Steelcase CFSTDDUALBAR Assembly Instructions Manual page 2

®
A Top Down Mount
B Forearm Cap 1x
115864
C M6-1 x 12mm Phillips Pan Head Screw 1x
716386
D Flat Washer 2x
715866
E Bushing
114548
1x F Quick Connect VESA Plate 2x
8524
G M4 x 12mm Phillips Pan Head Screw 8x
H
I
1x J 10-32 x 3/8" FPhMS w/Lock Patch 2x
K
114808
L
701153
Monitor Tilter 2x M
8500 Tilter
Dog Washer 2x N
105189
O
705198
Cable Cap 1x P*
114810
3mm Allen Wrench 1x Q*
701313
1/8" Allen Wrench 1x R*
701312
3/32" Allen Wrench 1x
* Included with optional thru-desk kit only,
700146
1439137001SR (sold separately).
7/32" Allen Wrench 1x
701127
Parts List
M8 x 95mm SCHS 1x
716061
Spacer 1x
701544
Lock Nut 1x
710015
Page 1 of 12
P/N 1439128001
158043 Rev B
