  • Page 1 P R O S W I N G OPERATOR FOR SWINGING DOORS ENGLISH MANUAL INSTRUCTIONS...
  • Page 3 SESAMO PROSWING Thank you for choosing this product. For best automatism performance, Sesamo recommends you carefully read and follow the installation and use instructions found in this manual. Installation of this automatism must only be performed by the professionally qualified personnel for whom this manual is addressed.

  • Page 4: Direttiva Macchine

    - the relative technical documentation will be compiled by: SESAMO SRL, Strada Gabannone, 8/10 - 15030 Terruggia (AL) - Italy...

  • Page 5: Caratteristiche Tecniche

    4)This automatism has been designed and built exclusively for the use specified in this documentation. Any different use not stated herein could affect the integrity of the product and/or represent danger situation. 5)SESAMO declines any responsibility from misuse or different use from which it was intended.

  • Page 6: Recycling And Disposal

    6)Do not install the product in explosive environment: the presence of flammable gases or fumes is a serious safety hazard. 7)SESAMO is not responsible for the failure to comply with the Good Technical construction procedure of the door to be automated, as well as deformations that may occur to the door when using the same.

  • Page 7: Limit Of Use

    This device is intended only for swinging pedestrian door, dry and inside use. SESAMO shall not be held liable for any other use contrary to the use foreseen. TYPES OF ARMS RIGID ARM: the rigid arm can be used as PULLING arm (when the operator is installed on the same side of the opening of the door).
  • Page 8 INSTALLATION PULL SLIDE ARM (PROSWING R) Remove the cover (Fig.9 Part.A) from the guide (Fig.9 part.B) to allocate the fixing points.

  • Page 9: Push Arm Installation

    SESAMO PROSWING Close the cover (Fig.9 Part.A) of the guide. Closed the right cap (Fig.9 part.E) and left cap (Fig.9 part.D) with the supplied screws. Proceed with the adjustment of the spring [vedi paragrafo “[see paragraph “Spring adjustment”]. Before tighten the arm extension, please check the distance between the guide and the upper...

  • Page 10: Spring Adjustment

    SESAMO PROSWING ATTENTION: For articulated push arm, both right/left opening, set switch as shown in Fig. 16. SPRING ADJUSTMENT The spring has to be charged according to the width of the door keeping in consideration the norm EN 1154 in the range from EN 4 to EN 6.
  • Page 11 SESAMO PROSWING Bring the cable inside the automatism paying attention not to damage it against metallic edges. Open the cover (Fig.18 Part.A) Connect the power supply and the ground cable on the terminal (Fig.18 Part.B) Close the cover (Fig.18 Part.A) ATTENTION: Never invert power supply cable and ground cable.
  • Page 12 SESAMO PROSWING EXTERNAL PERIPHERALS CONNECTORS INPUT SEGNALE DEFAULT DESCRIZIONE FUNZIONAMENTO If the contact opens the unit sends a complete closing cycle command (from any position) From this moment until the Lock contact. Lock devices signal is closed the door stays closed and...

  • Page 13: Installation Of The Sensors

    SESAMO PROSWING This contact allows to unlock manually the 5- Command lock release lock without opening door through motor. 6- Single command in In case of Double system, opens only double system MASTER  door. When the contact is closed the door goes...
  • Page 14 SESAMO PROSWING Sensors wiring and control board setting: SENSORE SCHEMA 17=0 Safety monitoring sensor in closing (ref. Fig.39 A) ref. Fig.22 30=1 17=0 Safety monitoring sensor in opening (ref. 39 B) ref. Fig.23 30=1 Detection sensor (radar) entry (ref. Fig.39 D) ref.

  • Page 15: Dip - Switches Setting

    SESAMO PROSWING ATTENTION: LS must be repeated whenever the configurations of the sensors connected or the automatism are modified. ATTENTION: in case of double Proswing (2 wings) it is necessary to carry out LS procedure on both control boards (master and slave).
  • Page 16 SESAMO PROSWING To properly see the display set the jumper according the opening direction of the wing as shown in Fig.27. La modalità di programmazione è la seguente: Select parameter thorough push button [+] and [-]; press [ENT] to enter in the adjustment procedure.
  • Page 17 SESAMO PROSWING Activation of the electric lock or motor 3 = Proswing R mag lock always active on logic ONE closing according to radar and TWO radards (automatic) the logic selected 0 = DDA opening 1 = Emergency opening 2 = Interlock door with priority...
  • Page 18 RANGE: 5 ÷ 60 (0 = force min 9= force max) procedure Opening angle RANGE: 0÷50% reduction Installation on lintel 2=Proswing R only lintel or door 0=Low Energy DDA speed 1= speed according to parameters 1 e 2 0=std (only spring)

  • Page 19: Message Or Errors Code

    SESAMO PROSWING During parameters setting any movement of motor is allowed. When parameters setting it is not used, push button [ENT] is an opening command (only with One Radar or Two Radars logics). START UP Set main power switch (Fig.1 A) on OFF.

  • Page 20: Operating Logics

    SESAMO PROSWING CL Fixed Door closed CL Blinking Door closing Door needs self learning procedure (see Paragraph “Start up”) Wrong arm selection [DIP 1 or switch on break board - see Paragraph “type arm selection”), or wrong selection automatism- DIP 5.
  • Page 21 Closing force of RANGE: 0(min) ÷ 9(max) electric lock Activation of the electric lock or motor 3 = Proswing R mag lock always active on logic ONE closing according to radar and TWO radars (automatic) the logic selected 4 = Lock feedback...
  • Page 22 SESAMO PROSWING push back hit. It is powered again when door is RANGE: 0÷9 near to fully closed position [t=200÷2000 ms] See Fig.27 - Magnet, keep door closed , if ELETTROMAGNETE released, the door is free. It does not require a...
  • Page 23 SESAMO PROSWING with two Proswing installed on each door and connected together by a extension kit Fig.30 (OPTIONAL). The two Proswing, through a wiring on the selector terminal board, can exchange information in order to rightly drive the two doors. It is needed to set one control door as a Master and one as a Slave.
  • Page 24 SESAMO PROSWING • MASTER (parameter 13 =1); • SLAVE (parameter 13 =2); Even in case of door without displacement it is necessary to set Master and Slave. ATTENTION: use same power line for the two automatisms without any fuses or switches between the two boards.

  • Page 25: Logic Switch

    Hand the guarantee and test certificate over filled according to the instructions shown in the certificate. The certificates must be sent to SESAMO in 8 days from the positive test date. Hand the technical documentations over to the client .
  • Page 26 SESAMO PROSWING...
  • Page 27 SESAMO PROSWING Fig.1 Fig.2 Fig.3...
  • Page 28 SESAMO PROSWING Fig.4...
  • Page 29 SESAMO PROSWING Fig.5...
  • Page 30 SESAMO PROSWING Fig.6...
  • Page 31 SESAMO PROSWING Fig.7...
  • Page 32 SESAMO PROSWING Fig.8...
  • Page 33 SESAMO PROSWING Fig.9 Fig.10...
  • Page 34 SESAMO PROSWING Fig.11 Fig.12...
  • Page 35 SESAMO PROSWING Fig.13 Fig.14 Fig.15 Fig.16...
  • Page 36 SESAMO PROSWING Fig.17 Fig.18...
  • Page 37 SESAMO PROSWING Fig. 19...
  • Page 38 SESAMO PROSWING Fig. 20 Fig. 21...
  • Page 39 SESAMO PROSWING Fig. 22...
  • Page 40 SESAMO PROSWING Fig. 23...
  • Page 41 SESAMO PROSWING Fig. 24 Fig. 25...
  • Page 42 SESAMO PROSWING Fig.26 Fig.27...
  • Page 43 SESAMO PROSWING Fig.28 Fig.29...
  • Page 44 SESAMO PROSWING Fig.30 Fig. 30...
  • Page 45 SESAMO PROSWING Fig. 31...
  • Page 46 SESAMO PROSWING...
  • Page 48 MAN_PRO.R _EN_16_10_20 SESAMO srl Str. Gabannone, 8/10 15030 Terruggia (AL) Italy Tel: +39 0142 403223 Fax: +39 0142 403256 www.sesamo.eu e-mail: info@sesamo.eu...
