DESCRIPTION - INFLATABLE TUBE

I-1 TECHNICAL CHARACTERISTICS OF THE eJET 450 ................................................................................ 3

I-2 INVENTORY AND LOCATION ............................................................................................................... 6

I-3 HANDLING ........................................................................................................................................ 12

I-3-1 Transport ................................................................................................................................... 12

I-3-2 Storage ...................................................................................................................................... 13

I-3-3 Lifting ........................................................................................................................................ 15

II-1 MAINTENANCE OF THE INFLATABLE TUBE...................................................................................... 16

II-2 INSTALLING THE INFLATABLE TUBE ON THE HULL .......................................................................... 16

II-3 SECURING THE INTERNAL PROTECTIVE FLAP .................................................................................. 17

II-4 INFLATING THE INFLATABLE TUBE .................................................................................................. 18

II-5 PRESSURE ........................................................................................................................................ 20

III- INSPECTION BEFORE USE ................................................................................................................. 23

III-1 INFLATABLE TUBE ........................................................................................................................... 23

III-2 BILGE .............................................................................................................................................. 23

III-3 12V BATTERY .................................................................................................................................. 23

III-4 BMW i3 HIGH-VOLTAGE BATTERY .................................................................................................. 23

III-5 THRUST REVERSER FLAP ................................................................................................................. 24

III-6 STEERING WHEEL ........................................................................................................................... 24

III-7 COOLING SYSTEM ........................................................................................................................... 24

III-8 ELECTRICITY .................................................................................................................................... 25

III-9 PROPULSION................................................................................................................................... 25

III-10 EXTINGUISHER .............................................................................................................................. 25

IV-1 STARTING A TRIP ............................................................................................................................ 26

IV-2 MOTION FORWARD AND REVERSE ................................................................................................ 27

IV-3 BRAKING ......................................................................................................................................... 28

IV-4 END TRIP ........................................................................................................................................ 28

V- CHARGING THE HIGH-VOLTAGE BATTERY ........................................................................................ 29

VOLUME 2

PROPULSION SYSTEM

FITTING AND CIRCUITS

CONTENTS

Page 1 / 47

Edition 3

Table of Contents

Need help?

Do you have a question about the eJET 450 and is the answer not in the manual?

Questions and answers

Summary of Contents for Zodiac eJET 450

Page 1: Table Of Contents
VOLUME 2 DESCRIPTION - INFLATABLE TUBE PROPULSION SYSTEM FITTING AND CIRCUITS CONTENTS I-1 TECHNICAL CHARACTERISTICS OF THE eJET 450 ................3 I-2 INVENTORY AND LOCATION ....................... 6 I-3 HANDLING ............................12 I-3-1 Transport ........................... 12 I-3-2 Storage ............................13 I-3-3 Lifting ............................15 II-1 MAINTENANCE OF THE INFLATABLE TUBE..................
Page 2 VI-1 HIGH-VOLTAGE SYSTEM ......................... 30 VI-2 ELECTRICITY ............................ 31 VI -2-1 General wiring diagram ......................31 VI -2-2 General wiring plan ........................ 33 VI -2-3 Location of items ........................36 VI -2-4 Circuit breaker ........................36 VI -2-5 12V battery ..........................37 VI -2-6 Bilge fan ..........................
Page 3: Technical Characteristics Of The Ejet 450
DESCRIPTION - Technical characteristics I-1 TECHNICAL CHARACTERISTICS OF THE eJET 450 Dimensions Dimension tolerance +/- 3% 4.53 0.50 14‘ 10“ 1‘8“ Inflatable tube diameter 4.00 4.32 Without the inflatable tube 13‘ 1“ 14‘2“ 2.04 1.45 6‘ 8“ 4‘ 9’’ 1.00 1,08 3‘...
Page 4 DESCRIPTION - Technical characteristics eJET 450 : Seating area for category C Seating area for category C Seat with handholds WARNING!!! DO NOT EXCEED THE MAXIMUM NUMBER OF PEOPLE RECOMMENDED. NO MATTER HOW MANY PEOPLE ARE ON BOARD, THE TOTAL WEIGHT OF PASSENGERS AND EQUIPMENT MUST NEVER EXCEED THE MAXIMUM RECOMMENDED LOAD.
Page 5 DESCRIPTION - Technical characteristics eJET 450 : Engine, battery and charger characteristics Engine configuration TORQEEDO Deep blue DB 80i-1600 rpm Continuous shaft Power Equivalent motor power Operating temperature range °C -30 / +120 Battery configuration BMW i3 high-voltage battery Technology...
Page 6: Inventory And Location
DESCRIPTION - Inventory and location I-2 INVENTORY AND LOCATION 14 15 16 Page 6 / 47...
Page 7 DESCRIPTION - Inventory and location Ref. DESCRIPTION Hydrojet Polyester hull with counter-moulded deck Ski mast Rear navigation light Rear chest Cup holders Maintenance hatch : access for authorized personnel only Console Side handles Navigation lights 4 lifting points (1 rear, 2 side, 1 front) Bilge fan Inside the deck Inflation/deflation valves (2 rear, 3 front)
Page 8 DESCRIPTION - Inventory and location HYDROJET TUNNEL DETAILS Ref. DESCRIPTION Rear plate Anode Bilge pump outlet Steering cable Reverser actuator Battery exhaust outlet Cooling water outlet Page 8 / 47...
Page 9 DESCRIPTION - INVENTORY and location CONTROLS AND INSTRUMENTS REF. DESCRIPTION Torqeedo display, touchscreen Bilge fan switch Bilge pump switch Navigation lights switch Courtesy lights switch Glove compartment inside the compartment 12V plug and USB plug Key switch Remote throttle display Remote throttle Emergency stop switch Carbon steering wheel, steering cable...
Page 10 DESCRIPTION - INVENTORY and location TORQEEDO ELECTRICAL SYSTEM NOTE: Refer to Torqeedo’s user Manual for more information Ref. DESCRIPTION Shore power distribution S AC Charger Motor power electronics Deep Blue motor DB 80i BMW i3 high-voltage battery Battery cooling System management unit Motor cooling TORQEEDO CONTROL SYSTEM Ref.
Page 11 DESCRIPTION - INVENTORY and location PROPULSION SYSTEM Ref. DESCRIPTION Thrust reverser flap and actuator Stator Reverser actuator Maintenance hydrojet hatch Hydrojet shaft Water intake Transmission belt Page 11 / 47 Edition 3...
Page 12: Handling
DESCRIPTION - Handling I-3 HANDLING I-3-1 Transport Trailer installation recommendations are specified in VOLUME I of the owner's manual. Use a trailer adapted to your boat. The boat is compatible with standard road gauge. It is designed to be transported inflated. The weight in transport conditions for a trailer includes: Unladen weight of the boat: 870 kg...
Page 13: I-3-2 Storage
DESCRIPTION - Handling I-3-2 Storage The steering wheel can be tilt down to optimise the height of the boat for storage. WARNING!!! THE BOAT MUST REST ON THE BOW LINE. SEE DIAGRAM BELOW. Page 13 / 47 Edition 3...
Page 14 DESCRIPTION - Handling Page 14 / 47...
Page 15: I-3-3 Lifting
DESCRIPTION - Handling I-3-3 Lifting The boat has 4 lifting points. Contact an AVON dealer to obtain the approved AVON lifting sling. WARNING USE ONLY THE AVON APPROVED LIFTING RINGS AND SLING TO LIFT THE BOAT. WARNING LIFTING MUST BE CARRIED OUT BY PROFESSIONALS. DANGER!!! NO PASSENGERS ON BOARD WHILE LIFTING.
Page 16: Maintenance Of The Inflatable Tube
INFLATABLE TUBE – Installing the inflatable tube on the hull II-1 MAINTENANCE OF THE INFLATABLE TUBE Your boat’s inflatable tube can be made from 2 different fabrics : • Carbon fabric : NEOPRENE CSM-CR 1670 Decitex fabric Or/and • Other : NEOPRENE CSM-CR 1100 Decitex fabric II-2 INSTALLING THE INFLATABLE TUBE ON THE HULL IF THE INFLATABLE TUBE WAS STORED AT A TEMPERATURE BELOW 0°C / 32°F, LEAVE IT AT 20°C / 68°F FOR 12 HOURS BEFORE UNFOLDING.
Page 17: Securing The Internal Protective Flap
INFLATABLE TUBE – Securing the internal protective flap II-3 SECURING THE INTERNAL PROTECTIVE FLAP Put the internal protective flap in place Set up the tube and fix the internal protective flap (tube deflated) by using the screws and nuts supplied with the tube kit. Apply sealing compound on all the screws and in the hull holes to achieve watertightness.
Page 18: Inflating The Inflatable Tube
INFLATABLE TUBE – Inflating the inflatable tube II-4 INFLATING THE INFLATABLE TUBE INFLATOR a. tube end b. adaptor c. tube base d. inflation port NOTE: An electrical (12 V) high output inflation pump is available as an option (contact your dealer). "EASY - PUSH"...
Page 19 INFLATABLE TUBE - Inflating the inflatable tube THE PRESSURE GAUGE WARNING!!! DO NOT USE A COMPRESSOR OR COMPRESSED AIR CYLINDER. INFLATION 1º/Place all valves in inflation position. 2º/ Fit the adaptor that matches the diameter of the "easy- push" valve to the inflation tube tip. 3º/ Attach the hose connector to the inflation pump.
Page 20: Pressure
INFLATABLE TUBE - Pressure b: 220 mb c: 240 b: 220 mb c: 240 mb NOTE: A slight loss of air is normal before the cap is screwed on. Only the plugs provide final airtightness. II-5 PRESSURE The inflatable tube has 5 compartments. Each must be inflated to a pressure of 240 mb / 3.4 PSI. It is the inflatable tube's correct pressure.
Page 21 SPECIAL CARE FOR HULL III- SPECIAL CARE FOR HULL The eJET450 is a GRP hull with a polyurethane coating finish. To prevent hull from gel coat blistering and to increase hull life, it is recommended you take the boat out of the water after each outing and you clean the bottom of the hull with fresh water. Once a month, it is recommended to clean the boat with neutral soap.
Page 22 INFLATABLE TUBE - Pressure RISK OF OVERPRESSURE Example: Your boat is inflated to its recommended pressure (240 mb/3.4 PSI) at the beginning or end of the day (low outside temperature = 10°C). Later in the day, your boat is left in the sun on the beach or on the deck of a boat.
Page 23: Iii- Inspection Before Use
INSPECTION BEFORE USE IV- INSPECTION BEFORE USE Check with your distributor /agent that your boat has been pre-inspected and examined in accordance with the manufacturer’s conditions. ITEM CHECK INFLATABLE TUBE (1) Pressure (240 mb) + valve plug cover in place BILGE (1) Absence of water 12V BATTERY (2)
Page 24: Iii-5 Thrust Reverser Flap
INSPECTION BEFORE USE – Thrust reverser flap IV-5 THRUST REVERSER FLAP Check the thrust reverser flap is operating properly by using the tilt buttons on the remote throttle. NOTE : see Torqeedo’s user Manual, chapter System Start. Press the tilt down button The thrust reverser flap moves down Press the tilt up button The thrust reverser flap moves up...
Page 25: Iii-8 Electricity
INSPECTION BEFORE USE - Electricity IV-8 ELECTRICITY Check that the navigation lights and fan operate. For the bilge pump, set the switch to automatic position, place your finger over the sensor (1) for several seconds to check the pump is activated correctly. Clean the intake strainer if necessary (2). IV-9 PROPULSION Carefully check the maintenance hydrojet hatch to make sure that there is no seaweed, debris or other...
Page 26: Starting A Trip
HOW TO DRIVE YOUR BOAT- Starting a trip V-1 STARTING A TRIP Before starting, refer to the Owner's Manual Volume I and to the Torqeedo’s user Manual. Check the thrust reverser flap is tilt up. Put the lanyard (1) on the switch (2) and then place Ventilate for 4 Battery switch set to ON the Emergency stop switch (2) on the RUN position...
Page 27: Motion Forward And Reverse
HOW TO DRIVE YOUR BOAT- Motion forward and reverse V-2 MOTION FORWARD AND REVERSE NOTE : see Torqeedo’s user Manual, chapter Motion forward/reverse. FORWARD Make sure the thrust reverser flap is up. Use the tilt up button on the Gradually operate the remote throttle forward throttle if necessary REVERSE Make sure the thrust reverser flap is...
Page 28: Braking
HOW TO DRIVE YOUR BOAT-Braking and end trip V-3 BRAKING The boat is not provided with a separate braking system. It stops under the resistance of the water when the lever is moving back to the neutral position. LEARN TO DETERMINE THE BRAKING DISTANCE NEEDED TO BRING THE BOAT TO A COMPLETE STOP.
Page 29: V- Charging The High-Voltage Battery
CHARGING THE HIGH-VOLTAGE BATTERY VI- CHARGING THE HIGH-VOLTAGE BATTERY An adapter cord 16A/250V Schuko/CEE and a shore power cable 16A/250V are supplied with the boat. NOTE : see Torqeedo’s user Manual, chapter Charging the high-voltage battery. Place the Emergency stop Connect the shore power Set the shore circuit breaker to switch (2) in the RUN position...
Page 30: High-Voltage System
INSTALLATION – High-voltage system VII-1 HIGH-VOLTAGE SYSTEM Ref. DESCRIPTION Shore power inlet (on the deck) Shore power distribution S AC Charger Motor power electronics Deep Blue motor DB 80i BMW i3 high-voltage battery Battery cooling System management unit Outlet venting DANGER!!! DANGER TO LIFE FROM ELECTRIC SHOCK.
Page 31: Electricity
INSTALLATION AND CIRCUIT - Electricity VII-2 ELECTRICITY VII -2-1 General wiring diagram The document is available in PDF format from your dealer. Page 31 / 47 Edition 3...
Page 32 INSTALLATION AND CIRCUIT - Electricity Ref. DESCRIPTION Bilge fan switch Bilge pump switch Navigation light switch Courtesy light switch Underwater lights switch (option) 12V plug (console) USB plug (console) Connected box (console) Reverser actuator Sound system with 2 speakers (option) White light Red / green lights Courtesy lights (deck)
Page 33: 2-2 General Wiring Plan
INSTALLATION AND CIRCUIT - Electricity VII -2-2 General wiring plan The document is available in PDF format from your dealer. 12 13 14 15 16 17 18 Page 33 / 47 Edition 3...
Page 34 INSTALLATION AND CIRCUIT - Electricity Page 34 / 47...
Page 35 INSTALLATION AND CIRCUIT - Electricity Ref. DESCRIPTION Port courtesy lights connection 12V battery connection Water pump connection (option) Bilge fan connection Underwater lights connection (option) Bilge pump connection Reverser actuator connection White light connection 12V Torqeedo’s system connection Circuit breaker connection Starboard courtesy lights connection 5A fuse (free for option) 1A fuse connected box...
Page 36: 2-3 Location Of Items
INSTALLATION AND CIRCUIT - Electricity VII -2-3 Location of items Ref. DESCRIPTION Circuit-breaker 12V battery VII -2-4 Circuit breaker When you stop using the boat, set the circuit-breaker to OFF. WARNING SWITCH OFF THE SYSTEM BEFORE SETTING THE CIRCUIT-BREAKER TO “OFF”...
Page 37: 2-5 12V Battery
INSTALLATION AND CIRCUIT - Electricity VII -2-5 12V battery The charge state of the 12V battery must be higher than 11V. MAINTAIN YOUR BATTERY: KEEP THE BATTERY CLEAN AND DRY IN ORDER TO AVOID PREMATURE WEAR. TIGHTEN AND MAINTAIN THE TERMINAL LUGS BY GREASING THEM REGULARLY WITH VASELINE.
Page 38: 2-6 Bilge Fan
INSTALLATION AND CIRCUIT - Electricity VII -2-6 Bilge fan Use this button to ventilate the battery compartment before starting. To do this, turn the circuit breaker to ON and ventilate 4 minutes. The LED ring turns blue when the switch is ON. VII -2-7 Navigation lights Press this button to switch on the navigation lights.
Page 39: Installation Of The Draining Systems
INSTALLATION AND CIRCUIT - Draining VII-3 INSTALLATION OF THE DRAINING SYSTEMS VII-3-1 Description of essential functional items Ref. DESCRIPTION Through-hull Bilge pump outlet Bilge pump Page 39 / 47 Edition 3...
Page 40: Vi-3-2 Through-Hull Draining Deck
INSTALLATION AND CIRCUIT - Draining VII-3-2 Through-hull draining deck The through-hull fittings mounted on the deck are equipped with a strainer (1) to protect draining deck from seaweeds and debris. REGULARLY CLEAN THE STRAINER FROM SEAWEEDS AND DEBRIS. Page 40 / 47...
Page 41: Vi-3-3 Bilge Pump
INSTALLATION AND CIRCUIT - Draining VII-3-3 Bilge pump The bilge pump is not wired to the battery switch and operates independently; the switch always connected. The switch controls the automatic and manual modes of the bilge pump.  Auto mode : when the LED ring is not lit up, the bilge pump works automatically. ...
Page 42: Steering
INSTALLATION AND CIRCUIT - Steering VII-4 STEERING Comply with the steering manufacturer's recommendations (installation, use and maintenance). To get the best out of your boat, please consult your dealer. VII-5 FIRE WARNING WE RECOMMEND YOU KEEP AN EXTINGUISHER ON BOARD AND COMPLY WITH THE LAWS APPLICABLE IN YOUR COUNTRY.
Page 43: Anchoring/Mooring
INSTALLATION AND CIRCUIT - Anchoring/mooring VII-6 ANCHORING/MOORING Ref. DESCRIPTION Pop up cleats Bow ring Anchor locker An anchor is supplied with the boat. WARNING FOR PERMANENT MOORING, USE THE BOW RING OR CLEAT. Page 43 / 47 Edition 3...
Page 44: Boarding
INSTALLATION AND CIRCUIT - Boarding VII-7 BOARDING DANGER!!! CHECK THAT THE SYSTEM IS SWITCHED OFF BEFORE ANYONE CLIMBS BACK ON BOARD USING THE REAR LADDER. Page 44 / 47...
Page 45: Vii-1 Position Of Stickers
LABELLING VIII-1 POSITION OF STICKERS Page 45 / 47 Edition 3...
Page 46: Vii-2 Description Of Labels
LABELLING VIII-2 DESCRIPTION OF LABELS Page 46 / 47...
Page 47: Viii- Troubleshooting
TROUBLESHOOTING IX- TROUBLESHOOTING NOTE : see Torqeedo’s user Manual, chapter Troubleshooting. ERROR CAUSE CHECKING/CORRECTION System display does not switch Circuit breaker is off Check the boat circuit breaker and on after turning the key switch switch it on if necessary. Battery charge is too low Check the charge state of the 12V battery.
