DIMENSIONS - UNIT BASE
Figure 11.1 - Unit Base Dimensions
4.09
2.53
1.37
INSIDE BASE ASSEMBLY
DETAIL VIEW
2.53
2.53
LANDING AREA
FOR ROOF CURB
ATH15-520.2
85.22
90.28
BASE ASSEMBLY AS
VIEWED FROM BOTTOM
90.28
BASE ASSEMBLY AS
VIEWED FROM SIDE
59.22
11
