ITV1000/2000/3000
Series
Dimensions
ITV20
Flat bracket
Solenoid valve EXH
Cable connector (4 wire)
with ferrite core (not shown)
to comply with EMC
Right angle type
SMC REGULATOR
ITV2000
L-bracket
2
36
2 x Rc1/4, 3/8
SUP port, OUT port
11
Note) Do not attempt to rotate, as the cable connector does not turn.
M12 x 1
12.5
Cable connection threads
Rc1/4
Exhaust port
OUT
EXH (3)
2 x Rc1/4, 3/8
Port size
Cable connector (4 wire)
with ferrite core (not shown)
to comply with EMC
Straight type
SMC REGULATOR
ITV2000
OUT
L-bracket
INI-398-0-6
(Optional)
2.3
45
M5
Solenoid valve
EXH
SUP (1)
Flat bracket
P3020114
(Optional)
UNLOCK
G
(10) 30
(7) 36
SMC REGULATOR
ITV2000
OUT (2)
36
4 x M5
thread depth 6 mm through
Mounting hole
50
4 x ø7
Mounting hole
RESET
SET
LOCK
84
100
