- Page 1 Innovation In and Out of Parlour Milk Meter Installation Manual Version - 1.2 Date - December 2014 Part Number - 39-0062...
-
Page 2: Table Of Contents
Innovation In and Out of Parlour Index Manual Version......................Good Installation Practice....................The Milk Meter Flask..................... Milk Meter Flask and Solenoid Box Mounting..............Milk Meter Control and Wash Box Mounting..............Connection Box Mounting..................... Milk Meter System Wiring Overview................Switch Mode Power Supply Wiring Connections..............Solenoid Box Installation..................... -
Page 3: Index
Innovation In and Out of Parlour Index MicroM3S Setup for Milk Meters..................Wash Box Wiring......................Wiring the Wash Box into the Connection Box..............Setting Up the Wash Box The Wash Time......................The Type of Milk Meter System..................Setting the Number of Milking Points on a Stand-Alone System..........Setting the Cumulative Milk Yield to Automatically Zero on a Stand-Alone System.... -
Page 4: Manual Version
Innovation In and Out of Parlour Manual Versions Version 1.0 - December 2013..............First Version of Manual Version 1.1 - February 2014..Added lift to start ACR, wash slugger and delivery line drain valve wiring Version 1.2 - December 2014........Added milking time, kick off and rotary cluster drop 4 | Milk Meter Installation Manual | v1.2... -
Page 5: Good Installation Practice
Innovation In and Out of Parlour Good Installation Practice Mains Supply A separate mains supply and earth running directly from the customers distribution board is essential. Avoid routing the mains cable to the power supply close to other supplies especially those providing intermittent current - motors that are starting and stopping continually or high power heaters with thermostatic control. - Page 6 Innovation In and Out of Parlour Good Installation Practice Continued Adopting good engineering practice during installation will avoid most problems with electronic control systems. The following should be considered when installing milk meter systems: Check the existing wiring carefully. Do not assume that it will be up to the required standard. It may have been extended with thinner wire and be unable to carry the current without a volt drop.
-
Page 7: The Milk Meter Flask
Innovation In and Out of Parlour The Milk Meter Flask The milk meter is despatched from ATL with the top bracket attached and milk inlet to right-hand side. Fit the milk meter onto the main bracket by releasing the M6 wing nut and slotting the top bracket onto the M6 stud. Locate the M5 flange nuts on the base of the milk meter into the 2 holes in the base of the main bracket. -
Page 8: Milk Meter Flask And Solenoid Box Mounting
Innovation In and Out of Parlour Milk Meter Flask and Solenoid Box Mounting - High Level The milk meter and the solenoid box are mounted on the same 1.25” nominal bore tube. The diagram below shows the preferred mounting arrangement. Shut-Off Valve IMPORTANT - Milk Meter Flask... -
Page 9: Milk Meter Control And Wash Box Mounting
Innovation In and Out of Parlour Milk Meter Control and Wash Box Mounting The Control Box comes with a standard bracket which allows mounting on a 1.25 inch (nominal bore) tube either vertically or horizontally using exhaust clamps. M4 x 16mm Pozi-Pan S/S &... -
Page 10: Connection Box Mounting
Innovation In and Out of Parlour Connection Box Mounting The connection box is mounted on the same 1.25” nominal bore tube. The diagram below shows the preferred mounting arrangement. Spring Clips Connection Box 1.25 Inch (Nominal Bore) 10 | Milk Meter Installation Manual | v1.2... -
Page 11: Milk Meter System Wiring Overview
Innovation In and Out of Parlour Milk Meter System Wiring Overview IMPORTANT - Wire power to each connection box separately to ensure equal loading. If power supply to connection boxes is daisy chained from one to another, ATL will not cover warranty if connection boards fail due to power overload. -
Page 12: Switch Mode Power Supply Wiring Connections
Innovation In and Out of Parlour Switch Mode Power Supply Wiring Connections Mains Voltage: 100-240volt AC Ensure the loading on each power supply is as even as possible. Output Voltage: Nominal 13.6volt DC Mains Fuse: 5 Amp Recommended ACR Solenoid Spec: 1 2 v o l t DC Continuous Operation Normally Closed with Automatic Over Current Protection... -
Page 13: Solenoid Box Installation
Innovation In and Out of Parlour Solenoid Box Installation The solenoid box contains two solenoids, one is used to operate the milk meter plunger, the other the shut-off valve. The box is fitted with two spring clips to enable easy installation to a 1.25 inch (nominal bore) tube. The solenoid box is delivered pre-wired. -
Page 14: Solenoid Box Installation (With Pulsation Stop)
Innovation In and Out of Parlour Solenoid Box Installation (with Pulsation Stop - PCB CON218) The solenoid box contains two solenoids, one is used to operate the milk meter plunger, the other the shut-off valve. The box is fitted with two spring clips to enable easy installation to a 1.25 inch (nominal bore) tube. The solenoid box is delivered pre-wired. -
Page 15: Interpuls Acr Ram And Cv20 Control Valve Connections To Solenoid Box
Innovation In and Out of Parlour Interpuls ACR Ram and Cv20 Control Valve Connections to Solenoid Box Solenoid Box Solenoid Box NB - Diodes included within solenoid box Connect moulded 3-pin connector into Cv20 control valve and crimped connectors onto respective solenoid boxes. 1 2 3 Interpuls CV20 Solenoid Valve... -
Page 16: Solenoid Box Wiring On Pulsation Stop Systems
Innovation In and Out of Parlour Solenoid Box ACR Wiring on Pulsation Stop Systems (using PCB CON218) A link wire is required between each pair of solenoid boxes which use one control valve for the ACR ram. The diagram below shows the wiring. Milk Meter Point 1 Milk Meter Point 2 ACR Solenoid... -
Page 17: Interpuls Acr Ram And Cv20 Control Valve Connections To Milk Meter Control
Innovation In and Out of Parlour Interpuls ACR Ram and CV20 Control Valve Connections to Milk Meter Control IMPORTANT - Only connect to milk meter display on low level milking parlours) + Brown + Brown Micro Milk Micro Milk Meter Meter IMPORTANT - Diodes not included within milk meter control so... -
Page 18: Lift To Start Ac Connections To Milk Meter Control
Innovation In and Out of Parlour Lift to Start ACR Connections to Milk Meter Control Start - - + Link the - Power Ground to the - Start Lift to Start ACR Ram 18 | Milk Meter Installation Manual | v1.2... -
Page 19: 24Vac Or 24Vdc Acr Ram And Solenoid Connections
Innovation In and Out of Parlour 24vAC or 24vDC ACR Ram and Solenoid Connections 1N4002 Diode IMPORTANT - Diodes not included within milk meter control so should be installed on CV20 solenoid valve - see diagram below Solenoid Box Common Positive (+) 12volts Diode 1N4002 across terminals. -
Page 20: Milk Meter Control Wiring
Innovation In and Out of Parlour Milk Meter Control Wiring The Milk Meter Control Box has a large character backlit LCD display and 6 button keypad to access real-time and historical (must be connected to MicroM3S control) milk yield and animal information. Left/Right Input Left/Right Ground LCD Screen Contrast... -
Page 21: Connection Box Wiring
Innovation In and Out of Parlour Connection Box Wiring Cat5e Cable To Cat5e Cable Milk Meter Display 6 OUT To Next Connection Box Auxiliary Gland Cat5e Cable To Milk Meter Display 5 Power LED Green - Correct Polarity Red - Wrong Polarity 2.5Amp Brown 1.5 Spare Power Positive +... -
Page 22: The Parlour Type Setting
Innovation In and Out of Parlour Setting Up The Milk Meter System Before it can be used, the Milk Meter System must be setup. This is outlined in the following pages. The Parlour Type Setting This setting selects the type of parlour the milk meter control is being installed on. The setting allows for doubled-up (via LHS and RHS settings), swingover and rotary parlours. -
Page 23: The Drop Value Setting
Innovation In and Out of Parlour The Drop Value Setting The drop value is the calibration setting for the milk meter ‘dump’ value. It is the meter chamber volume in millilires. It can be changed to take up any minor variations in chamber size, trigger point or milk conductivity value. -
Page 24: The Purge Setting
Innovation In and Out of Parlour The Purge Setting The purge setting is a simple ON/OFF function. When the ACR operates and the ram pulls the cluster, setting purge ON makes the shut-off valve momentarily open to allow a blast of air to enter the line and purge any milk residues through the milk line. -
Page 25: The Kick Off Enable Setting
Innovation In and Out of Parlour The Kick Off Enable Setting The kick off enable setting lets the user specify a length of time the length of time after the ACR hold off delay has passed, that if an ACR take off occurs, the control will give a kick off alert. To Alter the Kick Off Enable value: Select either Y or N by using the LEFT and RIGHT... -
Page 26: Checking The Software Version Of The Milk Meter Display
Innovation In and Out of Parlour Checking the Software Version of the Milk Meter Display To check the software version: Press and hold the LEFT, WASH, MILK and RIGHT arrow keys to display the software version Release the keys The software version of the wash box is now displayed. To exit press the WASH 26 | Milk Meter Installation Manual | v1.2... -
Page 27: Microm3S Setup For Milk Meters
Innovation In and Out of Parlour MicroM3S Setup If the Milk Meter system is linked to a MicroM3S, the following setup needs to take place. IMPORTANT - For these subroutines to be available the software in the MicroM3S control needs to be: MAIN PCB - V4.23 or greater Have Subroutine 331 enabled (see next page) SET Milk Meter SYSTEM: Subroutine 311... - Page 28 Innovation In and Out of Parlour MicroM3S Setup Continued SET VERSION 2 MILK METER SYSTEM: Subroutine 331 Program Ration Yield/Flags This subroutine tells the micro control to communicate using version 2 protocols. Check that Program Mode is selected. Run the subroutine. The message ‘v200’ is displayed with ‘yES’ or ‘no’ in the Yield/Flags window.
-
Page 29: Wash Box Wiring
Innovation In and Out of Parlour Wash Box Wiring The Wash Box has a large character backlit LCD display and 6 button keypad to set the parlour into wash, idle or milking modes. For Stand - Alone mode wire into Meridian Master connections (Connections marked M), for all other modes wire into slave connections (Connections marked S). -
Page 30: Wiring The Wash Box Into The Connection Box
Innovation In and Out of Parlour Connection Box Wash Box Wiring Connect Wash box to any spare meter connection (F2 etc) or if a spare is not available, connect using spare power (F3) and meridian connection (F4). 2.5Amp Resettable Fuse 2.5Amp Resettable Fuse Connecting the RJ45 Cable... -
Page 31: Setting Up The Wash Box
Innovation In and Out of Parlour Setting Up The Wash Box Before it can be used, the Milk Meter System must be setup. This is outlined in the following pages. The Wash Time This sets the wash time for the Milk Meter system. To Set the Wash Time: Press and hold the IDLE, TICK,... -
Page 32: Setting The Cumulative Milk Yield To Automatically Zero On A Stand-Alone System
Innovation In and Out of Parlour Setting the Cumulative Milk Yield to Automatically Zero on a Stand-Alone System This automatically sets the milk yield totaliser to zero. To Set the Cumulative Milk Yield Automatic Zero On or Off: Select by using the UP and DOWN arrow keys N = Do not clear cumulative milk yield on entering Milking Mode... -
Page 33: Setting The Air Blast Channel 2 On Time
Innovation In and Out of Parlour Setting the Air Blast Channel 2 On Time - Software v2.10 onwards This sets the channel 2 on time for the wash slug air blast system. To Set the Channel 2 On Time: Select by using the UP and DOWN arrow keys NB If the TICK... -
Page 34: The Dump Line Enable Setting
Innovation In and Out of Parlour The Dump Line Enable Setting This setting enables the milk line and dump line to be washed automatically through the milk meter. It allows the time the milk meter is connected to the dump line and the milk line to be set and altered, allowing each line to be washed during a normal wash cycle of the parlour. -
Page 35: The Compressed Air Purge Of The Delivery Line Setting
Innovation In and Out of Parlour The Compressed Air Purge of the Milk Delivery Line Setting - Software v2.12 onwards This setting enables the drop output on the wash box to be used to control the input of compressed air into the milk delivery line to purge the majority of the remaining milk at the end of milking through to the bulk milk tank. -
Page 36: The Milk Pump Air Blast Hold Off Setting
Innovation In and Out of Parlour The Milk Pump Air Blast Hold Off Setting This setting is a hold off time that delays the air blast on the milk line operating for X 1-60 seconds if the milk pump has just started running. It is to help systems whereby there is the possibility during washing the milk pump cannot keep up with the amount of water in the system and is designed to try and provide a buffer to prevent the ball going up on the sanitary trap and the wash finishing prematurely. -
Page 37: Checking The Software Version Of The Wash Box
Innovation In and Out of Parlour Checking the Software Version of the Wash Box To check the software version: Press and hold the IDLE, TICK, and DOWN arrow keys to display the software version. Release the keys The software version of the wash box is now displayed. To exit press the IDLE 37 | Milk Meter Installation Manual | v1.2... -
Page 38: Calibrating The Milk Meter System - Method 1
Innovation In and Out of Parlour Calibrating the Milk Meter System - Method 1 To ensure accurate performance each Milk Meter requires calibrating before use. This procedure may be carried out between milkings using milk or a hypochlorite solution. The calibration equipment required is as follows: 15 litres of milk or 3% Hypochlorite solution 1 metre length of 16mm stainless steel pipe with 1mm hole in the end... - Page 39 Innovation In and Out of Parlour Calibrating the Milk Meter System Continued Press the WASH key to confirm drop value and press it further times to step to the end of the setup routine. Note the drop value from the milk meter control onto the calibration chart (NB factory default figure is 200) (photocopy chart on next page).
- Page 40 Innovation In and Out of Parlour Milk Meter Calibration Form - SAMPLE Milk Meter No. Original Drop Value Reading No. Scales - Kilogram Control - Litres Scales - Litres* 12.0 12.5 11.2 12.3 11.0 11.8 12.0 11.2 12.5 Total 37.3 35.8 33.4 A = Total Weighing Scale Readings (litres)
- Page 41 Innovation In and Out of Parlour Checking the Calibration of the Milk Meter System It is recommended that a Calibration Check is carried out on each Milk Meter annually. To check the calibration follow the instructions on calibrating the milk meter on page 33. The resulting relative error should be not more than +/-5%;...
- Page 42 Innovation In and Out of Parlour Milk Meter Calibration Check Form - SAMPLE Milk Meter No. Original Drop Value Reading No. Scales - Kilogram Control - Litres Scales - Litres* 12.0 12.5 11.2 12.3 11.0 11.8 12.0 11.2 12.5 Total 37.3 35.8 33.4...
-
Page 43: Calibrating The Milk Meter System - Method 2
Innovation In and Out of Parlour Calibrating the Milk Meter System - Method 2 Another method for calibrating the Milk Meter system is by comparing the daily milk yield total in either the Micro Wash Control on stand-alone systems or the MicroM3S on integrated systems to the bulk tank total. Set the drop value to 200 (this is the factory default). -
Page 44: Calibrating Milk Meter Systems Integrated With The Microm3S Control
Innovation In and Out of Parlour Calibrating Milk Meter Systems integrated with the MicroM3S After a few days make a note of the Daily Milk Yield Total on the MicroM3S. The Daily Milk Yield Total is stored under the Herd Totals. The Daily Milk Yield Total is calculated during the 11:00am automatic housekeeping routine. - Page 45 Innovation In and Out of Parlour Additional Items Required to Install Milk Meter System A 1¼” spline to mount the milk meter and solenoid connection box (one per milking pint, 1¼” U bolts supplied. 6mm PVC signal pipe to connect the shut off valve and the milk meter to the solenoid box (approx 2m per point).
