- Page 1 HEAVY-DUTY TOOL TROLLEY Model No: CTT320 Part No: 7630630 ASSEMBLY INSTRUCTIONS GC12/11...
- Page 2 GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for its intended purpose.
- Page 3 Before assembling, please check contents against the following list of loose items on page 4, and advise your Clarke dealer immediately if any parts are missing. The keys to the top drawer are taped inside the unit.
- Page 4 COMPONENT PARTS Parts & Service: 020 8988 7400/E-mail:Parts@clarkeinternational.com or Service@clarkeinternational.com...
- Page 5 ASSEMBLY STEP 1 Using carriage bolts (I), flat washers (J) and nuts (K), attach the casters (G) and (H) in matched pairs, with the braked casters (H) at one end of the bottom tray. STEP 2 Upper end Lower end 1.4”...
- Page 6 STEP 3 Using the M8 bolts (L) nuts (M) & washers (S), attach both the short frames (B) to the corner frames (E). Using further M8 bolts, nuts & washers, attach the tool tray (R) to the corner frames. STEP 4 With the help of an assistant, align the upper shelf assembly (A) with the top of the corner uprights (E) and attach...
- Page 7 Fit the side handle (F) as shown, by inserting two STEP 5 bolts (I) through the lower two holes & securing with nuts and washers. The handle is best fixed to the end of the trolley already fitted with braked casters for safer manouvering of the trolley.
