  • Page 1 BeneView T6/T8/T9 Patient Monitor Service Manual...
  • Page 3 Mindray, nor the rights of others. Mindray does not assume any liability arising out of any infringements of patents or other rights of third parties.
  • Page 4 Preface Manual Purpose This manual provides detailed information about the assembling, dissembling, testing and troubleshooting of the equipment to support effective troubleshooting and repair. It is not intended to be a comprehensive, in-depth explanation of the product architecture or technical implementation.
  • Page 5 User maintenance: 888888 (User adjustable) Factory maintenance: 332888 Demo mode: 2088 Configuration mode: 315666 (User adjustable) iView login: MINDRAY NOTE When log in iView system and input the password, connect the keyboard to the special USB connector for iView system.
  • Page 6 FOR YOUR NOTES...

  • Page 7: Table Of Contents

    Contents 1 Safety ..........................1-1 1.1 Safety Information ......................1-1 1.1.1 DANGER ......................1-2 1.1.2 Warnings......................1-2 1.1.3 Cautions ......................1-2 1.1.4 Notes ........................1-3 1.2 Equipment Symbols ......................1-3 2 Theory of Operation ......................2-1 2.1 Introduction........................2-1 2.2 System Connections ......................2-2 2.2.1 Mounting the Patient Monitor ................
  • Page 8 3.4.1 ECG Tests......................3-16 3.4.2 Resp Performance Test..................3-17 3.4.3 SpO Test......................3-18 3.4.4 NIBP Tests......................3-18 3.4.5 Temp Test ......................3-18 3.4.6 IBP Tests......................3-19 3.4.7 C.O. Test......................3-21 3.4.8 Mainstream CO Tests..................3-21 3.4.9 Sidestream and Microstream CO Module Tests..........
  • Page 9 4.2 Part Replacement ......................4-1 4.3 Patient Monitor Status Check..................4-1 4.4 Software Version Check ....................4-2 4.5 Technical Alarm Check ....................4-2 4.6 Troubleshooting Guide....................4-2 4.6.1 Power On/Off Failures ..................4-2 4.6.2 Display Failures ....................4-3 4.6.3 Module Rack Failures ..................4-4 4.6.4 Alarm Problems....................
  • Page 10 5.4.18 Removing the Recorder.................. 5-33 5.5 Removing the SMR Assembly ..................5-38 5.6 Disassembling Modules ....................5-42 5.6.1 Disassembling the ICG Module ............... 5-42 5.6.2 Disassembling CO Module ................5-46 5.6.3 Disassembling the BeneLink Module .............. 5-52 5.6.4 Disassembling the New MPM Module ............5-55 6 Parts ..........................
  • Page 11 7.1 Introduction........................7-1 7.2 Upgrading Parameter Modules..................7-2 7.3 Upgrading Functional Assemblies .................. 7-4 7.3.1 Upgrading SMR ....................7-4 7.3.2 Upgrading Wireless Network Function.............. 7-4 7.3.3 Upgrading Recorder ................... 7-5 7.3.4 Upgrading Analog Output .................. 7-5 7.3.5 Upgrading iView System ................... 7-5 7.4 Upgrading Software ......................
  • Page 12 FOR YOUR NOTES...

  • Page 13: Safety

    Safety 1.1 Safety Information DANGER Indicates an imminent hazard that, if not avoided, will result in death or serious injury. WARNING Indicates a potential hazard or unsafe practice that, if not avoided, could result in death or serious injury. CAUTION Indicates a potential hazard or unsafe practice that, if not avoided, could result in minor personal injury or product/property damage.

  • Page 14: Danger

    1.1.2 Warnings WARNING All installation operations, expansions, changes, modifications and repairs of this product are conducted by Mindray authorized personnel. There is high voltage inside the equipment. Never disassemble the equipment before it is disconnected from the AC power source.

  • Page 15: Notes

    1.1.4 Notes NOTE Refer to Operation Manual for detailed operation and other information. 1.2 Equipment Symbols Attention: Consult accompanying documents iView network connector (this manual). Danger: High-voltage Network connector Alternating current(AC) Defibrillator connector Connector for satellite Power ON/OFF module rack Battery indication Video output Zero key...
  • Page 16 FOR YOUR NOTES...

  • Page 17: Theory Of Operation

    Theory of Operation 2.1 Introduction This patient monitor is designed to monitor a fixed set of physiological parameters including ECG, heart rate (HR), respiration (Resp), temperature (Temp), SpO , pulse rate (PR), non-invasive blood pressure (NIBP), invasive blood pressure (IBP), cardiac output (C.O.), carbon dioxide (CO ), oxygen (O ), anesthetic gas (AG), impedance cardiograph (ICG),...

  • Page 18: System Connections

    2.2 System Connections 2.2.1 Mounting the Patient Monitor The patient monitor can be mounted on a wall bracket or on a trolley support. The wall bracket or trolley support can be ordered optionally. Each type of mounting bracket is delivered with a complete set of mounting hardware and instructions. Refer to the documentation delivered with the mounting hardware for instructions on assembling mounts.

  • Page 19: Connectors For Peripheral Devices

    2.2.2 Connectors for Peripheral Devices On the back of the patient monitor you will find all connectors for peripheral devices. AC Power Connector: used to connect an AC power source (100 to 240 VAC, 50/60Hz). Equipotential Terminal: used to connect the equipotential terminal of other equipment, eliminating potential difference between different pieces of equipment.

  • Page 20: Main Unit

    2.3 Main Unit The patient monitor consists of: Input system: button board, knob, touchscreen, power switch and LED board Output system: LCD panel, alarm LED board, recorder, speaker Processing and communications system: main board, iView assembly, integral module rack Power management system: battery, battery interface board, power module Equipment interface system: USB interface board, DVI interface board, CF card assembly and internal wireless network card.

  • Page 21: Input System

    2.3.1 Input System Button board The button board, located at the lower part of the monitor’s front panel, contains 6 keys and provides connections for the following components to the main board: Knob Power switch & LED board Touchscreen control board Backlight board/Inverter Alarm LED board The following diagram shows the button board connections.

  • Page 22: Output System

    2.3.2 Output System The patient monitor adopts a high-resolution LCD. The LCD is connected with the main board. Signals and power supply of the backlight board are transferred by the button board. Alarm Lamp The patient monitor has two alarm lamps: alarm lamp and technical alarm lamp. Alarm lamp lights either red or yellow whereas technical alarm lamp lights blue only.

  • Page 23: Processing And Communications System

    Module Description Power interface Introduces a DC from the main board. Converts the input power into voltages that fit each module and then Power module forwards them to each module. Control the communications between modules. Control the communications between the main board and the Signal interface recorder CPU.
  • Page 24 The CPU board is an essential CPU system containing the CPU, FLASH, memory, realtime clock, EEPROM, etc. It interfaces to the mother board only, which then provides interfaces to all other external devices. The mother board is in charge of connections and communications with other components and provides the following interfaces: LCD port: connects a built-in display.

  • Page 25: Power Management System

    Speaker port: connects the speaker. Power module port: connects the power module. iView port: located at the back of the mother board for connecting the iView components. CF port: connects the CF card assembly. Recorder port: connects the recorder. Internal wireless network card port: connects the internal wireless network card iView System iView sytem includes iView mother board, computer board, hard disk and so on.
  • Page 26 Battery Interface Board The battery interface board connects batteries to the power module, enabling charging and discharging between the batteries and the power board. Power Module The power module is located at the back of the patient monitor. The main part of the power module is the power board, which contains 4 PCBs: charging &...
  • Page 27 The following diagram shows the pins of the power module socket (excluding the pins of the battery power socket. On power board, pin 1 has a triangle symbol): Pin ID Marking Description Cable color 2, 4, 6, 7, The output grounding terminal of the power board. Black 13, 15, 17 Receives serial communications (the main board sends).
  • Page 28 Pin ID Marking Description Cable color The positive end of the 12 V DC coming from the power 12, 1 12 V Yellow board. The positive end of the 5 V CIS coming from the power 14, 3 5 V CIS Purple board.

  • Page 29: Equipment Interface System

    2.3.5 Equipment Interface System USB Interface Board The USB interface board is compatible with such USB interfaces as USB2.0, USB1.1 and USB1.0. It is connected with the main board and the power module. It receives USB differential signals coming from the main board and then distributes them to maximumly six USB interfaces via two ISP1521 chips.
  • Page 30 DVI Interface Board The DVI interface board is connected with the mother board and the iView mother board. The following diagram shows its interfaces to other components. Interface Description iView Connector Connects the iView mother board. BNC connector Outputs nurse call signals. Micro-D connector Outputs analog signals and defibrillator synchronization signals.

  • Page 31: Parameter Module

    2.4 Parameter Module Each parameter module consists of the module infrared communication board, module power board, module button board, parameter board, etc. 2.4.1 Module Infrared Communication Board The module infrared communication board allows a short delay when powering up the module and adopts FPGA to enable infrared communications between the module and the module rack.

  • Page 32: Satellite Module Rack

    2.5 Satellite Module Rack The satellite module rack (SMR) is independent of the patient monitor, provides 8 slots for mounting parameter modules. It has the following features: It allows a parameter module to be plugged and unplugged with the patient monitor on. This allows function extension and patient transfer.

  • Page 33: Benelink Module

    2.6 BeneLink Module BeneLink module allows the information (patient data, alarms, etc.) from the external device to be displayed, saved, recorded, printed, or calculated through a BeneView patient monitor. If the patient monitor is connected with the CMS or gateway, information from the external device can also be transmitted to the CMS or gateway.
  • Page 34 FOR YOUR NOTES 2-18...

  • Page 35: Testing And Maintenance

    Testing and Maintenance 3.1 Introduction To ensure the patient monitor always functions normally, qualified service personnel should perform regular inspection, maintenance and test. This chapter provides a checklist of the testing procedures for the patient monitor with recommended test equipment and frequency. The service personnel should perform the testing and maintenance procedures as required and use appropriate test equipment.

  • Page 36: Preventative Maintenance

    3.1.3 Preventative Maintenance Below are preventative maintenance tests which need to be performed on the monitor. See the following sections for detailed maintenance procedures. Visual inspection NIBP test and calibration Microsteam and Sidestram CO test and calibration AG test and calibration 3.1.4 Recommended Frequency Check/Maintenance Item Frequency...
  • Page 37 Pressure calibration C.O. test Mainstream CO test Leakage test Sidestream and Microstream Performance test tests Calibration Leakage test Performance test AG tests Calibration ICG test BIS test RM test Interconnecting CCO/SvO test function Output calibration Performance test NMT test Sensor check EEG test PiCCO test ScvO...

  • Page 38: Preventative Maintenance Procedures

    3.2 Preventative Maintenance Procedures 3.2.1 Visual Inspection Inspect the equipment for obvious signs of damage. The test is passed if the equipment has no obvious signs of damage. Follow these guidelines when inspecting the equipment: Carefully inspect the case, display screen, buttons and knob for obvious signs of damage.

  • Page 39: Nibp Tests

    3.2.2 NIBP Tests NIBP Accuracy Test Tools required: T-shape connector Appropriate tubing Balloon pump Rigid Vessel with volume 500 ± 25 ml Reference manometer (calibrated with accuracy equal to or greater than 1 mmHg) Follow this procedure to perform the test: Connect the equipment as shown below.
  • Page 40 NOTE You can use an NIBP simulator to replace the balloon pump and the reference manometer to perform the test. You can use an appropriate cylinder and a cuff instead of the rigid vessel. NIBP Leakage Test NOTE You should perform NIBP accuracy test and make sure the test result is pass prior to NIBP leakage test.

  • Page 41: Sidestream And Microstream Co 2 Module Tests

    You can either perform a manual leakage test: Perform procedures 1-4 in the NIBP Accuracy Test section. Raise the pressure in the rigid vessel to 250 mmHg with the balloon pump. Then, wait for 5 seconds to let the measured values becoming stable. 3.
  • Page 42 Accuracy Test Tools required: A steel gas cylinder with 6±0.05% CO and balance gas N T-shape connector Tubing Flowmeter Follow this procedure to perform the test: Plug the module into the module rack. Wait until the CO module warmup is finished, and check the airway for leakage and perform a leakage test as well to make sure the airway has no leakage.
  • Page 43 Calibration Tools required: A steel gas cylinder with 6±0.05% CO and balance gas N T-shape connector Tubing Flowmeter Follow this procedure to perform a calibration: Make sure that the sidestream or microstream CO module has been warmed up or started up. Check the airway for leakage and perform a leakage test as well to make sure the airway has no leakage.

  • Page 44: Ag Tests

    If the calibration is finished successfully, the message [Calibration Completed!] is displayed in the [Calibrate CO ] menu. If the calibration failed, the message [Calibration Failed!] is displayed. In this case, perform another calibration. 3.2.4 AG Tests AG Leakage Test The AG leakage test is required every time before the AG measurement.
  • Page 45 NOTE When testing a particular gas in a mixture, only the concentration of the gas to be " tested needs to meet the requirements. " Handle the gas cylinder by following the instructions on the gas cylinder. Follow this procedure to perform the test: Plug the AG module into the module rack.
  • Page 46 AG Calibration Tools required: ! Gas cylinder with a certain standard gas or standard gas mixture. Gas concentration should meet the following requirements respectively: AA≥1.5%, CO2≥1.5%, N2O≥40%, O2≥40%, of which AA represents an anaesthetic agent. The gas concentration accuracy should have a tolerance as follows: AA±0.15%, CO2±0.1%, N2O±1%, O2±1%. ! T-shape connector ! Tubing NOTE...
  • Page 47 In the [Calibrate AG] menu, the concentration of each measured gas and flow rate are displayed. If the difference between the measured gas concentration and the actual one is within the tolerances in the user manual, a calibration is not needed. If the difference for one gas composition or more gas compositions is outside of the stated tolerances, a calibration for one gas composition or more gas compositions should be performed.

  • Page 48: Preventative Maintenance Test Report

    3.2.5 Preventative maintenance test report Customer name Customer address Servicing person Servicing company Equipment under test (EUT) Model of EUT SN of EUT Hardware version Software version Test equipment Model/No. Effective date of calibration Test items Test records Test results (Pass/Fail) Visual inspection The case, display screen, buttons, knob, SMR, modules, power...
  • Page 49 Block the gas inlet of the module or watertrap. The sidestream flowrate is slower than 10ml/min and an alarm of CO Filterline Err is given. It indicates that there is no leakage. The displayed CO value is within 6±0.05％. Microstream CO test Block the gas inlet of the module or watertrap.

  • Page 50: Power On Test

    3.3 Power On Test This test is to verify that the patient monitor can power up correctly. The test is passed if the patient monitor starts up by following this procedure: Insert two batteries in the battery chamber and connect the patient monitor to the AC mains, the AC mains LED and battery LED light.

  • Page 51: Resp Performance Test

    ECG Calibration Tool required: Vernier caliper Follow this procedure to perform a calibration: Select the ECG parameter window or waveform area→ [Filter]→ [Diagnostic]. Select [Main Menu]→ [Maintenance>>]. Select [Calibrate ECG]. A square wave appears on the screen and the message [ECG Calibrating] is displayed.

  • Page 52: Spo 2 Test

    3.4.3 SpO Test Tool Required: None. Follow this procedure to perform the test: Connect SpO sensor to the SpO connector of the monitor. Set [Patient Cat.] to [Adu] and [PR Source] to SpO2 on the monitor. Measure SpO on your finger. (Assume that you stay healthy) Check the Pleth wave and PR reading on the screen and make sure that the displayed is within 95%-100%.

  • Page 53: Ibp Tests

    3.4.6 IBP Tests IBP Performance Test Tool required: Medsim300B patient simulator, MPS450, or other equivalent device Dedicated IBP adapter cable (300B, P/N 00-002199-00) (use P/N 00-002198-00, if the simulator is MPS450) Follow this procedure to perform the test: Connect the patient simulator with the pressure module. Make the patient simulator outputs 0 to each IBP channel.
  • Page 54 Select the [Calibrate] button next to the desired IBP channel to start a calibration. If the calibration is completed successfully, the message [Calibration Completed!] will be displayed. Otherwise, a corresponding message will be displayed. Method 2: Tools required: Standard sphygmomanometer Balloon pump Tubing T-shape connector...

  • Page 55: Test

    3.4.7 C.O. Test Tools required: Medsim300B Patient simulator C.O. adapter box Follow this procedure to perform the test: Connect the patient simulator to the C.O. module using a C.O. main cable. Set the blood temperature (BT) to 37ºC on the patient simulator and check the temperature value is 37 ±...
  • Page 56 Blow to the CO sensor to generate a CO waveform and then place the sensor in the air. Check if the alarm message [CO Apnea] is displayed on the screen. Connect the test system as follows Indication of numbers in the figure above A steel gas cylinder with 6±0.05% CO Flowmeter 3-way valve (power supply controlled)

  • Page 57: Sidestream And Microstream Co

    3.4.9 Sidestream and Microstream CO Module Tests See section 3.2.3 Sidestream and Microstream CO Module Tests. 3.4.10 AG Tests See section 3.2.4 AG Tests. 3.4.11 ICG Test Tool required: ICG simulator (BZ-4575) Connect the ICG simulator and the patient monitor using standard ICG cable and sensor. Select [ICG setup]→...

  • Page 58: Bis Test

    3.4.12 BIS Test You can choose either of the following methods to perform the test: Method 1: Tools required: None. Connect the BIS sensor to a healthy, wide-awake adult as directed in the Operator’s Manual. Check the EEG wave and BIS numerics displayed on the screen and make sure the BIS value is within 80-100.

  • Page 59: Rm Test

    3.4.13 RM Test Tool required: Gas source Ventilator (calibrated) Artificial lung Pediatric/neonate flow sensor Monitor Artificial Ventilator lung Flow sensor Follow this procedure to perform the test: Connect the equipment as shown above. Make sure that the blue sensing tube on the flow sensor is connected with the artificial lung.

  • Page 60: Cco/Svo 2 Tests

    3.4.14 CCO/SvO Tests Interconnecting Function Tools required: None. Connect and set the patient monitor and Vigilance monitor per the procedures in the Operator’s Manual. Set the Vigilance monitor to Demo mode. Check that the CCO/SvO numerics displayed on the patient monitor and Vigilance monitor are consistent.

  • Page 61: Picco Tests

    3.4.15 PiCCO Tests Performance Test Tool required: Medsim300B patient simulator PiCCO IBP test cable (6800-J87) Follow this procedure to perform the test: Connect the patient simulator, the PiCCO IBP test cable and the PiCCO module. Let the patient simulator outputs 0 mmHg respectively to the pArt channel and the pCVP channel.
  • Page 62 Select [Main Menu]→[Maintenance >>]→[User Maintenance >>]→ [Cal. IBP Press. >>]. In the [Cal. IBP Press.] menu, set the calibration pressure to 200 mmHg. Select the [Calibrate] button next to the desired IBP channel to start a calibration. If the calibration is completed successfully, the message [Calibration Completed!] will be displayed.
  • Page 63 The message [Calibration Completed!] is displayed after a successful calibration. If the calibration failed, the prompt [Calibration Failed!] will be displayed. C.O. Test Tools required: Medsim300B Patient simulator, or equivalent equipment C.O. adapter box (for 300B) PiCCO test cable (PN: 040-001301-00) Follow this procedure to perform the test: Connect the patient simulator and the C.O.

  • Page 64: Scvo Tests

    3.4.16 ScvO Tests You can perform ScvO test by either of the following two methods: Method 1: Tools required: PC (installed OM_Simulation software, G-6800-S15) ScvO test cable (6800-J68) Connect the ScvO test cable to the ScvO module and the serial port on the PC respectively;...

  • Page 65: Nmt Tests

    3.4.17 NMT Tests NMT Performance Test Tool required: Resistance box Oscillograph (Agilent DSO6052A) Set up the resistance box: a. Set the resistance value to 1kOhm. b. Connect the stimulation electrodes to the two wiring terminals. Connect the oscillograph sensors to the NMT stimulation electrodes, making sure that each sensor and electrode connected have the same polarity.
  • Page 66 The test passes when the measurements are within the following ranges: Test items Measurements 【PK-PK】 54V - 66V 270μs - 330μs 【+Width】 Checking NMT Sensor Tools required: None Connect the patient monitor, NMT module, and NMT accessories. Select [Main Menu]→ [Maintenance >>]→ [User Maintenance >>]→ enter the required password→...

  • Page 67: Eeg Tests

    3.4.18 EEG tests Method 1 Tools required: EEG simulator (Nannini 169/1) Insert the EEG module into the module slot of the monitor. Connect the EEG module to the EEG simulator through the EEG patient cable. Select [EEG Setup]→ [Sensor Check] to perform a sensor check. Check that the result for each electrode is pass.

  • Page 68: Nurse Call Relay Performance Test

    3.5 Nurse Call Relay Performance Test Tools required: Multimeter Connect the nurse call cable to the Nurse Call Connector of the patient monitor. Enter Demo mode. Then, select [Main Menu]→ [Maintenance >>]→ [User Maintenance >>]→ enter the required password→ [Others >>]→ [Auxiliary Output]→...

  • Page 69: Touchscreen Calibration

    3.8 Touchscreen Calibration Tools required: None. Select the [Cal. Screen] QuickKey or select [Main Menu]→ [Maintenance >>]→ [User Maintenance >>]→ enter the required password→ [Cal. Touchscreen]. symbol will appear at different positions of the screen. Select, in turn, the central point of the symbol.

  • Page 70: Equipment Connection And Setup

    3.10.1 Equipment Connection and Setup Connect the patient monitor and network printer to a HUB using common network cables as follows: BeneView Network monitor printer Cable Cable Set IP address as follows: Select [Main Menu]→ [Maintenance >>]→ [User Maintenance >>]→ enter the required password→ [IP Address Setup >>] and set the IP address of the patient monitor in the same network segment with that of the network printer.

  • Page 71: Benelink Module Check

    3.11 BeneLink Module Check 3.11.1 Device Connection and Setup Tools required: External device (anesthesia machine, ventilator) ID adapter that maches the external device RJ45 connecting cable Serial port adapting cable that maching the external device Please refer to the following procedure to connect an external device: RJ45 Connecting ID Adapter BeneLink Module...
  • Page 72 Type of Serial Port Adapting External Device ID for ID adapter Cable No need to use the adapting cable: the ID adapter can be Mindray Wato 20/30/55/65 4D52B2AE plugged into the serial port of the external device directly. Newport E360 4E50B1B0 Type B SNDF：5042AFBE...

  • Page 73: Device Integration Function Test

    Type of Serial Port Adapting External Device ID for ID adapter Cable GS: no need to use the adapting cable: the ID adapter can be plugged into the serial port of the external device Drager Fabius GS/Plus/Trio 4446BBBA directly. Plus: type C Trio: type C Drager Primus 4450BBB0...
  • Page 74 External Device Setup Remark If you need to view the parameters of CO2、AG、BIS module in the anesthesia machine, select Mindray Wato 20/30/55/65 Not required. [Factory Mainenance>>] → [Function Configuration>>] → [Select Module] in standby mode and tick the corresponding module.
  • Page 75 External Device Setup Remark Protocol: Medibus Baud Rate: 19200 Draeger Evita 2 dura/ Evita Parity: even 4/ Evita XL Stop Bits: 1 Interval: ---( Evita 2 dura) The following information is for further reference: Baud Rate: 38400 bps Newport E360 Protocol: Newport Word Length: 8 bits Parity: NONE...
  • Page 76 External Device Setup Remark The following information is for further reference: Baud Rate: 19200 bps Ohmeda Avance/Aisys Not required. Word Length: 7 bits Parity: odd Stop Bits: 1 The following information is for further reference: Baud Rate: 19200 bps Ohmeda Aestiva 7100 Not required.

  • Page 77: Installation And Test Report

    3.11.3 Installation and Test Report Basic Information Hospital Department Serial number of ID Name of the external device adapter Type of serial port adapting ID of the external device cable Software version and other information of the external device Test Result Checking the connection （Yes/No）...

  • Page 78: Battery Check

    Other information 3.12 Battery Check Tools required: None. Function Test If the patient monitor is installed with batteries, remove the batteries first. Verify that the patient monitor works correctly when running powered form an AC source. Insert two batteries per the procedures provided in the Operator’s Manual. Remove the AC power cord and verify that the patient monitor still works correctly.

  • Page 79: Iview System Maintenance(For T8 And T9 Monitors Only)

    3.13 iView System Maintenance(for T8 and T9 monitors only) 3.13.1 Making USB Startup Disk Tools required: MakeUSB (PN: 110-002149-00) USB drive with capacity greater than 4G Insert the USB drive into PC. Run “prepareUSB.hta” file in the folder of MakeUSB. Select [Prepare Windows PE USB Flash Drive] in the drop-down list, and select [Next>].
  • Page 80 Select the drive label of the USB drive in the drop-down list, and configure [Format USB-drive？]. [Select Ghost Image file to use] is unselected by default. Then select [Next>]. Select [Prepare USB>] to start making the startup disk. The system selects [Full mode] and [Manual mode] by default.

  • Page 81: Restoring The System

    Select [Close] to finish. 3.13.2 Restoring the System Connecting the External USB Cable Connect the iView maintenance USB disk which stores the system image files and keyboard to the USB connectors special for iView maintenance. Setting BIOS Screen Start up the patient monitor and press [F2] key repeatedly on the keyboard. Select [Main Menu] →...
  • Page 82 Restoring the system To recover the iView system, operate according to the following steps: Start iView system, and press [F2] to enter BIOS. Select [Maintanence>>] → [User Maitanence >>] → enter the required password → [iView Maitanence>>]→ [iView Setup], and enter the following screen. Select [Boot] in the menu bar, and then select option of [1st Boot] in the submenu.
  • Page 83 3. Select [Save&Exit] in the menu bar. Then select the option of [Save Changes and Exit] in the submenu and press [Enter] key. After that, select [Yes] to exit. Insert the USB disk for iView maintanence (P/N: 115-017183-00) into the special USB connector for iView system on the back housing of BeneView T8.
  • Page 84 Click [File] as shown in the below figure, and then choose the image file path of the system. Click [OK]. Then select [Next]. 3-50...
  • Page 85 Select [Run>], and start to recover the system with image files. 3-51...
  • Page 86 The system recovery finishes. Click [OK], and then click [Reboot]. When the monitoring screen of BeneView T8 displays, remove iView maitanence USB disk. The system will restart and enter Windows 7 system. A prompt to actiavate WIN7 will display. Start the activation of Windows 7 system and enter the following screen. 3-52...

  • Page 87: Setting Automatic Login

    (the value is case sensitive). "AutoAdminLogon" = "1" "DefaultUserName" =“CIS" "DefaultPassword" =“MINDRAY" If some value entry does not exist of the above listed three items, you have to create a corresponding one: click the right button of mouse, select [New] → [String Value], and input the string as the name of the new value entry, also input the correct value.

  • Page 88: Factory Maintenance

    3.14 Factory Maintenance 3.14.1 Accessing Factory Maintenance Menu To access the factory maintenance menu, select [Main Menu]→ [Maintenance >>] → [Factory Maintenance]and then enter the required password. The [Factory Maintenance] menu is shown below. 3.14.2 Drawing Waves There are two methods to draw waves: Color and Mono. Color: selecting Color will have smoother waveforms.

  • Page 89: Software Version

    3.14.4 Software Version Selecting [Software Version] will show software version information. The [Software Version] menu is as follows: 3.14.5 Monitor Information Selecting [Monitor Information] will show the status of the patient monitor. Monitor information is displayed as follows: 3-55...
  • Page 90 Maintenance and Test Report (See the above sections for detailed test procedures and contents) Customer name Customer address Servicing person Servicing company Equipment under test (EUT) Model of EUT SN of EUT Hardware version Software version Test equipment Model/No. Effective date of calibration Test Test items Test records...
  • Page 91 ECG performance test ECG waves are displayed correctly without noise and the HR value is within 80±1 bpm. ECG Lead Off alarm behaves correctly. Paced signals are detected and pace pulse marks are displayed when [Paced] is set to [Yes] The difference between the amplitude of the ECG calibration square wave and that of the wave scale is not greater than 5%.
  • Page 92 Sidestream CO test Block the gas inlet of the module or watertrap. The sidestream flowrate is slower than 10ml/min and an alarm of CO Filterline Err is given. It indicates that there is no leakage. The displayed CO value is within 6±0.05％. Miscrostream CO test Block the gas inlet of the module or watertrap.
  • Page 93 The amplitude of electrical level at the signal output port of MAP, CVP and SpO are 5±0.25V, 5±0.25V and 10±0.5V respectively. PiCCO test The detected catheter type accords with the setting of the Pulsion Calbox, and the measurement errors of TB and TI are within ±0.1℃.
  • Page 94 Set the recorder to some problems such as out of paper, paper jam, etc. the monitor gives corresponding prompt messages. After the problem is removed, the recorder is able to work correctly. Automatic alarm recording for each parameter functions correctly when parameter alarms occur. Network print test The network printer can print out ECG reports correctly.

  • Page 95: Troubleshooting

    Troubleshooting 4.1 Introduction In this chapter, patient monitor problems are listed along with possible causes and recommended corrective actions. Refer to the tables to check the patient monitor, identify and eliminate the troubles. The troubles we list here are frequently arisen difficulties and the actions we recommend can correct most problems, but not all of them.

  • Page 96: Software Version Check

    4.4 Software Version Check Some troubleshooting tasks may require you to identify the configuration and software version of your patient monitor. To view information on the system configuration and system software version, Select [Main Menu]→[Maintenance>>]→[Software Version>>]. You can also view the information on system software version and module software version by selecting [Main Menu]→[Maintenance>>]→[Factory Maintenance>>]→...

  • Page 97: Display Failures

    4.6.2 Display Failures Symptoms Possible Cause Corrective Action Integrated display Cables defective or 1. Check that cables from the display to the mother is blank but the poorly connected. board and from the backlight board to the button patient monitor board/display are correctly connected.

  • Page 98: Module Rack Failures

    Cables defective or 1. Check that the cables from the touchscreen to the poorly connected. touchscreen control board, the touchscreen control board to the button board, and the button board to the mother board are correctly connected. 2. Check that the cables and connectors are properly connected Touchscreen control Replace the touchscreen control board...
  • Page 99 Power supply failure 1. Check if the voltage between two contact screws in any slot reaches 12V DC. If yes and the parameter module functions, the PCB assembly in SRM might fail. 2. If there is no 12 V sent to the SMR, check that the power module output voltage to the USB interface board reaches 12V.

  • Page 100: Alarm Problems

    Power supply to integral 1. Check if voltage between two contact screws in module rack abnormal any slot reaches 12VDC. If yes and the parameter module functions, PCB assembly in the SMR might fail. 2. If there is no 12V sent to the integrated module rack, check that power module output voltage to mother board reaches 12V DC.

  • Page 101: Button And Knob Failures

    4.6.5 Button and Knob Failures Symptoms Possible Cause Corrective Action Buttons do Cable defective or 1. Check that cable between button board and mother not work poorly connected board is properly connected. 2. Check that connecting cables and connectors are not damaged.

  • Page 102: Interface Failures

    4.6.7 Interface Failures Symptoms Possible Cause Corrective Action No analog signals or Respective output 1. Select [Main Menu]→[Analog Output nurse call signals are disabled Setup]→set [Analog Output] to [On]. issued DVI interface board 1. Check that cable between DVI interface cable loose board and mother board is properly connected.

  • Page 103: Cf Card Problems

    4.6.8 CF Card Problems Symptoms Possible Cause Corrective Action CF card malfunctions Wrong CF card or small Use only SanDisk-manufactured CF storage memory space cards. Those with 4GB memory space are recommended. CF card full; data error; Format CF card on PC. CF card error CF card failure Replace the CF card.
  • Page 104 Cable defective or 1. Check that cable between battery interface poorly connected board and power module is correctly connected. 2. Check that cables and connectors are not damaged. Power board failure Replace power board No +3.3 V output Power supply protection 1.

  • Page 105: Network Related Problems

    4.6.10 Network Related Problems Symptoms Possible Cause Corrective Action The patient monitor No connection to LAN 1. Check that the cables and connectors are in cannot be connected to good condition and that the network is iView system. correctly connected. 2.

  • Page 106: Software Upgrade Problems

    4.6.11 Software Upgrade Problems Symptoms Possible Cause Corrective Action Boot file upgrade fails Power failure or Return the CPU board to factory for repair. unintended power off during boot file upgrade Program upgrade fails Incorrect network 1. Check that network connector, not iView connection network connector, on the patient monitor is used.

  • Page 107: Device Integration Failures

    4.6.14 Device Integration Failures Symptoms Possible Cause Corrective Action 1. Replace the ID adapter. 2. Upgrade the ID adapter in [Factory The ID adapter is not Maintenance] menu to make the ID adapter compatible with the match the corresponding external device. See external device.
  • Page 108 FOR YOUR NOTES 4-14...

  • Page 109: Repair And Disassembly

    Repair and Disassembly 5.1 Tools During disassembly and replacing, the following tools may be required: Phillips screwdrivers Small flat-bladed screwdrivers Contact spanner Tweezers Sharp nose pliers Sleeve 5.2 Preparations for Disassembly Before disassembling the monitor, finish the following preparations: Stop monitoring the patient, turn off the monitor and disconnect all the accessories and peripheral devices.

  • Page 110: Basic Disassembly

    5.3 Basic Disassembly 5.3.1 Disconnecting the Base NOTE Be sure to disassemble the base first before proceeding with other parts. Be sure to place the monitor face up when disassembling it. If lay the monitor face down, be sure the surface is non-abrasive and static-free. Otherwise, the screen or the knob may be scratched or damaged.
  • Page 111 Pull out the base and then unplug the two cables marked in the picture, one connecting the Power Switch & LED board and the button board, and the other connecting the battery interface board and the power supply assembly. NOTE Exercise care when pulling the base out.

  • Page 112: Separating The Front And Rear Half Of The Monitor

    5.3.2 Separating the Front and Rear Half of the Monitor Keep the monitor (without the base) face up. Disconnect the cables marked in the picture, one connecting the LCD panel and the mother board, and the other connecting the button board and the mother board. NOTE Release the clip before disconnecting the cable between the button board and the mother board.
  • Page 113 Avoid pressing the knob on the table. NOTE Press the cover with a thumb when prying it. Avoid pressing the knob on the table. Lift the rear cover assembly to separate it from the front cover assembly. （T6/T8 front housing assembly） （T9 front housing assembly）...
  • Page 114 (Rear housing assembly) For T9 monitor, unscrew the four M3×6 screws and lift the middle frame upward to separate the front housing assembly from the middle frame.

  • Page 115: Further Disassembly

    5.4 Further Disassembly 5.4.1 Removing the Power Switch & LED Board Locate the cable marked in the picture and disconnect it from the power switch & LED board. Left Clip Right Clip Release the clips with fingers. At the same time pinch the power switch & LED board, push it to the left and take it out along with the power switch.

  • Page 116: Disconnecting The Encoder Assembly

    5.4.2 Disconnecting the Encoder Assembly Disconnect the cable that connects the knob encoder and the button board. Then unscrew the two M3×6 screws and take out the encoder assembly. (T6/T8) (T9) 5.4.3 Removing the Button Board Disconnect the cables from the button board to the power switch & LED board, knob encoder, alarm LED board, backlight board and, touchscreen control board and the mother board.

  • Page 117: Removing The Touchscreen Control Board

    Remove the grounding spring and then unscrew the three PT3×8 screws and take out the button board. NOTE Do not forget the grounding spring when reassembling. 5.4.4 Removing the Touchscreen Control Board Unplug the touchscreen cable and the cable from the button board to the touchscreen control board.

  • Page 118: Removing The Inverter Of T6 And T8

    5.4.5 Removing the Inverter of T6 and T8 Unscrew the six M3×6 screws and remove the inverter shield. Unplug the cables respectively from the button board and the LCD to the inverter. Then, unscrew the two M3×6 screws to remove the inverter. Heat-conductive insulator NOTE Release the clip (if any) before disconnecting the cable between the LCD and the...

  • Page 119: Removing The Backlight Board Of T9

    5.4.6 Removing the Backlight Board of T9 Disconnect the cable between the backlight board and the LCD screen. Unscrew the two M3 ×6 screws to remove the backlight board. 5-11...

  • Page 120: Removing The Lcd Screen

    5.4.7 Removing the LCD Screen CAUTION Do not touch the LCD screen. Disassemble the LCD screen in an environment as dust-free as possible. Unscrew the eight M3×6 screws of T6 or T8 monitor and take the screen assembly out carefully. To prevent the screen from being contaminated by dust, do not touch the screen. Unscrew the twelve M3×6 screws of T9 monitor and take the screen assembly out carefully.
  • Page 121 Do not touch the LCD panel Unscrew the four M3×6 screws and take out the LCD screen. Unscrew the four M3×6 screws and separate the LCD screen from the two supporters. 5-13...

  • Page 122: Removing The Alarm Lamp Board

    5.4.8 Removing the Alarm Lamp Board After removing the LCD panel, disconnect the cable that connects the alarm lamp board and the button board, and then remove the alarm lamp board on which there is no screw. NOTE Exercise care when removing the alarm lamp board because it may be adhered to the LCD assembly (as shown in the above figure).

  • Page 123: Removing The Wireless Ap

    5.4.9 Removing the Wireless AP 5.4.9.1 Removing the Internal Wireless AP Unplug the wireless AP cable from the main board. Then unscrew the three M3×6 screws and take out the wireless AP assembly. Unscrew the two M3×6 screws and then remove the wireless AP. 5-15...
  • Page 124 5.4.9.2 Removing the External Wireless AP Disconnect the network cable and the power cord Press the leaf on the fix board with forceps; push the AP and installation board upwards. Then remove the AP and installation board. Press the leaf with a forceps Installation board Unscrew the two M3×8 screws and take out the fix board.

  • Page 125: Removing The Cf Assembly

    5.4.10 Removing the CF Assembly Disconnect the cable between the CF driving board and main board. Unscrew the two M3×6 screws and take out the CF assembly. Unscrew the two M3×6 screws and take out the CF driving board. 5-17...

  • Page 126: Removing The Main Board

    5.4.11 Removing the Main Board Pull out all the connectors on the mother board. There are numbers beside the connectors, which are listed below. Number Connected to Power module Speaker Integral module rack Button board DVI interface board LCD panel Recorder Wireless AP iView assembly...
  • Page 127 Unscrew the four M3×6 screws as shown in the figure above and take out the main board that includes the mother board and the CPU board. Unscrew the four M2.5×6 screws and separate the mother board from the CPU board. Be sure not to damage the socket that connects the two boards.

  • Page 128: Removing The Fan

    5.4.12 Removing the Fan Disconnect the connector that connects the fan and the mother board. Then unscrew the three M3×6 screws and remove the fan. 5.4.13 Removing the Speaker Disconnect the connector that connects the speaker and the mother board. Then unscrew the two M3×6 screws and remove the speaker.

  • Page 129: Removing The Interface Board Assembly

    5.4.14 Removing the Interface Board Assembly Unscrew the four M3×6 screws and remove the interface board assembly. Unscrew the screws beside the DVI socket and micro-D socket. Then unscrew the two M3×6 screws in the holes. After that, pull out the DVI interface board. Screws beside micro-D socket Screws beside DVI socket Two M3×6 Screws in Holes...

  • Page 130: Removing The Iview Assembly (For T8 And T9 Monitor Only)

    Unscrew the two M3×6 screws and take out the USB interface board upwards. NOTE Before removing the USB interface board, the DVI interface board must be removed first. Be careful not to damage the insulation between the DVI interface board and the USB interface board.
  • Page 131 Remove the SSD hard disk and battery from assembly Unscrew the four pan head cross recessed screws and remove the cooling fin in the industrial control board. Pan head cross recessed 5-23...
  • Page 132 Seperate industrial control board from mother board. Remove the heat conductive glue on the mother board. Mother board Industrial control board Heat-conductive glue NOTE Take care of the heat-conductive glue which lies between the industrial control board and the CIS mother board. Make sure the heat-conductive glue is coated before reinstallation.

  • Page 133: Removing The Power Supply Assembly

    5.4.16 Removing the Power Supply Assembly Disconnect the four cables which connect to main control board, iView assembly, DVI interface board and battery interface board from the socket of the power supply assembly. NOTE For some cables, you have to release the clips on it before disconnecting them. Unscrew the two M4×20 screws.
  • Page 134 Lift the power supply assembly slightly to separate it from the two shafts on the rear cover and then remove the assembly. Shafts 5-26...
  • Page 135 Unscrew the two M3×12 screws and remove the cover of the power supply. Unscrew the two M3×6 screws. pry out the board with a small flat-bladed screwdriver in the gap between the power supply board and the housing. Then turn the board over and unplug the cables from it.

  • Page 136: Removing The Integral Module Rack

    NOTE Because the power supply board may be adhered to the insulator, be careful not to damage the parts, connector and cables when prizing it. 5.4.17 Removing the Integral Module Rack The following disassembling procedure takes the 5-slot module rack as an example. You can disassemble other types of module rack by referring to this procedure.
  • Page 137 If the module rack still engages with the back cover, insert a small flat-bladed screwdriver into the position marked in the picture and pry it out about 1mm to release the hidden snap between the integral module rack and the back cover. Then pull out the module rack.
  • Page 138 MPM Communication Board 3-slot module Rack Communication Board CAUTION Be sure to release the hidden snaps first when removing the integral module rack. Otherwise, the monitor will be damaged. 5-30...
  • Page 139 Release the three clips on the 3-slot module rack communication board and remove the Nios II module. Nios II module Unscrew the four M3×6 screws and take out the 3-slot module rack communication board. Unscrew the four M3×6 screws and take out the MPM Communication Board. MPM Communication Board 3-slot module Rack Communication Board 5-31...
  • Page 140 Unscrew the hex nut assy using the sleeve. Then separate the washer, spring and contact screw from each other. Contact screw Leaf M3 nut φ3 flexible washer φ3 flat washer 5-32...

  • Page 141: Removing The Recorder

    5.4.18 Removing the Recorder Open the recorder door and unscrew the two M3×6 screws. Pull the two clips in the directions as indicated and meanwhile pull out the recorder. NOTE Be sure not to damage the connecting cables or connectors when pulling out the recorder.
  • Page 142 Unscrew the M3×6 screw and remove the cables marked in the picture. Unclench the two clips and meanwhile take out the recorder drive board. Pay attention to the snap in the front. Snap 5-34...
  • Page 143 Pull out the press bar upwards about 1mm and then pull off the flexible cable. Remove the cable that connects the drive board and the button board. Unscrew the PT2×6 screw and remove the drive board’s grounding cable. Then take out the recorder drive board. Press bar 5-35...
  • Page 144 Unscrew the two PT2×6 screws and take out the thermal printhead. Then unscrew the two PT2×6 screws and remove the recorder’s button board. Remove the recorder mounting bracket by pulling out the recorder mounting bracket from the right side first. Recorder mounting bracket 5-36...
  • Page 145 Hold and then pinch the recorder housing so that the recorder housing becomes disengaged from the monitor housing. Then take out the recorder housing. NOTE When pinching the recorder housing, take care not to damage the recorder housing. When reassembling the recorder housing and the recorder mounting bracket, install the recorder mounting bracket first and meanwhile be sure the two clips are in right position.

  • Page 146: Removing The Smr Assembly

    5.5 Removing the SMR Assembly First remove the 4 screw covers and then unscrew the 4 M3×8 screws. Right-side board Left board Pull off the left- and right-side boards. Be sure to place the rubber loop in position when reassembling the right board. 5-38...
  • Page 147 From the left side, remove the cable that connects the module rack interface board and the 8-slot module rack communication board. Then take off the SMR cover. Unclench the two clips and take out the module rack interface board. Be sure not to damage the snap slot on the left side.
  • Page 148 Unclench the clips and take out the Nios II module. Then unscrew the six M3×6 screws and remove the 8-slot module rack communication board. 5-40...
  • Page 149 Use the sleeve to unscrew the hexagon nut and countersunk external toothed lock washer assembly which can be further separated into the washer, springlet and contact screw. Springlet Washer Hexagon nut and countersunk Contact screw external toothed lock washer assembly 5-41...

  • Page 150: Disassembling Modules

    5.6 Disassembling Modules WARNING For a reassembled module, a patient leakage current test must be performed before it is used again for patient monitoring. Make sure the monitor is off before disassembling the modules. The monitor supports three types of modules, single-slot modules, 2-slot modules and 3-slot modules.
  • Page 151 Move the snap lock in front of the contact spanner to the unlocking position. Insert a small flat-bladed screwdriver into the hole on the snap lock and press the snap down about 1mm. At the same time, push the snap lock forwards with a thumb until the snap lock and its counterpart separate.
  • Page 152 Press the two clips about 1mm and take off the housing. The side cover of the module without the housing is composed of two halves. Release the three snaps to separate the two halves. 5-44...
  • Page 153 Take out the non-insulated power board and disconnect all the cables from it. Take out the infrared communication board and disconnect all the cables from it. Disconnect all the cables on the ICG board and take off it with the front cover. 5-45...

  • Page 154: Disassembling Co Module

    5.6.2 Disassembling CO Module Remove the four contact screws on the back and two snap locks on the bottom and then unscrew the two M3×6 screws by referring to the procedure as described in 5.6.1 Disassembling the ICG Module . Take off the front cover of the CO module by referring to the procedure as described in 5.6.1 Disassembling the ICG Module.
  • Page 155 5-47...
  • Page 156 Hold the housing with both hands. Press the snap side with the thumb and move the other side with the index finger and the middle finger to separate the housing into two halves. 5-48...
  • Page 157 Take out the infrared communication board and disconnect all the cables from it. Disconnect the cables from the button board and unscrew the PT3×8 screw. Then release the two clips and take out the board. After that, disconnect the cable to the fan and remove the button board.
  • Page 158 Unscrew the two screws on the front panel. Disconnect the tubing between the watertrap assembly and CO parameter board. Disconnect the cable between the watertrap and parameter board. Then take out the watertrap connector assembly. 5-50...
  • Page 159 Disconnect the tubing between the CO parameter board and the front panel. Then release the four clips and remove the CO parameter board. NOTE When reinstalling, do not fold the tubings. 5-51...

  • Page 160: Disassembling The Benelink Module

    5.6.3 Disassembling the BeneLink Module Remove the contact screws, the spanner, and the front cover by referring to steps 1 to 3 as described in 5.6.1Disassembling the ICG Module . Take off the small cover board on one side of the rear cover. Then press the two clips about 1mm and take off the housing.
  • Page 161 Take off the cable between the USB board and the interface board. Take off the cable between the infrared communication board and the interface board to remove the infrared board. 5-53...
  • Page 162 Unclench the four clips with a tweezer to remove the interface board. 5-54...

  • Page 163: Disassembling The New Mpm Module

    5.6.4 Disassembling the New MPM Module Remove the contact screws and the spanner by referring to steps 1 to 3 as described in 5.6.1 Disassembling the ICG Module . Unscrew the two M3×6 screws. Then press down, in turn, the four clips that engage the front cover with a small flat-bladed screwdriver.
  • Page 164 Disconnect the cable of the infrared communication board, and release the snap lock to remove the infrared communication board. Snap lock Disconnect the cables of the NIBP inflation pump and the relief valves from the parameter board. Snip off the cable ties to remove the pump. Release the snap locks to remove the valves.
  • Page 165 Unscrew the two M3×8 screws on the parameter board. Then pull off the parameter board rightward as shown below. 5-57...
  • Page 166 Unscrew the two M3×4 screws on the SpO board to separate the SpO board and the parameter board. Unscrew the three M3×8 screws to separate the front panel assembly and the holder. 5-58...

  • Page 167: Parts

    Parts 6.1 Introduction This section contains the exploded views and parts lists of the main unit, satellite module rack and parameter modules of the patient monitor. It helps the engineer to identify the parts during disassembling the patient monitor and replacing the parts. Hardware architecture of the main unit is shown below:...

  • Page 168: Main Unit

    6.2 Main Unit (T6/T8） Exploded View Parts List Description Front housing assembly(17" LCD, anti-glare screen,T8） 6800-30-50479 or 6800-30-50480 Front housing assembly（17" LCD, touchscreen,T8) 6800-30-50936 or Front housing assembly(15”LCD, touch screen, T6) 6800-30-50937 Front housing assembly(15”LCD, Anti-glare Screen, T6) M6G-020015--- Hose, 0.47 m 6800-30-50637 Rear housing assembly M04-004017---...

  • Page 169: Main Unit (T9)

    6.3 Main Unit (T9) Exploded View Parts List Description 115-022476-00 Front housing assembly (T9) M6G-020015--- Hose, 0.47 m 6800-30-50637 Rear housing assembly M04-004017--- Crosshead screw M3×12 043-004044-00 Screw cap M04-005405--- Crosshead screw 6800-30-50468 Base assembly...

  • Page 170: Base Assembly

    6.4 Base Assembly Exploded View Parts List Description 6800-20-50183 or Battery cover L 043-004072-00 6800-20-50386 Battery cover spacer 6800-20-50181-51 Bottom cover (T8) or 043-004135-00 M04-004012--- Crosshead screw M3×6 6800-20-50212 Base support 6800-30-50108 Battery interface board 6800-20-50201-51 Power switch (T8) 6800-30-50088 Power switch board M05-010002-06 Lithium battery, 1.1 V, 4500 mAh...

  • Page 171: Front Housing Assembly

    6.5 Front housing Assembly 6.5.1 17” LCD with Anti-glare Screen Exploded View Parts List Description 043-000484-00 or Front housing (T8) 043-000484-01 6800-20-50199 Alarm LED cover 6800-20-50390 Light conduction block 2 6800-20-50389 Light conduction block 1 6800-30-50086 Alarm LED board 6800-20-50691 Insulating strip for alarm LED board...
  • Page 172 Description 6800-20-50220 PC cusion 1 6800-20-50221 PC cusion 2 6800-20-50228 Dust-proof pad 7 6800-20-50227 Dust-proof pad 6 6800-20-50207 Screen support 4(for 17” anit-glare screen) M04-004012--- Crosshead screw M3×6 6800-20-50232 Backlight board insulating sheet M04-002505--- Crosshead screw M3×6 6800-20-50671 Backlight board shielded cover 6800-20-50692 Backlight board insulating sheet 0000-10-11072...

  • Page 173: 15" Lcd With Anti-Glare Screen

    6.5.2 15” LCD with Anti-glare Screen Exploded View Parts List Description 043-000483-00 or Front bezel (T6) 043-000483-01 6800-20-50199 Alarm LED cover 6800-20-50390 Light conduction block 2 6800-20-50389 Light conduction block 1 6800-30-50086 Alarm LED board 6800-20-50691 Insulating strip for alarm LED board 6800-20-50220 PC cusion 1 6800-20-50221...
  • Page 174 Description 6800-20-50687 Dust-proof pad 10 6800-20-50211 Screen support 8 M04-004012--- Crosshead screw M3×6 6800-20-50232 Backlight board insulator M04-002505--- Crosshead screw M3×6 6800-20-50671 Backlight board shield 6800-20-50692 Backlight board insulating sheet 0000-10-10750 or Backlight board 0000-10-11073 (Optional) 9901-10-23920 Conducting foam.0501080 0000-10-10996 Berylium &...

  • Page 175: 19" Lcd Touchscreen

    6.5.3 19” LCD Touchscreen Exploded View Parts List Description 043-003550-00 Middle frame(T9) 051-001516-00 LED backlight adapter board 0000-10-10996 Leaf, 92-047 042-009881-00 Bracket (19”) 021-000137-00 LCD screen, TFT,19" 042-009883-00 19"right fix ing bracket M04-003105--- Tapping screw PT3×8 6800-30-50084 Button board 042-000693-00 Knob mounting plate 0000-10-10789 Optical encoder...
  • Page 176 Description 6800-20-50691 Insulating strip for alarm LED board 6800-30-50086 Alarm LED board 6800-20-50389 Light conduction block 1 6800-20-50199 Alarm LED cover 6800-20-50390 Light conduction block 2 043-003871-00 Front bezel (T9) 048-003353-00 Touchscreen waterproof strip 2 048-003352-00 Touchscreen waterproof strip 1 021-000135-00 Touchscreen, resistance-type, 19″...

  • Page 177: 17" Lcd Touchscreen

    6.5.4 17” LCD Touchscreen Exploded View Parts List Description 043-000484-00 or Front bezel (T8) 043-000484-01 6800-20-50199 Alarm LED cover 6800-20-50390 Light conducting block2 6800-20-50389 Light conducting block1 6800-30-50086 Indicator board 6800-20-50691 Insulating strip for alarm LED board 6800-20-50222 Dust-proof pad 1 6800-20-50223 Dust-proof pad 2 0000-10-11071 or...
  • Page 178 Description 6800-20-50226 Dust-proof pad 5 6800-20-50205 Screen support 2(for 17” touchscreen) 6800-20-50232 Backlight board M04-004012--- Crosshead screw M3×6 0000-10-11072 Backlight board M04-002505--- Crosshead screw M3×6 6800-20-50692 Backlight board insulating sheet 6800-20-50671 Backlight board shield 0000-10-10996 Berylium-bronze leaf 92-047 9901-10-23920 Conducting foam0501080 6800-30-50082 or Touchscreen control board 6800-30-51095...

  • Page 179: 15" Lcd Touchscreen

    6.5.5 15” LCD Touchscreen Exploded View Parts List Description 043-000483-00 or Front bezel (T6) 043-000483-01 6800-20-50199 Alarm LED cover 6800-20-50390 Light conducting block2 6800-20-50389 Light conducting block1 6800-30-50086 Alarm LED board 6800-20-50198 Silicon buttons 6800-20-50691 Insulating strip for alarm LED board 0000-10-10789 Optical Encoder 16 steps 5VDC Dip6 6800-20-50222...
  • Page 180 Description 6800-20-50686 Dust-proof pad 9 6800-20-50687 Dust-proof pad 10 6800-20-50239 Light shield 6800-20-50209 Screen support 6 M04-051001-01 Crosshead screw M3×4 6800-20-50232 Backlight board M04-004012--- Crosshead screw M3×6 6800-20-50692 Backlight board insulating sheet 6800-20-50671 Backlight board shield M04-002505--- Crosshead screw M3×6 0000-10-10750 or Backlight board 0000-10-11073（optional ）...

  • Page 181: Rear Housing Assembly

    6.6 Rear Housing Assembly 6.6.1 Rear Housing Assembly Exploded View Parts List Description TR6F-30-67306 TR6F recorder 115-001290-00 6800-20-50193 or Recorder chamber 043-004046-00 6800-20-50213 Recorder support rack 6800-20-50196 or CF card door 043-004075-00 6800-20-50185 or Handle cover 043-004073-00 043-000060-00 or Rear housing (new connector) 043-000060-01 6-15...
  • Page 182 Description M6G-020015--- Hose, 0.3m 6800-20-50234 Waterproof strip I 6800-30-50475 Power module assembly 6800-30-50469 Module rack (maximum configuration) 043-000561-00 or Grey USB cover 043-000561-01 043-000471-00 or CIS network port cover 043-000471-01 043-000470-00 or USB cover 043-000470-01 043-000469-00 or MiniDB9 cover (T8) 043-000469-01 6200-21-11629 Speaker...

  • Page 183: Power Module

    6.6.2 Power module Exploded View Parts List Description 0509-20-00098 Grounding terminal 9211-20-87369 Pothook for power supply plugs 6800-20-50197-51 Power module chamber (T8) or 044-000447-00 6800-20-50692 Backlight board insulating sheet 6800-20-50693 Backlight board insulating plate I, 100×27 mm M04-004017--- Philips pan head screw GB9074.5-88 M3×12 M04-021024--- Large washer class A GB/T96.1-2002 3 6800-20-50219...

  • Page 184: Integral Module Rack

    Description 009-000255-00 AC input connector and cable Stainless steel nut, hexagon GB/T6170-2000 M6 M04-004401--- polished M04-004504--- Spring washer M04-021003--- Flat washer 6.6.3 Integral Module Rack Exploded View Parts List Description 6800-20-50190 or Side plate, rear housing-ALL 043-004078-00 6800-20-50191 or Side plate small cover, rear housing -ALL 043-004042-00 M04-003105--- Tapping screw PT3×8...

  • Page 185: Interface Board Assembly

    Description M04-004012--- Philips pan head screw M3×6 6800-20-50233 Rubber feet 6800-30-50073 MPM module rack communication board Stainless steel hexagon nut GB/T6170-2000 M3 M04-000301--- polished Flat washer-grade A GB/T97.1-20023 nickel plated M04-000802--- to resist rust Standard spring washerGB/T93-1987 3 nickel M04-000104--- plated to resist rust 6800-20-50388 Leaf...
  • Page 186 Parts List Description 042-000055-00 T8 interface support (new interface) 051-000221-00 6800 DVI interface board (full configuration) 6800-20-50241 Interface board insulating plate 051-000222-00 6800 USB interface board (full configuration) 6800-20-50745 Waterproof strip M04-004012--- Screw, M3×6 M6T-030005--- Berilium & bronze leaf 187S30（4 leaves） M6T-030005--- Berilium &...

  • Page 187: Main Support Assembly (T8/T9)

    6.6.5 Main Support Assembly (T8/T9) Exploded View Parts List Description 6800-20-50215 Main support 6800-30-50509 Fan assembly 051-001300-00 6800 COME CIS Motherboard PCBA 023-000570-00 COM N2600 NM10 DDR3 onboard 2GB 023-000544-00 SSD 128GB MLC mSATA 1 (Optional) 047-009148-00 Thermal Pad/Chomerics/3.0/17*17*1 047-009104-00 Thermal Pad/Chomerics/3.0/23*15*1 045-000781-00 PC heatsink of iView...

  • Page 188: Main Support Assembly (T6)

    6.6.6 Main Support Assembly (T6) Exploded View Parts List Description 6800-20-50215 Main support 6800-30-50509 Fan assembly M04-004012--- Pan head screw with washer, M3×6 6-22...

  • Page 189: Main Control Board Assembly

    6.6.7 Main Control Board Assembly Exploded View Parts List Description M04-051045--- Cross head screw M2.5×6 051-000220-00 or 6800 mother board (full configuration) 051-000220-01 6800 mother board (standard configuration) M04-060021--- Stud M2.5x7+6-6 6800-30-50058 or MCF547x CPU module (basic configuration/lead-free) 6812-30-66989 M04-011001--- Nut GB6170 M2.5 6-23...

  • Page 190: 6800 Wireless Ap Kit (Asus)

    6.6.8 6800 Wireless AP Kit (ASUS) Exploded View Parts List Description 042-000599-00 T8 wireless AP mounting support 047-008023-00 Thermal pad for wireless card 023-000505-00 Wireless router 150Mbps Wi-Fi 042-007523-00 Cover for wireless LAN (T8) M04-004012--- Cross pan head screw with washer M3×6 009-002895-00 Cable for AP wireless (6100) 6-24...

  • Page 191: Others

    6.6.9 Others Description iView assembly –115-016498-00 6800-20-50304 Ethernet cable for DVI interface board 051-001300-00 6800 COME iView Motherboard PCBA 023-000570-00 COM N2600 NM10 DDR3 onboard 2GB 023-000544-00 SSD 128GB MLC mSATA 047-009148-00 Thermal Pad /Chomerics/3.0/17*17*1 047-009104-00 Thermal Pad/Chomerics/3.0/23*15*1 045-000781-00 PC Heatsink of iView M04-051020--- Countersunk flat head screw, M2×10 M04-004012---...

  • Page 192: Smr Assembly

    TR6F-20-67305 Silicon button TR6F-20-67307 Overlay TR6F-20-67314 Cable from recorder drive board to recorder button board TR6F-20-67319 Overlay TR6F-30-67308 Recorder button board TR6F-30-67310 Recorder drive board 6101-20-46746 Grounding wire (6101) 043-001269-00 Recorder chamber (DPM) 043-001273-00 Spanner (DPM) 6.7 SMR Assembly 6.7.1 SMR Assembly Exploded View 6-26...
  • Page 193 Parts List Description 6800-20-50249-51 or 6800-20-50249-52 or Inside assembly 043-004118-00 or 043-004119-00 M6G-020015--- Hose 6800-30-51154 Interface board 6800-20-50250 or Rear housing 043-004120-00 6800-20-50254 or Side plate fixture 043-004054-00 M04-004015--- Crosshead screw M3×8 6800-20-50308 or Screw cap 2 049-000650-00 6800-20-50253 or Side plate, right 043-004053-00 6800-20-50262 or...

  • Page 194: Smr Inside Assembly

    6.7.2 SMR Inside Assembly Exploded View Parts List Description 6800-20-50519 Insulating plate 9201-20-36010 Torsion spring washer 6800-20-50256 Light conducting pole 6800-20-50261 Contact spring 6800-21-51100 Contact screw 6800-20-50279 Infrared light filter 6800-20-50249 or SMR inside assembly 043-004118-00 6800-20-50388 Leaf M04-021024--- Washer M04-011002--- Hex nut assy 6-28...

  • Page 195: Parameter Modules

    Description 6800-20-50257-51 Reinforced section steel 6800-30-51153 8-slot module rack communication board M04-004306--- stub screw M3X16+8-8 6800-20-50233 Rubber feet M04-000104--- spring washer GB93 3 M04-004012--- Crosshead screw M3×6 M04-000306--- stud screw M3X10+8-8, coated with antirust nickel 6800-30-50075 Nios II module 6.8 Parameter Modules 6.8.1 MPM Module Exploded View 6-29...
  • Page 196 Parts List Description 6800-20-50278 or Spanner 043-004037-00 6800-20-50293 Screw 6800-20-50279 Infrared light filter M04-000104--- Spring washer 6800-20-50273 or Rear cover 043-004031-00 6800-20-50339 Waterproof seal 02 6800-30-50684 MPM module infrared communication backboard 6800-20-50275 or Right cover 043-004033-00 M51A-30-80924 NIBP&MPM analog module M51A-30-80870 MPM front panel assembly M04-005005---...

  • Page 197: New Mpm Module

    6.8.2 New MPM Module New MPM module applies the integrative parameter board (ECG ASIC). Exploded View 6-31...
  • Page 198 Cross pan head screw with washer M3×8 043-001964-00 or Holder 043-001964-01 115-011209-00 New MPM front panel assembly, Mindray SpO 115-011210-00 New MPM front panel assembly, Nellcor SpO New MPM front panel assembly, Masimo2013 15-011211-00 New MPM front panel assembly, Mindray SpO...

  • Page 199: Remote Display Box

    Description As configured New M51A Infrared communication board, no 115-011563-00 6800-20-50292 Fixer 801-6800-00211-00 NIBP pump for M51A and iPM S1-0103-00-0511 Tee connector, White, Nylon 0010-10-12408 Inline Filter 082-000098-00 630F Reducer 082-000864-00 Valve M04-005005--- Flat head screw, Phillips M3×6 6800-20-50278 or Spanner 043-004037-00 M04-000104---...
  • Page 200 Parts List Description M12A-20-75103 CIS lock catch M12A-20-75107 Lock catch spring M12A-21-75110 CIS bottom housing M6G-020015--- Silicone tube M04-011001--- Hex nut GB/T6170-2000M2.5 M04-060021--- Stud screw M2.5×7+6-6 M11A-30-75026 Remote display mother board M11A-30-75000 Equipment interface board M11A-20-75004-51 Remote display box rack M12A-30-75002 Indicator board M12A-20-75106...

  • Page 201: New Wireless Ap Package For 6800/6802

    6.10 New Wireless AP Package for 6800/6802 The new MPM module uses intergral parameter board (ECG ASIC). Exploded View Part List Description 042-007507-00 Wireless AP/CF card mount 023-000505-00 Wireless router 150Mbps Wi-Fi 042-007506-00 Mounting plate for wireless LAN (ASUS) Cross recessed small pan head screw with washer M04-004015- M3X8 9201-20-36109...

  • Page 202: Replaceable Parts

    6.11 Replaceable Parts To replace the parts, please refer to 5 Repair and Disassembly and the exploded views above. NOTE Here we list most replaceable parts. If you need more parts, please contact our Customer Service Department. 6.11.1 Main Unit Description Rear housing assembly 6800-20-50194 or...
  • Page 203 115-003227-00 6800-30-50509 Fan assembly 6800-20-50681 Speaker & cable 115-016498-00 iView assembly Front housing assembly (T9) 043-003550-00 Middle frame(T9) 051-001516-00 LED backlight adapter board 021-000137-00 LCD screen, TFT, 19＂ 6800-30-50084 Button board 043-003871-00 Front bezel(T9) 021-000135-00 Touchscreen, resistance-type, 19″ 6800-30-50082 Touchscreen control board 115-003711-00 Encoder assembly (Optical encoder) 6800-30-50086...

  • Page 204: Smr

    043-000483-00 or Front bezel (T6) 043-000483-01 0000-10-11071 or Touchscreen 0000-10-10748 (optional ) 6800-30-50082 Touchscreen control board Touchscreen control board（only used together 6800-30-51095(optional) with optional touchscreen 0000-10-10748） T6 button board(anti-glare/optical encoder) 115-004217-00 (without shank) T6 button board (touchscreen/optical encoder ) 115-004218-00 (without shank) 6800-30-50086 Alarm LED board...

  • Page 205: Parameter Modules

    6800-30-50486 BIS Module 6800-30-50488 RM module 6800-30-50487 CAPNOSTAT CO module 6800-30-50559 ORIDION CO module 6800-30-50500 Mindray sidestream CO module (M02B) 115-020189-00 Mindray sidestream CO module (M02C) 6800-30-50491 ICG module 6800-30-50501 AG module (with O /BIS) 6800-30-50502 AG module (with O...

  • Page 206: Cables

    New MPM6 module(Nellcor SpO /12lead) 115-010750-00 New MPM9 module(Nellcor SpO /3/5lead/no IBP) 115-010753-00 New MPM12 module(Nellcor SpO /12 lead) 115-010755-00 New MPM1 module(Mindray SpO /3/5lead) 115-010758-00 New MPM4 module(Mindray SpO /12lead) 115-010761-00 New MPM7 module(Mindray SpO /3/5lead/no IBP) 115-010764-00 New MPM10 module(Mindray SpO /12lead/no IBP) 6.11.4 Cables...
  • Page 207 6800-21-50337 AC input filter cable 6800-20-50513 Main unit Fan cable 6800-20-50672 Cable from mother board to DVI interface board 6800-20-50673 Cable from mother board to USB interface board 6800-20-50681 Speaker & cables Mother board to 6800-30-50124 Integral module rack flexible cable (T8) integral module rack Mother board to 6800-30-50126...
  • Page 208 Slow-release valve 6800-20-50664 Slow-release valve cable to parameter board Cable from ICG module to infrared communication 6800-20-50674 board 6800-20-50683 Mindray CO infrared communication cable 6800-30-50128 Mindray SpO flexible cable kit 6800-30-50132 Nellcor SpO flexible cable kit 6800-30-50130 Masimo SpO flexible cable kit...

  • Page 209: Upgrade

    Upgrade 7.1 Introduction You can upgrade parameter modules, functional assemblies and software by connecting the patient monitor to a PC running the System Update Tool. NOTE If you have to disassemble the patient monitor for software upgrade, be sure to eliminate the static charges before disassembling the equipment.

  • Page 210: Upgrading Parameter Modules

    , 3/5lead) 115-004900-00 MPM-2 Module (Masimo MS-2011, 3/5lead) M51A-30-80879 MPM-3 Module (Nellcor SpO , 3/5 lead) M51A-30-80880 MPM-4 Module (Mindray SpO , 12 lead) 115-004904-00 MPM-5 Module (Masimo MS-2011, 12 lead) M51A-30-80886 MPM-6 Module (Nellcor SpO , 12 lead) M51A-30-80900...
  • Page 211 M02B CO module upgrade package (for Sidestream (2 6800-30-50141 neonatal patient, with accessories) slots) Sidestream (1 115-020189-00 module slot) Oridion CO module upgrade package (with 6800-30-50820 Microstream accessories) Capnostat CO module upgrade package (with 6800-30-50852 Mainstream accessories) AG module upgrade package (with O , BIS, and 6800-30-50841 accessories...

  • Page 212: Upgrading Functional Assemblies

    7.3 Upgrading Functional Assemblies You can upgrade the following functional assemblies: Functional Description Remark assembly 6800-30-50641 SMR kit Internal AP, 6800 wireless network 801-6800-00108-00 for standard- configured upgrade kit patient monitor Wireless Internal AP, 6800 wireless network network 801-6800-00109-00 for fully configured upgrade kit patient monitor 801-6800-00002-00...

  • Page 213: Upgrading Recorder

    7.3.3 Upgrading Recorder Refer to the conrresponding section to install the recorder in your patient monitor. Refer to the Operator’s Manual for the use of recorder. 7.3.4 Upgrading Analog Output Refer to the conrresponding section to replace the interface board assembly and DVI interface board.

  • Page 214: Upgrading Software

    7.4 Upgrading Software You can upgrade the software with the System Update Tool (PN: 110-000493-00) through network. This tool can directly run on a PC. Through network or by connecting the patient monitor to a PC via a crossover network cable, you can upgrade the following programs: Software Description Remark...
  • Page 215 Software Description Remark BIOS program for parameter 0010-30-43083 module(BF531) DSP board M25P16 software M51A-30-80950 for M51A module DSP board LPC2131 software M51A-30-80951 for M51A module 7024 software for M51A The System Update Tool M51A-30-80952 module module ECG board for MPM program 110-000539-00 module software for 9008...

  • Page 216: How To Upgrade Software

    Run the System Update Tool in the PC. Select [BeneView] in the [Machine Type Selection] window and confirm. Select [Select Package] in the main screen of the Mindray Patient Monitor Software Upgrade Tool. Choose the package you want to upgrade and click [Start].
  • Page 217 7.4.1.1 Upgrading BIOS program If your BIOS program is version 1.2 or prior, the patient monitor has a blank screen during software upgrade. For BIOS program version greater than 1.2, the patient monitor enters the upgrade screen and presents related prompts during software upgrade. For example, to upgrade BIOS program from version 2.0 to 3.0 or greater, Run the System Update Tool, version 3.0.
  • Page 218 Make sure the version of the upgrade package is you desired one. If you want to obtain the latest upgrade package, contact Mindray Customer Service Department. To upgrade the MPM module from Mindray ECG algorithm to Mortara ECG algorithm, you have to send the MPM module to manufacture.

  • Page 219: A Electrical Safety Inspection

    Electrical Safety Inspection The following electrical safety tests are recommended as part of a comprehensive preventive maintenance program. They are a proven means of detecting abnormalities that, if undetected, could prove dangerous to either the patient or the operator. Additional tests may be required according to local regulations.

  • Page 220: Device Enclosure And Accessories

    A.2 Device Enclosure and Accessories A.2.1 Visual Inspection Test Item Acceptance Criteria No physical damage to the enclosure and accessories. No physical damage to meters, switches, connectors, etc. The enclosure and accessories No residue of fluid spillage (e.g., water, coffee, chemicals, etc.).
  • Page 221 Preparation First select the test current that will be used for performing the Protective Earth Resistance test by pressing AMPERES (SOFT KEY 3). Connect the test lead(s) between the RED input jack and the GREEN input jack. Press CAL LEADS. The 601PRO will measure the lead resistance, and if less than 0.150 Ohms, it will store the reading and subtract it from all earth resistance readings taken at the calibrated current.

  • Page 222: Earth Leakage Test

    NOTE When "Over" is displayed for Ohms, this signifies that a valid measurement was not obtained because either an open connection was detected or that the measurement was not within range. Readings greater than 9.999 Ohms will be displayed as Over. In Case of Failure Once it reaches the limitation, stop using and inform the Customer Service Engineer for analysis and disposal.
  • Page 223 SOFT KEY 1 toggles the DUT outlet Polarity from Normal to Off to Reverse. SOFT KEY 2 toggles the DUT outlet from Earth to No Earth. SOFT KEY 3 toggles the DUT outlet from L2 to No L2. SOFT KEY 4 toggles the AP to Earth to No AP to Earth. Press the print data key at any time to generate a printout of the latest measurement.

  • Page 224: Patient Leakage Current

    A.6 Patient Leakage Current Patient leakage currents are measured between a selected applied part and mains earth. All measurements have a true RMS only response. Preparation Perform a calibration from the Mains on Applied Part menu. The following outlet conditions apply when performing this test: Normal Polarity, Earth Open, Outlet ON Normal Polarity, Outlet ON Normal Polarity, L2 Open, Outlet ON...

  • Page 225: Mains On Applied Part Leakage

    In Case of Failure Check any broken of the enclosure. Replace any defective part. Inspect wiring for bad crimps, poor connections, or damage. Test the wall outlet; verify it is grounded and is free of other wiring abnormalities. Notify the user or owner to correct any deviations. As a work around, check the other outlets to see if they could be used instead.
  • Page 226 Preparation To perform a calibration from the Mains on Applied Part test, press CAL (SOFT KEY 2). Disconnect ALL patient leads, test leads, and DUT outlet connections. Press CAL to begin calibration, as shown: If the calibration fails, the previously stored readings will be used until a passing calibration has occurred.

  • Page 227: Patient Auxiliary Current

    NOTE If all of the applied parts correspond to the instrument type, the applied parts will be tied together and one reading will be taken. If any of the applied parts differ from the instrument type, all applied parts will be tested individually, based on the type of applied part.
  • Page 228 Press SOFT KEYS 1-4 to select leakage tests Press APPLIED PART (SOFT KEY 4) at any time to select the desired applied part leakage current: Modify the configuration of the front panel outlet by pressing the appropriate SOFT KEY on the 601PRO: Press the print data key at any time to generate a printout of the latest measurement.

  • Page 229: Scheduled Electrical Safety Inspection

    A.9 Scheduled Electrical Safety Inspection For scheduled electrical safety inspection, test items 1, 2, 3, 4, 5, 6, 7, and 8 included in the ELECTRICAL SAFETY INSPECTION FORM shall be performed. ELECTRICAL SAFETY INSPECTION FORM Location: Technician: Equipment: Control Number: Manufacturer: Model: Measurement equipment /SN:...

  • Page 230: Electrical Safety Inspection After Repair

    A.10 Electrical Safety Inspection after Repair The following table specifies test items to be performed after the equipment is repaired. Test items: 1, 2, 3 Repair with main unit not disassembled When neither power supply Test items: 1, 2, 3, 4 Repair with PCBA nor patient main unit...
  • Page 231 ELECTRICAL SAFETY INSPECTION FORM Location: Technician: Equipment: Control Number: Manufacturer: Model: Measurement equipment /SN: Date of Calibration: INSPECTION AND TESTING Pass/Fail Limit Power Cord Plug Device Enclosure and Accessories Device Labeling Protective Earth Resistance ____Ω Max 0.2 Ω Max: Normal NC: 300μA(refer to condition(NC) ____μA...
  • Page 232 FOR YOUR NOTES A-14...
  • Page 234 P/N: 6800-20-50661(13.0)

This manual is also suitable for:

Beneview t8Beneview t9

Table of Contents

Save PDF
