Description of charging of the battery

The product is provided with built-in chargeable battery. When the
battery level is not sufficient, please charge it in time through two
modes.
Charging mode 1:
Please charge it through USB Type-C interface of the thermal
imagery telescope and pull off the USB line after charging is
completed.
Charging mode 2:
1. Open the battery cover to take out the batteries.
2. Please use the charger provided by the original factory to charge
the batteries and install the batteries according to the polarity on
the charger correctly.
3. Please disconnect the power supply of the charger in time after
fully charging.
USB interface
Battery case
LED Indicator light
Contact of the
positive electrode
Contact of the
negative electrode
6
Prompt: If the device is out of use for a long time, please charge it
once every three months to avoid irreversible reduced capacity loss
due to self discharge of the battery due to long-term storage.

Instruction for battery installation

1. Open the battery cover: screw off the battery cover in anti-clock-
wise direction.
2. Install the lithium battery: put the battery into the battery
compartment with the negative electrode facing outwards as shown
in figure 1.
3. Install the battery cover: screw up the battery cover in clockwise
figure 1
-
+
7
