ALL FIBERGLASS
AGM 33 PIKE
Specifications:
Parts List
Optional Recovery System
Required to complete: 5 minute epoxy,
120/220 sandpaper, masking tape, finishing
filler/paint, Rubbing Alcohol for cleaning.
1
Length: 43.5"
Diameter 2.6"
Weight: 40oz
Recovery: 30" Nylon Chute
Motor Mount: 38mm
Fins: 6 - 3/32" G10
CP: 32.5" from nose tip
1.
(1) Fiberglass nose cone
2.
(1) G10 nose cone bulk plate
3.
(1) Pre-slotted body tube
4.
(2) G10 centering rings
5.
(1) 38mm motor tube
6.
(6) G10 fins
7.
(2) Eyebolts (4) nut, (1) washer
8.
(1) Nylon shock cord
9.
(2) Rail Buttons and Screws
1.
(1) 9"x9" flameproof chute protector
2.
(1) 30" Nylon chute
™
