MAINTENANCE MANUAL
MILLENNIUM SERIES AUTOMATIONS
TYPE OF AUTOMATISM
Light Millennium
Telescopica Millennium
Pratika Millennium
During a scheduled maintenance operation, carried out by an authorised technician, it is advisable to
carefully perform the checks and procedures listed below :
Remove the mains power supply using the bipolar switch upstream from the automatism.
Open the automatism by removing the cover.
Disconnect the batteries.
Check the tightening of the screws on the carriages and the components installed inside the box.
Check the connections of the wiring between the accessories, sensors and the electronic control unit.
Clean the runway with a cloth (without detergents) and check that it is intact.
Check the smoothness of the frame, its general conditions (evaluate any misalignments caused by
impacts) and check, above all, that there is a minimum space of 5 mm between the pavement and the
wing so as to guarantee correct sliding even in the event of extensive thermal expansions of the frame.
Clean the pulleys of the carriages and check the wear; replace if necessary.
Grease the runway with a thin layer of bearing grease.
Check the wear of the belt and grease it.
Reconnect the automatism to the mains power supply and the batteries.
Check the wear and correct operation of the floor guide; grease or replace it if necessary.
Check the wear of the rubber stops; replace and adjust them as necessary.
Check the correct operation of the blocking device, manual release and automatic reset.
Check the safety sensors (functionality and adjustment).
Check the detection sensors (functionality and adjustment).
Check the movement of the wings during braking and approach.
Verify the correct selection of the operation logics.
Check the efficiency of the batteries by operating the installation for a period without the mains power
supply.
Test the correct operation of the antipanic breakaway system, if installed.
MAINTENANCE MANUAL FOR
FOR SLIDING DOORS
SERIAL NUMBER
DATE
1
MILLENNIUM SERIES
INTERVENTION
Maintenance Operation
Intervention by Request
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sesamo MILLENNIUM SERIES
Summary of Contents for Sesamo MILLENNIUM SERIES
- Page 1 MAINTENANCE MANUAL MILLENNIUM SERIES MAINTENANCE MANUAL FOR MILLENNIUM SERIES AUTOMATIONS FOR SLIDING DOORS TYPE OF AUTOMATISM SERIAL NUMBER DATE INTERVENTION Light Millennium Maintenance Operation Telescopica Millennium Intervention by Request Pratika Millennium During a scheduled maintenance operation, carried out by an authorised technician, it is advisable to carefully perform the checks and procedures listed below : Remove the mains power supply using the bipolar switch upstream from the automatism.
- Page 2 MAINTENANCE MANUAL MILLENNIUM SERIES Note: Diagnostics to identify the automatism failure DESCRIPTION NUM. WHAT TO DO An error occurred during initialisation, in particular, the measured opening quota is too low. Check the encoder, the Initialization error OFF OFF OFF connection between the encoder and mother boards.
