2.3 Connect Output Source
Q2 Series supports SDI、DVI、HDMI、HDBaseT and other optional output modules.
Connect Q2-4 with monitors.
2.4 Connect control Computer
Q2 series is operated by XPOSE,so it is necessary to connect device with control computer.
Method 1：Direct Connection:Connect Q2-4 with computer via network cable as shown in the figure below.It is
suitable for single user to control the device.
Method 2：Router Connection:Connect control computer and Q2-4 with Router as shown in the figure below.It
supports simultaneous online operation by multiple users.
Q2
User Manual
17
