Q2-4
1
Purple Input 1-9
2
Blue Output 1-5
3
Yellow COMM
4
Q2
1
4
Input slots 1-9,supporting DVI,HDMI,DP,H.264 modules and
other optional modules.
Output slots 1-5,supporting HDMI,DVI and other optional
modules.
Communication board with LAN and RS232 port,to connect
router or computer to realize software control.
Power Interface,4U and above supports double power.
