K-193
98666 00193
8
Specifications:
Parts List
* 54mm version has (1) Eyebolt and (2) nut and relies on motor
forward closure anchor for shock cord.
Optional Recovery System
Required to complete: 5 minute epoxy,
120/220 sandpaper, masking tape, finishing
2
Tomach
FIBERGLASS KIT
Length: 63"
Diameter 2.6"
Weight: 28oz
Recovery: 30"/14" Nylon Chutes
Motor Mount: 38mm or 54mm
Fins: 3 - 1/16" G10
CP: 48" from nose tip
1.
(1) Fiberglass nose cone
2.
(1) Fiberglass nose cone coupler
3.
(1) G10 nose cone bulk plate
4.
(1) Pre-slotted body tube (33")
5.
(1) Payload tube (16")
5.
(2) G10 centering rings
6.
(1) 38mm (8") or 54mm (12") MMT
7.
(3) G10 fins
8.
(2) Eyebolts (4) nut, (1) washer*
9.
(2) Nylon shock cords
10. (2) Rail Buttons and Screws
11. (1) Fiberglass Removable A-Bay
1.
(2) 9"x9" flameproof chute protector
2.
(1) 30" Nylon chute (Main)
3.
(1) 14" Nylon chute (Drogue)
™
