Matrix 908 Field Computer

CONSOLE CONNECTIONS AND FEATURES

Power Button
Serial Number
Camera Connection*
Harness Connection
Speaker
Power On/Off Button
On – Press the POWER button
Off – Press and briefly hold the POWER button
WARNING! Wait 30 seconds before restarting the console.
Serial Number
Take note of your serial number. It is required for product registration.
Product Registration
8
www.teejet.com
Integrated RAM Mount (assembly required)
Ethernet Connection*
.
.
USB Port
GNSS Antenna Connection
*Connection Activity is dependent on software version.
WiFi Antenna
Connection*
