Solution overview

This application note describes how to configure an Anybus AS-Interface Master module and how to set up
the AS-Interface network. Below you can find an overview of the system described in this document. Other
nodes may be attached to the network, but are not necessary.
The configuration is described in two steps.
1. The Anybus Master module configuration is explained.
2. The configuration of the AS-Interface network is described.
Note: This document is valid for all Anybus AS-Interface Master products, however sections written in
italics describe the configuration of a specific product.
The contents describe step by step how a configuration is done. This document assumes the reader is familiar
with industrial communication, AS-Interface networks and Anybus X-gateway.
AS-Interface
Master
Other network
i.e. Modbus-TCP
Figure 1 Hardware connection overview.
www.anybus.com
Example of AS-Interface
network
AS-Interface
Anybus X-gateway
Modbus-TCP
PC
ModScan
HMS Industrial Networks AB
How to configure an Anybus AS-Interface Master module
SCM-7032-036
Rev 1.02
AS-Interface
Anybus AS-Interface
Master PCI
