-WB55 X-NUCLEO-IKS01A3...
- Page 9 • Copy the .zip file content into a folder on your PC • The package contains the source code examples (Keil, IAR EWARM, System Workbench for STM32) compatible with P-NUCLEO-WB55 • ST BLE Sensor App for Android/iOS to download from Google Play Store / iTunes...
- Page 10 FP-SNS-MOTENVWB1 STM32 Function Pack FP-SNS-MOTENVWB1 www.st.com/stm32ode-fp Go to Docs Select FP-SNS-MOTENVWB1 BSP, HAL and drivers STM32 WPAN BLE, Motion Libs Application example Download and unpack .\Projects\P-NUCLEO-WB55.Nucleo\Applications\MOTENV1 Android™/iOS™ Smartphone and ST BLE Sensor Build/Flash and Run the project...
- Page 11 FP-SNS-MOTENVWB1 Unicleo-GUI (1/2) • Unicleo-GUI supports connection with BLE device* with compatible FW http://www.st.com/en/product/unicleo-gui Enable BLE support in Unicleo-GUI (and restart the app) Add BT device. Select WBMEMS or STM32WB. Pin: 111111 * Windows 10 is required...
- Page 12 FP-SNS-MOTENVWB1 Unicleo-GUI (1/2) Connect Select device See data Enable / Disable characteristics Show charts...
-
Page 13: Installation Procedure
FP-SNS-MOTENVWB1 Installation procedure • Connect the P-NUCLEO-WB55 and the X-NUCLEO-IKS01A3 expansion board • Connect the P-NUCLEO-WB55 to your PC From the software package drag and drop the *.bin Binary folder) on STM32 WB Nucleo drive... - Page 14 FP-SNS-MOTENVWB1 ST BLE Sensor App for Android/iOS (1/2)
- Page 15 FP-SNS-MOTENVWB1 ST BLE Sensor App for Android/iOS (2/2)
- Page 16 DB3966: STM32Cube function pack for STM32WB with BLE connectivity and environmental and motion sensors – Data brief • UM2613: Getting started with the STM32Cube function pack for STM32WB with BLE connectivity and environmental and motion sensors – User Manual • Software setup file Consult www.st.com for the complete list...
- Page 17 Quick Start Guide Contents FP-SNS-MOTENVWB1: STM32Cube function pack for STM32WB with BLE connectivity and environmental and motion sensors Hardware and Software overview Setup & Demo Examples Documents & Related Resources STM32 Open Development Environment: Overview...
- Page 18 The STM32 Open Development Environment (ODE) consists of a set of stackable boards and a modular open SW environment designed around the STM32 microcontroller family. STM32 Nucleo STM32Cube expansion boards development software (X-NUCLEO) STM32Cube STM32 Nucleo expansion software development boards (X-CUBE) Function Packs (FP) www.st.com/stm32ode...
- Page 19 Power supply STM32 microcontroller through USB or external source Integrated debugging Complete product range and programming from ultra-low power to high-performance ST-LINK probe ST morpho extension header Arduino™ UNO R3 extension headers www.st.com/stm32nucleo...
- Page 20 Boards with additional functionality that can be plugged directly on top of the STM32 Nucleo development board directly or stacked on another expansion board. Connect Power Move/Actuate Interact Sense Motion MEMS sensors Environmental sensors DIL24 support for new devices Example of STM32 expansion board (X-NUCLEO-IKS01A1) www.st.com/x-nucleo...
-
Page 21: Software Components
Environment is compatible with a number of IDEs including IAR EWARM, Keil MDK, and GCC-based environments. Users can choose from three IDEs from leading vendors, which are free of charge and deployed in close cooperation with ST. These include Eclipse-based IDEs such as Ac6 System Workbench for STM32 and the MDK-ARM environment. - Page 22 NFC, Wi-Fi, GNSS Audio amplifier ACCESS Touch controller Translate Operation Amplifier CREATE Move / Stepper motor driver DC & BLDC motor driver Actuate Industrial input / output POWER Power Energy management & battery General-purpose microcontrollers PROCESS Process Secure microcontrollers www.st.com/stm32ode Software...
