Installation Instruction Thank you for choosing this product. For best automatism Machine directive performance, Sesamo recommends you carefully read and The installer who motorised a door becomes the automatic follow the installation and use instructions found in this man- door machine manufacturer according to directive 98/37/CE ual.
A. Extruded aluminium alloy fastening base B. Extruded aluminium alloy cover C. Aluminium end sides (Flat steel end sides option) D. Gear motor unit E. SESAMO MILLENNIUM Electronic control panel F. Transformer G. Encoder unit H. Emergency battery (24V 0,8Ah)
PIUMA MILLENNIUM Installation Instruction Sizes and dimension The Piuma Millennium automatism is available in two configurations: with standard heads in aluminium (L=810 mm) and with flat heads (optional) in steel (L=800 mm). Standard End Sides Flat End Sides (opzionali) Fig. 3 Fixing Holes (Std End Sides) Gearmotor axis Fig.
PIUMA MILLENNIUM Installation Instruction Automatism assembly WARNING : Before proceeding with the installation, remove the cardboard component positioned underneath the motor body. Positioning dimensions (rigid pull arm) The rigid pull arm is used when the automatism is installed on the swing side of the door . WARNING For a correct positioning, always use the main axis of the door hinges and the operation axis of the gearmotor as a reference, as shown in Fig.6.
Page 8
PIUMA MILLENNIUM Installation Instruction Positioning dimensions (articulated push arm) The articulated push arm is used when the automatism is installed on the approach side of the door (the side opposite the swing side). For left-hand opening doors (door opening with anti-clockwise rotation) position the automation as shown in Fig.
Page 9
PIUMA MILLENNIUM Installation Instruction Automatism components shift and removal Disassemble the push arm (if present) (Fig. 10 Part A) by unscredoor the counter-sunk head screw M6 x 70 (Fig. 10 Part B). Extract the top hexagonal stop (Fig. 10 Part C). Remove the aluminium cover (Fig. 10 Part D) by pulling it outwards. Fig.
Page 10
PIUMA MILLENNIUM Installation Instruction Installation of the guide and rigid pull arm Insert the threaded hexagon in the upper part of the hexagonal hole of the gearmotor (Fig.12 part.A). Assemble the rigid pull arm (Fig.12 part.B) to the upper hexagon with the flathead screw M6x70 supplied (Fig.12 part.C) after having interposed the washers Ø6,4x12 (Fig.12 part.D) as shown in the figure Before tightening the flathead screw, check carefully that the distance bet- ween the guide and the rigid arm is about 13 mm (Fig.13).
Page 11
PIUMA MILLENNIUM Installation Instruction Installation of the guide and rigid pull arm Reach the guide fixing box (Fig.16 part.A) taking off the S924/A cap (Fig.16 Part.B). Make at least 4 holes corresponding to the “V” shape in the guide profile. Use these holes to fix the guide to the frame with appropriate screws.
Fig. 18 WARNING : The max. allowed opening angle is 100°. In the absence of the optional SESAMO stops, limit the travel of the door in any case (MAX 100°) by means of a rubber stop for example (not included in the supply).
PIUMA MILLENNIUM Installation Instruction Final operations Before starting the automatism, check and perform the following: • Accurately remove and dust or shavings • Ensure the proper fixing of the automatism on the wall • Check correct tightening • Check that the wires are fixed and that no wire pass near the movement area. •...
Fig. 22 (*)For the connection of the electric lock, use the optional SESAMO wiring. The compatible electric locks can have a 12V or 24V power supply and must have the "anti-repeater” function (permanent release after the electric pulse: the locking is restored after the door has been opened and closed).
PIUMA MILLENNIUM Installation Instruction Right Side Electronic Board Connections Fig. 23 A. Photocell amplifier board connector (optional) Insert the amplifier module observing the assembly direction shown in Fig. 21 WARNING Select the Jumper for single or double beam and check the red led JUMPER BEAM OFF Closed towards B2...
Page 16
PIUMA MILLENNIUM Installation Instruction Multi-logic selector connector ADVANCED SELECTOR Shielded cable with 4 wires 0,22 mm. Fig. 37 (Do not connect the shield of the wire used) BASE SELECTOR Fig. 26 Use the four conductors in the shielded wire for connections, observing the correspondences indicated by the markings on the terminal board and multi-logic selector.
Page 17
PIUMA MILLENNIUM Installation Instruction SIGNAL TYPE * DESCRIPTION FUNCTION Common electrical signal. SAFE CLOSE Signal for the connection of an external If the door is closing and the contact opens, the unit sends and photocell or safety control device for immediate motion inversion command.
PIUMA MILLENNIUM Installation Instruction LED Functions ON indicates mains Factory use ON indicates 12V external voltage present only peripheral power supply indicates encoder signal presence ON indicates electronic lock power Diagnostics Led External peripheral (see Error Message Table) signal presence led. ON indicates motor power supply Fig.
PIUMA MILLENNIUM Installation Instruction Electric Lock Operation Selection S7 ON S7 OFF (Default) Electric Lock active Electric Lock disabled The automatism, with every opening of the door, excites the electric lock with a pulse having a duration of 120 ms. Select the power supply voltage of the electric lock by setting the jumper J1 as shown in the following diagram: J1 OFF (DEFAULT) J1 ON...
PIUMA MILLENNIUM Installation Instruction “Low Power” mode Selection The Piuma Millennium operation can be set in "low power" mode, which provides for reduced operating speeds and acce- lerations. S4 ON S4 OFF (DEFAULT) Normal mode "low power" mode MultiSlave Selection A single selector can be connected and extended to several Piuma Millennium automatisms using two different operation logics: - DEFAULT: the selector acts on all the automatisms connected to it without any distinction.
PIUMA MILLENNIUM Installation Instruction Battery Mode S6 OFF - Normal Mode (Default). S6 ON - Antipanic Mode. In the event of power failure the equip- In the event of power failure, the ment continues working powered by equipment moves the doors to the the battery.
PIUMA MILLENNIUM Installation Instruction Master - Slave Selection (Piuma Doppio Only) Only in the case of Piuma Doppio, after having set S3=ON, it is necessary to set a master automatism and a slave automatism. S1 ON S1 OFF S2 OFF S2 OFF S3 ON S3 ON...
Hand the guarantee and test certificate over filled according to the instructions shown in the certificate. The certificates must be sent to SESAMO in 8 days from the positive test date. Hand the technical documentations over to the client .
Page 25
PIUMA MILLENNIUM Installation Instruction At the end of reset the equipment is ready for use; check correct sensor operations for opening command and safety control.Also check anti-crushing sensitivity; if the value requires increasing and decreasing, see the advanced selector manual. To test automatism operations without connections to the open command device use the START button on the unit (see Fig.
PIUMA MILLENNIUM Installation Instruction Piuma Doppio connection and use WARNING Define the Master door (see Set Dip-Switch paragraph) before performing the connections. It will not be possible to determine the Master or Slave door after completing the wiring. WARNING Both devices should be connected to the same power supply branch with no switches or fuses between them. The SAFE CLOSE, KEY, START 1 and START 2 peripherals, if any, should be connected to the Master door.
PIUMA MILLENNIUM Installation Instruction Inter lock connection and use The MILLENNIUM unit is set to work in inter lock mode through con- Control Unit A nections to an electronic unit of the same family. In inter lock mode one door can only open if the other is not moving, that is, if not in the movement phase.
