Equipment Setup

Equipment Setup
2
2.1

Mounting

The QuickServer can be mounted using the DIN rail mounting bracket on the back of the unit.
Din Rail
Bracket

Figure 1: DIN Rail Bracket

NOTE: For dimension details see Section 10.7.

Figure 2: DIN Rail Mounted
