  • Page 1 Automatisms for swinging doors P P A A T T E E N N T T P P E E N N D D I I N N G G...
  • Page 3: Table Of Contents

    Connections ......................pag. Led functions ...................... pag. Jumpers ......................pag. Start up ........................ pag. Inter lock connection and use ................pag. Error Message Table.................... pag. SESAMO reserves the right to change the technical specifications of the products, even without notice.
  • Page 4 Installation Instruction Machine directive Thank you for choosing this product. For best automatism performance, Sesamo recommends you carefully read and The installer who motorised a door becomes the automatic follow the installation and use instructions found in this man- door machine manufacturer according to directive 98/37/CE ual.
  • Page 5: Technical Specifications

    C. Safety closing device D. Logic selection selector E. Opening button at exit Fig. 1 Automatism description The Swingo automatism (Fig.2) is essentially made up of: A. Steel fastening base B. Plastic cover C. Gear motor unit D. Electronic control panel E.
  • Page 6: Sizes And Dimensions

    Installation Instruction Sizes and dimension Fig. 3 Dimension of the fixing holes and cables opening SWINGO standard Fig. 4 Use the appropriate drilling template included with the product to make easier the installation. Adapter plate (optional) Fig. 5...
  • Page 7: Automatism Assembly

    For a correct positioning, always use the main axis of the wing hinges and the operation axis of the gear- motor as a reference, as shown in Fig.5. Swingo fastening diagram 1 left-hand opening wing Rigid Pull Arm right-hand opening...
  • Page 8 WARNING : For a correct positioning, always use the main axis of the wing hinges and the operation axis of the gear- motor as a reference, as shown in Fig.7. Swingo fastening diagram 1 left-hand opening wing Articulated push arm Gearmotor Axis Articulated push arm Fig.
  • Page 9 Installation Instruction Use of adapter plate (optional) If one or more fastening points of the Swingo plate are unusable for firmly anchoring the automatism to the fixed part, use the optional adapter plate. Adapter plate (optional) Gearmotor Axis WARNING : For a correct positio-...
  • Page 10 Installation Instruction Assembly of the articulated push arm WARNING : The articulated arm is NOT symmetric. Depending on the opening direction (right-hand or left-hand), posi- tion the brackets of the arm and the bushings as indicated in the following figures. Wings Wings Right Opening...
  • Page 11: Adjustment Of The Stop

    Installation Instruction Adjustment of the Stop Open the wing to the desired opening limit, then position the rubberized stop on the floor and tighten the screw on the stop. WARNING : The max. allowed opening angle is 100°. Battery connections Connect the battery wiring to the proper clamp on the electronic board Fig.
  • Page 12: Number Wing Selection

    S3 ON Double setting wing Master Double setting wing Slave “Low Power” mode Selection The Swingo operation can be set in "low power" mode, which provides for reduced operating speeds and accelerations. S4 ON S4 OFF (DEFAULT) Normal mode "low power" mode...
  • Page 13: First Input Mode Selection

    First Input Mode Selection Swingo can be connected to a closing device such as an electronic key, key selector, transponder, etc. Using the dip switch S5, the signal can be controlled in bistable or monostable mode with an activation time of about 500msec.
  • Page 14: Swingo Electronic Board

    Installation Instruction SWINGO Electronic Board The meanings of the main electronic board components are listed in Fig. 17 : connector Transformer Battery Encoder connector connector Switch connector connector Jumpers External Connettore peripheral Motore connector START opening Electronic Multi-logic selector Dip Switchs...
  • Page 15 Installation Instruction External peripheral connector Fig. 20 SIGNAL TYPE* DESCRIPTION FUNCTION Common electrical signal. SAFE CLOSE Signal for the connection of an external If the door is closing and the contact opens, the unit sends and photocell or safety control device for immediate motion inversion command.
  • Page 16: Led Functions

    Connector for PC - unit connections PC connection board Fig. 21 A PC connection board (optional) is required to connect the SWINGO unit to a Personal Computer. The following is possible with MILLENNIUMWARE software: • Advanced adjustments of some operating parameters •...
  • Page 17: Start Up

    Installation Instruction Start Up WARNING If no optional operation lock device is installed, make sure the KEY input is short circuited with the COM input. Otherwise the equipment cannot be started. If no safe close device is installed, make sure the SAFE CLOSE input is short circuited with the COM input. Otherwise the equipment cannot be started.
  • Page 18: Inter Lock Connection And Use

    Reassemble the cover by screwing on the two appropriate screws. Hand the guarantee and test certificate over filled according to the instructions shown in the certificate. The certificates must be sent to SESAMO in 8 days from the positive test date. Hand the technical documentations over to the client.
  • Page 19 SESAMO srl Str. Gabannone, 8/10 • 15030 Terruggia (AL) • Italy Tel: +39 0142 403223 • Fax: +39 0142 403256 www.sesamo.eu • E-mail: info@sesamo.eu...
