- Page 1 Innovation In and Out of Parlour ATL HDX Active Sync Manual Version - 1.1 Date - October 2017 Part Number - 39-0215...
- Page 2 Innovation In and Out of Parlour INDEX GOOD PRACTICE: Control, Power and Data Cables and Conduit. Good Practice Cables must be kept as short as possible running directly from point to point. Cut out any excess cable rather than leaving it coiled. ATL V2.00 HDX Reader Synchronisation Connections: Where ever possible cables should be contained in a waterproof conduit using the correct...
- Page 3 Innovation In and Out of Parlour ATL V2.00 HDX Reader Synchronisation to Non-ATL HDX Reader WARNING: DO NOT RUN TWISTED PAIR DATA CABLE NEXT TO MAINS CABLES OR CABLES CARRYING HIGH CURRENT AS WILL CAUSE INTERFERENCE AND SYSTEM WILL NOT FUNCTION CORRECTLY. Master / Slave Jumper V2.00.03 16-12-08...
- Page 4 Innovation In and Out of Parlour ATL V3.00 HDX Reader Synchronisation to Non-ATL HDX Reader WARNING: DO NOT RUN TWISTED PAIR DATA CABLE NEXT TO MAINS CABLES OR CABLES CARRYING HIGH CURRENT AS WILL CAUSE INTERFERENCE AND SYSTEM WILL NOT FUNCTION CORRECTLY. Master / Slave Switch (Switch 1) Set to ON to synchronise V3.02...
