AXIOMTEK SHB230 Quick Installation Manual page 2

Connectors
Connector
External Temperature Sensor
Connector (Optional)
Digital I/O
DVI-I Connector
LVDS Connector
LVDS Inverter Connector
USB Port 0/1
USB Port 2/3
Axiomtek Front Panel
USB2.0/3.0 Port 1
PS2 Connector(Keyboard & Mouse)
USB2.0/3.0 Port 2
SYS FAN
CPU FAN
RJ45 ( i217LM)
RJ45 ( i210AT)
SATA 1 ~ 2 6Gb (SATA3)
CFast™ Connector
COM1 ~ COM2 Connecters
Audio Connector
2
Description
CN2
CN1
CN6
CN7
CN5
CN10
CN12
CN3
CN11
CN8
CN9
FAN1
FAN2
LAN1
LAN2
SATA1~SATA2
SCF1
COM1
AUDIO1
9418C230000E
©
Copyright 2014 Axiomtek Co., Ltd.
Version A1 March 2014
Printed in Taiwan
Board Layout
Top Side
9418C230000E
©
Copyright 2014 Axiomtek Co., Ltd.
Version A1 March 2014
Printed in Taiwan
3
