Delete Last Marked Boundary - Spraying Systems TeeJet Matrix 908 User Manual

6. Travel the perimeter of the application area.
While traveling, use as needed:
Pause Boundary – pauses the
mark boundary process. A straight
line will be drawn between the pause point
and the resume point.
Resume Boundary – resumes the
mark boundary process. A straight
line will be drawn between the pause point
and the resume point.
Cancel Boundary – cancels mark
boundary process.
7. Finish the boundary:
Automatic close – travel to within one swath width
of the starting point. The boundary will
close automatically (the white guideline will
turn black).
Manual close – press the FINISH
BOUNDARY icon to close the
boundary with a straight line between the
current location and the starting point.
NOTE: If the minimum distance is not travelled
(five times the swath width), an error message
will pop-up.
8. Press:
►Accept – to save and manually name the
boundary
►Decline – to save and automatically name the
boundary

Delete Last Marked Boundary

Delete Last Marked Boundary (interior or exterior)
deletes the last marked boundary from the current job.
Delete Exterior Boundary
Delete Interior Boundary
Matrix 908 Field Computer
29
98-01578-EN R0
